Dahua Waterproof Wall Mount Bracket White The Dahua Waterproof Wall Mount Bracket White DH-PFB205W-E is crafted from durable aluminum alloy, offering a cost-effective and sturdy solution for mounting specific Dahua cameras. Its sleek, white design complements any installation environment while providing reliable protection against the elements. Measuring 161.6 mm x 125.6 mm x 76.0 mm, this bracket ensures a secure and precise fit, enhancing both the functionality and aesthetics of your surveillance setup. Ideal for professional installations requiring both durability and style. Features Aluminium alloy material, cost-effective Dedicated for particular cameras, beautiful and elegant designed Specifications CAMERA BRACKETS TYPE Wall Mount Bracket MATERIAL Aluminum COLOUR White DIMENSION 161.6 mmx125.6 mmx76.0 mm (6.36''x4.94''x2.99'') Downloads DH-PFB205W_datasheet

Read more less

Dahua DH-PFB204W Waterproof Wall Mount Bracket for CCTV Cameras The Dahua DH-PFB204W is a durable waterproof wall mount bracket designed specifically for CCTV cameras. Crafted from high-quality aluminum and SECC materials, it ensures robust support and long-lasting performance. Its sleek white finish and compact dimensions (160mm x 122mm x 76mm) provide an unobtrusive, professional installation. Ideal for secure outdoor mounting, this bracket combines aesthetic design with reliable protection against the elements, making it a trusted choice for expert surveillance setups. Features Aesthetic design Wall mount bracket Material: aluminum & SECC Specifications Dahua Security Camera Bracket TYPE Wall Mount Bracket MATERIAL Aluminum & SECC COLOUR White DIMENSION 160mmx122mmx76mm (6.30''x4.80''x2.99'') Downloads DH-PFB204W Datasheet

Read more less

The Dahua PFA137 is an essential accessory for any professional security installation. This waterproof junction box provides a secure, weatherproof enclosure for camera pigtails and connectors, ensuring long-term reliability by preventing water ingress and cable corrosion. Now available in both Classic White and Midnight Black to perfectly match your camera housing and building aesthetics. Key Performance Features Rugged Construction: Built from high-quality aluminum alloy, providing excellent structural strength and durability. IP66 Waterproof Rating: Engineered for harsh outdoor environments, keeping your electrical connections bone-dry in heavy rain and dust. Seamless Integration: Designed specifically for Dahua dome and turret cameras, ensuring a perfect physical fit and easy alignment. Color Options: Choose White for standard residential installs or Black (PFA137-B) for modern architectural finishes or dark soffits. Technical Specifications Model DH-PFA137 (White) / DH-PFA137-B (Black) Material Aluminum Alloy Dimensions Φ122.0mm x 34.0mm (4.80” x 1.34”) Pipe Thread G1/2" Load Bearing 1.0kg (2.2lb) Ingress Protection IP66 Rated Operating Temp. -40ºC to +60ºC Why Use a PFA137 Junction Box? Cable Protection: Protects your RJ45 and power connectors from tampering and environmental damage. Clean Aesthetics: Hides messy cables behind the camera for a tidy, professional look. Serviceability: Provides a convenient access point for future maintenance without needing to re-run cables. Downloads DH-PFA137_datasheet Installation Tip: For high-exposure outdoor areas, we recommend using the included waterproof gasket and applying a small amount of silicone sealant to the screw holes for maximum protection.

Read more less

Dahua Waterproof Junction Box White Neat & Integrated design Material: Aluminum IP66 junction box Specifications CAMERA BRACKETS TYPE Water-proof Junction Box MATERIAL Aluminum COLOUR White DIMENSION 124mmx41mm(4.88''x1.61'') Downloads DH-PFA130-E_datasheet

