HIKVISION DS-PDP15P-EG2-WB 15m Wireless PIR Detector

Description

HIKVISION AX PRO SERIES

Advanced Interior Motion Security with Zero False Alarms

The DS-PDP15P-EG2-WB(B) is a fully supervised, two-way wireless PIR detector designed for seamless integration into Hikvision AX PRO alarm systems. Delivering high-precision detection across a 15-metre range with an 85.9° field of view, this interior sensor utilizes Smart Environmental Control (SEC) and 3D sealed optics to eliminate false triggers caused by pets, drafts, or temperature shifts. Built for residential and commercial security deployments, it ensures immediate intrusion detection while maintaining multi-year maintenance-free operation.

Detection Coverage
15m / 85.9° Wide Angle
Pet Immunity
Up to 30 kg
Wireless Protocol
Tri-X 433 MHz / 1.2km
Battery Lifespan
Up to 5 Years (1x CR123A)

Enterprise Tri-X Wireless Architecture & Smart Analytics

Powered by Hikvision's proprietary Tri-X wireless communication, the DS-PDP15P-EG2-WB(B) PIR detector transmits data securely over a 433 MHz frequency with AES-128 encryption and dynamic frequency hopping to prevent signal jamming. Featuring 52 detection zones and full remote configuration via the Hik-Connect application, security teams and homeowners can adjust sensor sensitivity, perform signal strength testing, and manage firmware updates wirelessly without unmounting the physical device.

Smart Environmental Control (SEC)

Integrates 3D sealed optics and digital signal processing to filter out non-human motion, minimizing false alarms caused by temperature fluctuations or pets up to 30 kg.

Anti-Sabotage & Tamper Protection

Includes front and rear tamper switches that immediately notify the central monitoring station or mobile app if the housing is opened or forcibly detached from the wall.

Technical Specification Matrix
Camera / Detector Model DS-PDP15P-EG2-WB(B)
Detection Method Passive Infrared (PIR)
Detection Range & Angle 15 metres / 85.9° coverage angle
Pet Immunity Limit Up to 30 kg
Wireless Frequency & Range 433 MHz Tri-X Wireless (1.2 km open space)
Wireless Security AES-128 Encryption & Frequency Hopping
Battery Type & Lifespan 1x CR123A 3V Battery (Up to 5 Years Standby)
Operating Temperature -10°C to 55°C (14°F to 131°F)
Mounting Height & Scenarios 1.8m to 2.4m wall mounting / Indoor
How does the pet immunity feature work on the DS-PDP15P-EG2-WB(B)?

The detector uses Smart Environmental Control (SEC) combined with 3D optics to evaluate shape and motion signature, effectively ignoring pets weighing up to 30 kg while triggering instantly for human movement.

How long does the battery last and is it user-replaceable?

The unit operates on a standard CR123A 3V lithium battery, providing up to 5 years of operation under typical standby conditions. The battery compartment is PCB-protected for quick and easy replacement.

How do I connect this PIR detector to my AX PRO control panel?

Enrollment is simple and flexible—you can pair it via the Hik-Connect mobile application by scanning the QR code, using remote ID enrollment, or simply powering up the device near the hub.

Is the wireless communication secured against intrusion attempt or jamming?

Yes, the detector communicates via Tri-X wireless protocol using multi-channel frequency hopping and AES-128 bit encryption to prevent radio interference or signal manipulation.

Technical Datasheet Quick Start Guide
Installation Manual
Official HIKVISION Stock
Commercial Warranty
Aust-Wide Delivery

HIKVISION DS-PDP15P-EG2-WB 15m Wireless PIR Detector

Product form

SKU: DS-PDP15P-EG2-WB-B

$80.00  $68.00 Incl. GST

    • PayPal
    • Apple Pay
    • Visa
    • Mastercard
    • American Express
    • Zip
    • Afterpay

    • Warranty: 24 months
    • 30 day Money Back Guarantee
    • Australian Stocks & Express Delivery
    • Back-to-base Warranty & Tech Support
    • FREE Shipping over $180
    3.0
    Rated 3.0 out of 5 stars
    Based on 1 review
    Total 5 star reviews: 0 Total 4 star reviews: 0 Total 3 star reviews: 1 Total 2 star reviews: 0 Total 1 star reviews: 0
    0%would recommend this product
    Write a Review (Opens in a new window)
    1 review
    • Rated 3 out of 5 stars
      10 months ago
      Hikvision ax pro sensor

      It is just avarage, it is not very sensitive

      TT
      Tam T.
      Verified Buyer
      Was this helpful?

