Complete Dahua 10″ Android Video Intercom Kit · PoE
10″ Android Kit
A premium front-door system built around a big 10-inch Android touchscreen monitor. The kit pairs the VTO2202F-P-S2 door station (2MP colour, 160° fisheye view) with the Android VTH5341G-W monitor, an IP-COM F1106P-4-63W 4-port PoE switch and a weatherproof rain cover. See and speak to visitors, unlock up to two doors, and answer from the DMSS app over Wi-Fi or Ethernet — all genuine Dahua, backed by Australian stock and local support.
In The Kit
Door Station + 10″ Monitor + PoE Switch
Big Screen
10″ Android Touchscreen
Wide View
160° Fisheye 2MP Colour
App Control
DMSS Talk & Unlock
Why Choose This Dahua 10″ Android Intercom Kit
Premium 10″ Android Monitor
A large 10-inch capacitive touchscreen on Android 8.1 gives a smooth, smartphone-like experience for answering and managing the door.
160° Fisheye Coverage
The 2MP colour camera captures a wide 160° view, so you see visitors head-to-toe and parcels left at the door.
True PoE Install
The IP-COM F1106P-4-63W carries power and data over a single cable to the monitor and door station — cleaner wiring, fewer plugs.
Unlock Up To Two Doors
Built-in access control drives two locks — handy for a gate plus a front door, or door plus garage.
DMSS App + Wi-Fi
The monitor connects over Ethernet or Wi-Fi, so you can answer visitors and unlock from your phone anywhere.
Weatherproof & Protected
The IP65 / IK07 door station ships with a surface rain cover for reliable performance at exposed entries.
What's In The Box
1 × 2-Wire IP Door Station — VTO2202F-P-S2
Anodised aluminium panel, 2MP colour 160° fisheye low-illumination camera, two-way video, access control for two locks, 2-wire & RJ45, H.265, IK07 / IP65, surface or flush mount.
1 × 10″ Android Indoor Monitor — VTH5341G-W
Android 8.1, 10-inch TFT capacitive touchscreen (1024×600), Ethernet & Wi-Fi, PoE, DMSS app, optional microSD up to 256GB.
1 × IP-COM 4-Port PoE Switch
F1106P-4-63W. 6 ports total (4× PoE + 2× uplink), 802.3af/at, up to 30W per port, extend mode to 250m, plug-and-play, desk or wall mount.
1 × Surface Rain Cover — VTM05R
Surface-mount rain cover for the door station, shielding it from weather at the entry.
Technical Specifications
Door Station — VTO2202F-P-S2
Camera
2MP HD colour, low illumination
View Angle
160° fisheye
Panel
Anodised aluminium
Access Control
Supports two locks
App
DMSS talk & remote unlock
Wiring
2-wire & RJ45 compatible, PoE
Video Coding
H.265
Protection
IP65 & IK07
Mounting
Surface or flush
Indoor Monitor — VTH5341G-W (Android)
OS
Android 8.1
Screen
10-inch TFT capacitive touchscreen
Resolution
1024 × 600
Network
Ethernet & Wi-Fi
Power
Standard PoE
Storage
Optional microSD, up to 256GB
App
DMSS remote answering & unlock
PoE Switch — IP-COM F1106P-4-63W
Ports
4 × 10/100 PoE + 2 × 10/100 uplink (6 total)
PoE Standard
IEEE 802.3af / 802.3at
Per-Port PoE
Up to 30W
Total PoE Power
Up to 63W
Backplane
1.2 Gbps
Extend Mode
Up to 250m transmission
Mounting
Desktop or wall-mount, plug & play
Datasheets & Guides
VTO2202F-P-S2 Door Station Datasheet
Dahua Door Station Quick Start Guide
VTH5341G-W Monitor Datasheet
Dahua Indoor Monitor User Manual
F1106P-4-63W Switch Datasheet
IP-COM PoE Switch Quick Start Guide
Frequently Asked Questions
What's included in this kit?The VTO2202F-P-S2 door station, a 10-inch Android VTH5341G-W monitor, an IP-COM F1106P-4-63W 4-port PoE switch and a VTM05R rain cover.
What makes the monitor special?It's a large 10-inch Android 8.1 touchscreen with a smooth, app-like interface and both Ethernet and Wi-Fi.
Can I answer the door from my phone?Yes. The Dahua DMSS app lets you talk to visitors and unlock the door remotely.
Can it unlock more than one door?Yes. The door station's access control supports two locks — for example a gate and a front door.
How wide is the camera view?The 2MP colour fisheye camera captures a wide 160° view to see visitors and parcels close to the door.
How many devices does the PoE switch power?The F1106P-4-63W has 4 PoE ports — ample for the monitor, door station and an extra camera, up to 30W each.
Is the door station weatherproof?Yes. The VTO2202F-P-S2 is IP65 weather-rated and IK07 impact-rated, and ships with a surface rain cover.
Is a door lock included?No. Electric strikes, magnetic locks and exit buttons are chosen separately to suit your door type.
