WizMind 8 · 4 × 2 MP · 180° Panoramic Dome · IK10Dahua DH-IPC-PDBW8802P-H-A180-E4-AC24V — 4 × 2 MP Multi-Sensor 180° Panoramic IR Dome WizMind Network Camera (8802 Series)
The Dahua DH-IPC-PDBW8802P-H-A180-E4-AC24V is a flagship WizMind 8 multi-sensor panoramic dome — the dome form factor of the 8802 series, with four 1/2.8" 2 MP CMOS sensors spliced into a seamless 180° horizontal field of view for 8 MP of total panoramic detail across the hemisphere. Discreet ceiling/soffit-friendly chassis — ideal for transport platforms, retail interiors, building lobbies, undercover canopies and council reserves where a visible bullet would clash with architecture. Each sensor pairs Starlight low-light with the full WizMind 8 AI suite (face detection, perimeter protection, people counting, heat mapping); 30 m IR illumination across the panoramic field; IP67 sealed; IK10 vandal-rated metal housing; TVS 6000 V lightning protection. Power is 24 VAC or PoE+ (IEEE 802.3at) at ≤ 25.5 W. Operating range −40 °C to +60 °C. Backed by a 5-year Australian warranty through CCTV Guru as authorised Dahua AU reseller. SKU 8802 series.
Why Choose the Dahua PDBW8802P WizMind Panoramic Dome
True 180° Splice from a Discreet Dome
Four 2 MP CMOS sensors splice into a continuous 180° panoramic image — from a low-profile dome chassis that mounts cleanly under undercover canopies, soffits and architectural ceilings where a bullet would be too visible.
WizMind 8 Edge AI Suite
Face detection, perimeter protection, people counting, heat mapping and stereo analysis run on the dedicated WizMind AI chip — the premium-tier Dahua AI platform.
IK10 Vandal-Rated Dome
Metal housing with IK10 impact rating + TVS 6000 V lightning, surge and voltage-transient protection. Built for transport platforms, schools, retail interiors and shopping-centre carparks where vandalism risk is real.
Built for Harsh Climates
−40 °C to +60 °C operating range. Built-in heater pre-warms the optics in cold conditions. Suitable for Alpine, mountain, desert and tropical Australian deployments.
30 m Panoramic IR
Built-in IR array delivers up to 30 m of even night-time illumination across the entire 180° panoramic field — designed for even coverage rather than spot range.
Flexible Power — 24 VAC or PoE+
Runs on either 24 V AC mains or 802.3at PoE+. Maximum 25.5 W under full load — within standard PoE+ switch budgets.
Important Install Note — PoE+ or 24 VAC Required
This camera requires 802.3at PoE+ (Class 4) or 24 V AC supply — standard 802.3af will not run it. Multi-sensor processing draws up to 25.5 W under full load. The dome housing is heavy (~3.5 kg) and requires a heavy-duty ceiling mount — see compatible accessories below.
AI & Smart Detection Capabilities
Face Detection & Attribute Extraction
Each sensor runs face detection with attribute extraction. Captures forensic-grade snapshots from busy 180° scenes. Subject to local privacy law for analytics use.
Perimeter Protection (IVS)
Tripwire, intrusion, abandoned/missing object, loitering, fast-moving, parking detection and people-gathering events — all with human and vehicle classification.
People Counting & Heat Mapping
Business intelligence built into the camera — track footfall, dwell time and movement patterns. Useful for retail, transport and educational facilities.
SMD Plus & Motion Filtering
Smart Motion Detection filters out animal, foliage, weather and lighting changes — only people and vehicles raise alarms in DMSS.
Abnormality Detection
SD card status, network disconnection, IP conflict, video tampering, audio detection and voltage detection — push to DMSS for any abnormal device state.
ONVIF Profile S, G, T Compatible
Records to any ONVIF-compatible third-party NVR. WizMind AI events push end-to-end only on a genuine Dahua AI NVR.