    Description

    HIKVISION AX PRO SERIES

    Advanced Interior Motion Security with Zero False Alarms

    The DS-PDP15P-EG2-WB(B) is a fully supervised, two-way wireless PIR detector designed for seamless integration into Hikvision AX PRO alarm systems. Delivering high-precision detection across a 15-metre range with an 85.9° field of view, this interior sensor utilizes Smart Environmental Control (SEC) and 3D sealed optics to eliminate false triggers caused by pets, drafts, or temperature shifts. Built for residential and commercial security deployments, it ensures immediate intrusion detection while maintaining multi-year maintenance-free operation.

    Detection Coverage
    15m / 85.9° Wide Angle
    Pet Immunity
    Up to 30 kg
    Wireless Protocol
    Tri-X 433 MHz / 1.2km
    Battery Lifespan
    Up to 5 Years (1x CR123A)

    Enterprise Tri-X Wireless Architecture & Smart Analytics

    Powered by Hikvision's proprietary Tri-X wireless communication, the DS-PDP15P-EG2-WB(B) PIR detector transmits data securely over a 433 MHz frequency with AES-128 encryption and dynamic frequency hopping to prevent signal jamming. Featuring 52 detection zones and full remote configuration via the Hik-Connect application, security teams and homeowners can adjust sensor sensitivity, perform signal strength testing, and manage firmware updates wirelessly without unmounting the physical device.

    Smart Environmental Control (SEC)

    Integrates 3D sealed optics and digital signal processing to filter out non-human motion, minimizing false alarms caused by temperature fluctuations or pets up to 30 kg.

    Anti-Sabotage & Tamper Protection

    Includes front and rear tamper switches that immediately notify the central monitoring station or mobile app if the housing is opened or forcibly detached from the wall.

    Technical Specification Matrix
    Camera / Detector Model DS-PDP15P-EG2-WB(B)
    Detection Method Passive Infrared (PIR)
    Detection Range & Angle 15 metres / 85.9° coverage angle
    Pet Immunity Limit Up to 30 kg
    Wireless Frequency & Range 433 MHz Tri-X Wireless (1.2 km open space)
    Wireless Security AES-128 Encryption & Frequency Hopping
    Battery Type & Lifespan 1x CR123A 3V Battery (Up to 5 Years Standby)
    Operating Temperature -10°C to 55°C (14°F to 131°F)
    Mounting Height & Scenarios 1.8m to 2.4m wall mounting / Indoor
    How does the pet immunity feature work on the DS-PDP15P-EG2-WB(B)?

    The detector uses Smart Environmental Control (SEC) combined with 3D optics to evaluate shape and motion signature, effectively ignoring pets weighing up to 30 kg while triggering instantly for human movement.

    How long does the battery last and is it user-replaceable?

    The unit operates on a standard CR123A 3V lithium battery, providing up to 5 years of operation under typical standby conditions. The battery compartment is PCB-protected for quick and easy replacement.

    How do I connect this PIR detector to my AX PRO control panel?

    Enrollment is simple and flexible—you can pair it via the Hik-Connect mobile application by scanning the QR code, using remote ID enrollment, or simply powering up the device near the hub.

    Is the wireless communication secured against intrusion attempt or jamming?

    Yes, the detector communicates via Tri-X wireless protocol using multi-channel frequency hopping and AES-128 bit encryption to prevent radio interference or signal manipulation.

    Technical Datasheet Quick Start Guide
    Installation Manual