Read more less

Dahua Genuine Accessory Dahua DH-PFA139 — Waterproof Junction Box for CCTV Turret Cameras A clean, professional CCTV installation starts with the right accessories. The Dahua DH-PFA139 is a purpose-built waterproof junction box designed to conceal and protect cable entry points behind turret and eyeball cameras. Crafted from durable aluminium with an aesthetic low-profile design, it keeps your installation looking sharp while shielding wiring from moisture, dust, and UV exposure — indoors or out. Protection Waterproof Material Aluminium Dimensions 108 × 28.5 mm Colours White & Black Why Use the Dahua DH-PFA139 Junction Box? Weatherproof Cable Protection Seals the cable entry point behind your camera, preventing water ingress, dust, and insects from reaching your wiring — essential for any outdoor installation. Aesthetic Low-Profile Design The slim, flush-mount profile blends seamlessly with your camera and wall surface, giving installations a clean, professional finish that clients notice. Durable Aluminium Construction Aluminium resists corrosion, UV degradation, and physical impact — outlasting plastic alternatives in harsh Australian outdoor environments. Genuine Dahua Compatibility Engineered specifically for Dahua turret and eyeball cameras. Ensures a perfect fit with no gaps, no improvised adapters, and no compromised weatherproofing. Available in White & Black Choose White (DH-AC-PFA139) to match light-coloured soffits and walls, or Black (DH-AC-PFA139-B) for dark surfaces, feature walls, and discreet installations. Easy Wall or Ceiling Mount Compact 108 × 28.5 mm footprint mounts directly to standard wall or ceiling surfaces. Straightforward installation saves time on every job. Technical Specifications Model DH-PFA139 / DH-AC-PFA139 Type Waterproof Junction Box Material Aluminium Dimensions 108.0 × 28.5 mm (4.25" × 1.12") Available Colours White (DH-AC-PFA139) / Black (DH-AC-PFA139-B) Mounting Wall or ceiling surface mount Compatibility Dahua turret / eyeball cameras SKU – White DH-AC-PFA139 SKU – Black DH-AC-PFA139-B Frequently Asked Questions Which Dahua cameras is this compatible with? The DH-PFA139 is designed for Dahua turret (eyeball) cameras. It fits the standard Dahua camera base footprint — check your camera's datasheet to confirm compatibility. Is it suitable for outdoor use? Yes. The aluminium construction and waterproof design make it ideal for outdoor installations, protecting cable entry points from rain, moisture, and dust. What is the difference between White and Black versions? They are identical in function and dimensions — only the colour differs. White (DH-AC-PFA139) suits light walls and soffits; Black (DH-AC-PFA139-B) suits dark surfaces and discreet installs. Do I need this junction box for every camera? It's not mandatory, but strongly recommended for any outdoor camera or anywhere cable entry needs to be weatherproofed and neatly concealed for a professional result. Downloads Download Datasheet Fast AU Shipping Genuine Dahua Stock Expert AU Support

Read more less

Dahua Waterproof Wall Mount Bracket Black Aesthetic design Wall mount bracket Material: aluminum & SECC Specifications CAMERA BRACKETS TYPE Wall Mount Bracket MATERIAL Aluminum & SECC COLOUR Black DIMENSION 160mmx122mmx76mm (6.30''x4.80''x2.99'') Downloads DH-PFB204W_datasheet

Read more less

Dahua Horizontally Inclined Bracket for VTO1000J Door Station Horizontal angle 15° and supports combination (2 brackets maximum) Specifications CAMERA BRACKETS TYPE Horizontally inclined bracket MATERIAL PC + ABS COLOUR Black DIMENSION 49.63mm x 136.35mm x 16.57 mm (1.95'' x 5.37'' x 0.65'') Downloads DH-AC-VTM22A Datasheet

Read more less

Hikvision Water-proof Wall Mount Bracket, DS-1273ZJ-140 Features Aluminum alloy material with surface spray treatment The outlet hole makes the feature looks better Convenient installation coordinating with lower bowl Suitable for IPC-T561H-MU, IPC-T581H-MU, IPC-T289PH-MU/SL, IPC-T269H-MU/SL Weight: 703g Aluminum Alloy Download DatasheetQuick Start Guide

