UniFi Dream Router 7 — WiFi 7 All-in-One Cloud Gateway & NVR (UDR7)
The Ubiquiti UniFi Dream Router 7 (UDR7) packs an entire UniFi network into one compact desktop console — a WiFi 7 router, multi-WAN security gateway, PoE switch, and built-in UniFi Protect NVR, all in a single unit with no subscription. It runs the full UniFi application suite — Network, Protect, Access, Talk and Connect — manages 30+ devices and a handful of cameras, and routes up to 2.3 Gbps of IDS/IPS through a 10G SFP+ WAN. Ideal for homes, home offices, and small businesses across Australia, backed by genuine Ubiquiti stock and fast Australia-wide shipping.
WiFi
WiFi 7
WAN
10G SFP+
IDS / IPS
2.3 Gbps
Protect NVR
Built-in
Why Choose the UniFi Dream Router 7?
Whole UniFi Stack in One Box
Runs the full UniFi application suite — Network, Protect, Access, Talk and Connect — so one console handles routing, WiFi, cameras, door access, and VoIP with no monthly fees.
WiFi 7 Tri-Band
Tri-band WiFi 7 (2.4/5/6 GHz) delivers up to 5.7 Gbps on 6 GHz with 2×2 MU-MIMO and ~160 m² of coverage — fast, low-latency wireless for modern devices.
Built-in Protect NVR
A pre-installed 64 GB microSD records UniFi Protect cameras locally — supports up to 5 HD, 2 × 2K, or 1 × 4K camera — expandable via the microSD slot, no separate NVR needed.
10G SFP+ & Multi-WAN
A 10G SFP+ plus 2.5 GbE WAN and up to 4 WAN ports give multi-gig internet, load balancing, failover, and UniFi LTE backup support.
Enterprise Security & VPN
2.3 Gbps IDS/IPS, Layer 7 firewall, content filtering, ad blocking, plus license-free SD-WAN and a full VPN suite — WireGuard, OpenVPN, L2TP, Teleport and Site Magic.
Integrated PoE Port
Four 2.5 GbE LAN ports include one PoE output (15.4 W) to power a camera or access point directly — add a UniFi PoE switch for larger camera systems.
NDAA Compliant
Fully NDAA Section 889 compliant for government, defence, and security-sensitive networks.
Technical Specifications
Model
UDR7 (UniFi Dream Router 7)
UniFi Applications
Network, Protect, Access, Talk, Connect
Managed UniFi Devices
30+
Managed Cameras
5 × HD • 2 × 2K • 1 × 4K
Simultaneous Clients
300+
WiFi
WiFi 7 tri-band (2.4/5/6 GHz) • 6 GHz 5.7 Gbps, 5 GHz 4.3 Gbps, 2.4 GHz 688 Mbps • 2×2 MU-MIMO
Coverage
~160 m² (1,750 ft²)
Ports
1 × 10G SFP+ (WAN) • 4 × 2.5 GbE RJ45 (1 with PoE output)
Max WAN Ports
4 (multi-WAN load balancing & failover)
IDS/IPS Throughput
2.3 Gbps (20,000+ signatures with CyberSecure)
Security
Stateful + Layer 7 firewall, DPI, zone-based filtering, content filtering, ad blocking, IPS/IDS
VPN & SD-WAN
License-free SD-WAN, Site Magic, IPsec, WireGuard, OpenVPN, L2TP, Teleport
NVR Storage
Pre-installed 64 GB microSD • microSD expansion slot
PoE
1 PoE port, 15.4 W budget (44–57 V)
Processor / Memory
Quad-core Arm® Cortex®-A53 @ 1.5 GHz • 3 GB RAM
Display
0.96″ status LCM
Power
Universal AC 100–240 V, internal 50 W PSU • max 26 W (excl. PoE)
Dimensions / Weight
⌀110 × 184.1 mm • 1.1 kg
Operating Temperature
−10 to 40°C, 5–95% non-condensing
Certifications
CE, FCC, IC, Anatel
Compliance
NDAA compliant
Downloads & Resources
UDR7 Datasheet
Ubiquiti Dream Router 7 Quick Start Guide
What's in the Box
UniFi Dream Router 7
UDR7 console with pre-installed 64 GB microSD.
Power Cable
Universal AC power lead (internal 50 W PSU).
Documentation
Quick-start guide and setup instructions.
Required Separately
An SFP+ module / fibre or RJ45-SFP for the 10G WAN if needed, and a UniFi PoE switch for larger camera systems.
Best For
Homes & Apartments
One device for WiFi 7, routing, and a few Protect cameras — no separate NVR or AP.
Home Offices
Multi-gig 10G WAN, VPN, and enterprise security in a silent desktop unit.
Small Business
Run Network, Protect, Access, and Talk together with no monthly fees.
UniFi Starters
The simplest way to launch a full UniFi stack and expand with switches and APs later.
Runs the UniFi application suite locally — add UniFi cameras, switches, and access points as you grow.
WAN via 10G SFP+ or the 2.5 GbE port; the four 2.5 GbE ports cover LAN, with one PoE output (15.4 W).
The pre-installed 64 GB microSD records Protect cameras; swap in a larger card for more footage.
For more than a couple of cameras or PoE devices, pair with a UniFi PoE switch.
Frequently Asked Questions
Does the UDR7 run UniFi Protect cameras?
Yes. It includes a built-in Protect NVR with a pre-installed 64 GB microSD and supports up to 5 HD, 2 × 2K, or 1 × 4K camera. Expand storage via the microSD slot.
Does it need a subscription?
No. It runs Network, Protect, Access, Talk and Connect locally on UniFi OS with no monthly fees (optional CyberSecure adds the IDS/IPS signature set).
How many cameras and devices can it handle?
30+ UniFi devices and 300+ clients, plus a small camera load (5 HD / 2 2K / 1 4K). For larger camera systems, use a dedicated UNVR.
Can it power cameras directly?
It has one PoE output port with a 15.4 W budget — enough for a single camera or AP. Add a UniFi PoE switch to power more devices.
What internet speeds does it support?
A 10G SFP+ WAN plus a 2.5 GbE WAN, with up to 2.3 Gbps of IDS/IPS throughput and multi-WAN load balancing/failover.
Is the UDR7 NDAA compliant?
Yes. Ubiquiti is a US-based manufacturer and the UDR7 is NDAA Section 889 compliant.