Technical Specifications
Multi-Sensor Camera System
| Model |
DH-IPC-PDBW8802P-H-A180-E4-AC24V |
| Form Factor |
Multi-sensor panoramic dome (PDBW chassis) |
| Sensors |
4 × 1/2.8" CMOS Starlight |
| Resolution per Sensor |
2 MP (1920 × 1080) |
| Total Resolution |
8 MP across 180° splice |
| Field of View |
H: 180° (splice across 4 sensors) |
| Frame Rate |
Up to 25/30 fps per sensor |
| WDR |
120 dB per sensor |
| Day / Night |
Auto (ICR) / Colour / B&W |
| IR Illumination |
Up to 30 m built-in array |
Intelligence & Video
| AI Engine |
WizMind 8 Series (dedicated AI chip) |
| IVS Library |
Tripwire · intrusion · abandoned/missing object · loitering · fast-moving · parking detection · people gathering |
| Face Detection |
Per sensor — with attribute extraction |
| People Counting / Heat Map |
Yes (panoramic analytics) |
| SMD Plus |
Yes |
| Video Compression |
H.265 · H.264 · Smart H.265+ · Smart H.264+ · MJPEG |
| Resolutions |
2 MP · 1080p · 1.3 MP · 720p · D1 · VGA · CIF per sensor |
Power, Environment & Build
| Power Supply |
24 VAC / PoE+ (IEEE 802.3at Class 4) |
| Power Consumption |
Max 25.5 W under full load |
| Operating Temperature |
−40 °C to +60 °C |
| Operating Humidity |
≤ 95% RH (non-condensing) |
| Protection |
IP67 · IK10 vandal · TVS 6000 V lightning · surge protection · voltage transient protection |
| Casing |
Metal |
| Network |
RJ-45 (10/100/1000 Base-T) · ONVIF Profile S, G, T · CGI · SDK |
| Storage |
Micro SD up to 256 GB · FTP · SFTP · NAS |
| Mobile Client |
DMSS (iOS / Android) |
| Certifications |
CE-LVD (EN62368-1) · CE-EMC (2014/30/EU) · RCM (AU) |
| Australian Warranty |
5 Years (via CCTV Guru — WizMind tier) |
How It Compares — PDBW8802P (Dome) vs PFW8802P (Bullet)
The natural sibling is the Dahua DH-IPC-PFW8802P-H-A180-E4-AC24V — the bullet version of this same camera. Choose the dome (this camera) for discreet ceiling installs and IK10 vandal resistance in interior environments; choose the bullet for outdoor mounting flexibility and longer 35 m IR reach.
| Feature |
PDBW8802P (this — dome) |
PFW8802P (sibling — bullet) |
| Form Factor |
Dome — discreet ceiling/soffit |
Bullet — visible deterrence |
| Sensors |
4 × 2 MP |
4 × 2 MP |
| Total Resolution |
8 MP across 180° |
8 MP across 180° |
| IR Distance |
Up to 30 m |
Up to 35 m |
| WizMind AI |
Yes — full suite |
Yes — full suite |
| IK10 Vandal |
Yes |
Yes |
| Power |
24 VAC / PoE+ 25.5 W |
24 VAC / PoE+ 25.5 W |
| Best For |
Building lobbies, undercover canopies, transport platforms, retail interiors |
Long fence-lines, building façades, carpark frontages, large open courtyards |
Recommended NVR Pairings
Dahua DHI-NVR5216-16P-AI/ANZ
5-Series AcuPick NVR · 16 channels · 16 PoE+ ports. Runs the PDBW8802P plus 12 fixed cameras.
View Dahua NVR5216-16P-AI →
Dahua DHI-NVR5432-AI/ANZ
5-Series AcuPick NVR · 32 channels · 4 HDD bays. Enterprise pairing for multiple PDBW8802 deployments.
View Dahua NVR5432-AI →
Dahua DHI-NVR5208-8P-AI/ANZ
5-Series AcuPick NVR · 8 channels · 8 PoE+ ports. Single-camera site sizing.
View Dahua NVR5208-8P-AI →
Frequently Asked Questions
Is the Dahua PDBW8802P-H-A180-E4-AC24V NDAA compliant?
No. Dahua is not certified under NDAA Section 889.
What does "multi-sensor panoramic" mean?
The camera contains four independent 2 MP sensors arranged to capture a continuous 180° horizontal field of view, spliced in-camera into a seamless panoramic stream.
How many NVR channels does it use?
Four. Each sensor presents as a separate IP video stream.
Does it require PoE+ or will standard PoE work?
PoE+ (802.3at Class 4) is required, or a local 24 V AC supply. Standard 802.3af will not run it under full load.
How is the warranty 5 years rather than 3?
WizMind series products carry a 5-year Australian warranty through CCTV Guru — reflecting their premium project-grade build.
What IR distance does it provide?
Up to 30 m built-in IR across the entire 180° panoramic field.
What's the difference between the dome and bullet versions?
Same sensors, AI and resolution. The dome (this) suits ceiling/soffit installs and interior environments; the bullet (PFW8802P) suits outdoor mounting and visible-deterrence positions, with 5 m longer IR reach.
Does it work with third-party NVRs?
Yes — ONVIF Profile S, G and T. WizMind AI events push end-to-end only on a genuine Dahua AI NVR.
What temperature range is it rated for?
−40 °C to +60 °C. Built-in heater pre-warms the optics in cold conditions.
Can I view it on my phone?
Yes — Dahua's free DMSS app. Each sensor viewable as a separate stream within the app.
