UNIVIEW · NETWORK VIDEO RECORDERSUniview NVR502-32E-IX-G 32-Channel SeekFree AI NVR 2-HDD
Search larger Uniview CCTV systems with SeekFree natural-language and image-based tools. The NVR502-32E-IX-G supports 32 IP channels, two SATA drive bays and independent paired HDMI/VGA outputs, with no built-in PoE camera ports.
Model
NVR502-32E-IX-G, distinct from the IM-G version
Built-in PoE
None, external camera power required
Camera resolution
Up to 16MP
Designed for your installation
AcuSearch and AcuTrack help locate and follow relevant targets in supported recordings. External PoE switches let the network be distributed around a larger site, provided the switching capacity, power budget and cabling are designed for the connected cameras.
192 Mbps incoming and outgoing
Storage
2 SATA HDD bays, up to 24 TB per drive
2 HDMI plus 2 VGA, paired independent outputs
Technical Specifications
| Model |
NVR502-32E-IX-G |
| Model |
NVR502-32E-IX-G, distinct from the IM-G version |
| IP channels |
32 |
| Built-in PoE |
None, external camera power required |
| Camera resolution |
Up to 16MP |
| Bandwidth |
192 Mbps incoming and outgoing |
| Storage |
2 SATA HDD bays, up to 24 TB per drive |
| HDD included |
No |
| Video outputs |
2 HDMI plus 2 VGA, paired independent outputs |
| Maximum HDMI mode |
4K at 30 Hz |
| Decoding with smart functions off |
Up to 32 × 1080p streams |
| Decoding with smart functions on |
Up to 16 × 1080p streams |
| SeekFree resources |
Up to 32 compatible UNV SIP/UMD channels or 16 normal-camera channels, resolution-dependent |
| Search |
Natural-language English search, AcuSearch and AcuTrack on supported footage |
| Recording recovery |
ANR with compatible cameras and storage |
| Power |
12 VDC |
Setup and compatibility
Use supported cameras, firmware and recording settings for the required SeekFree functions. Search and decoding limits change with resolution and smart mode. Add compatible surveillance HDDs and external PoE switches; this unit cannot power cameras directly.
Downloads
NVR502-32E-IX-G Datasheet (PDF)
Frequently asked questions
Does NVR502-32E-IX-G include a hard drive?
No hard drive is included in the base listing. Select compatible surveillance-rated HDDs separately before local recording.
What should I check before installation?
Use supported cameras, firmware and recording settings for the required SeekFree functions. Search and decoding limits change with resolution and smart mode. Add compatible surveillance HDDs and external PoE switches; this unit cannot power cameras directly.
Where can I download the NVR502-32E-IX-G datasheet?
The manufacturer PDF is hosted on CCTV Guru’s Shopify file library and linked in Downloads on this product page.