Read more less

Dahua PFB203W · Waterproof Wall Bracket · White & Black Dahua DH-AC-PFB203W Waterproof Wall Mount Bracket — White (PFB203W) & Black (PFB203W-B) The Dahua DH-AC-PFB203W is the factory waterproof wall mount bracket engineered for Dahua's dome, turret and eyeball cameras — the bracket Australian installers reach for whenever an IPC-HDW or IPC-HDBW camera needs to be wall-mounted on render, brick, weatherboard, fibre cement or Colorbond instead of soffit-mounted to a ceiling. Available in both White (DH-AC-PFB203W) and Black (DH-AC-PFB203W-B) to colour-match the camera body, the bracket is built from a single-piece aluminium & SECC steel housing with an internal cable channel, a rubber gasket entry seal and a powder-coat finish rated for Australian sun and salt-air exposure. Dimensions are 160 × 122 × 76 mm, net weight is just 0.5 kg, the assembly is load-rated to 1 kg (2.2 lb) of camera mass — comfortably covering every Dahua turret and dome in the WizSense and Lite line-ups — and the operating temperature window of −40 °C to +60 °C handles every Australian climate from a Hobart winter to a Karratha summer. Each bracket ships with three M4 machine screws, four ST4 self-tappers, four plastic anchors and a hex wrench, ready for fitment on the first ladder trip. DH-AC-PFB203W — WhiteMatches Dahua white turrets & domes (HDW3849H, HDBW3441E, HDW2231R-ZS-S2, etc.) DH-AC-PFB203W-B — BlackMatches the BLK / Black-body Dahua TiOC turrets and dark-render or Colorbond facades. Material Aluminium & SECC Steel Dimensions 160 × 122 × 76 mm Load Bearing 1 kg (2.2 lb) Protection Waterproof Cable Entry Colour Options White & Black Operating Temp −40 °C to +60 °C 3-Year Australian Warranty Fast Australia-Wide Shipping Australian Tech Support Why Choose the Dahua DH-AC-PFB203W for Your Wall-Mounted Camera Mounting a dome or turret straight onto a wall with the factory ceiling base looks rough, leaves the cable exposed, and almost always leaks water. The PFB203W is the cleaner, weather-tight answer — it lifts the camera off the wall, gives the lens an unobstructed downward view, hides the cable inside an internal channel and seals the entry hole with a rubber gasket. For Australian installers, this is the bracket that turns a quick fit-off into a job you'd be happy to photograph for your portfolio — and one that won't come back as a warranty call after the first Sydney southerly. Genuine Dahua Engineering — Not a Generic Knock-Off The mounting hole pattern matches the Dahua HDW & HDBW dome/turret base exactly. The bracket ships with the correct M4 machine screws for the camera, the correct ST4 self-tappers for the wall, and an Allen wrench — no rummaging in the van for the right thread pitch. White or Black to Match the Camera The standard White PFB203W matches every Dahua white-housing turret and dome. The Black PFB203W-B colour-matches the BLK variants of the TiOC range (e.g. HDW3849H-AS-PV-ANZ-S2 Black) and disappears against dark-render walls, charcoal Colorbond or stained timber. Internal Cable Channel & Rubber Gasket The camera tail-cable runs cleanly through the bracket arm and out the wall entry — no exposed RJ45 loop, no UV cracking, and the rubber gasket at the wall-entry hole keeps wind-driven rain out of your wall cavity. Aluminium & SECC Steel — Built for the Australian Climate The arm is cast aluminium (light, won't rust) and the base-plate is SECC galvanised steel (rigid, hard-wearing). The powder-coat finish handles UV, salt-air and the daily expansion/contraction cycle on a north-facing brick wall in Perth or Brisbane. Compact 160 × 122 × 76 mm Footprint Just over six inches deep — close enough to the wall to look discreet, far enough off the surface that the camera's IR doesn't bounce off the render at night and wash out the image. Load-Rated for the Full Dahua Dome/Turret Range 1 kg load rating covers every Dahua eyeball, turret, mini-dome and small box camera (most weigh 350–700 g). Don't use it for full-size PTZs or thermal cameras — those need a heavier bracket. Official Dahua Installation Tutorial Dahua's factory installation walk-through for the PFB203W — covers the wall-mount sequence, cable entry, gasket fitment and the three-screw camera attachment using the included wrench. Worth a 4-minute watch before the first install. White PFB203W vs Black PFB203W-B — Which Should You Choose? Mechanically and electrically, the two variants are identical — same bracket, same load rating, same screws in the box, same datasheet. The only difference is the finish colour. Use the table below to choose the right SKU for the wall and the camera you're mounting. DH-AC-PFB203W (White) vs DH-AC-PFB203W-B (Black) Feature DH-AC-PFB203W (White) DH-AC-PFB203W-B (Black) Colour / Finish White powder-coat Black powder-coat Best Matched Camera Body White Dahua HDW / HDBW turrets & domes (default colour) BLK / Black-body Dahua TiOC turrets & domes (e.g. HDW3849H-AS-PV-ANZ-S2 Black) Best Matched Wall Surface White render, light brick, painted weatherboard, fibre cement, soffit linings Dark render, charcoal Colorbond, stained timber, dark face brick, black-painted feature walls Material Aluminium & SECC galvanised steel Aluminium & SECC galvanised steel Dimensions (W × H × D) 160 × 122 × 76 mm 160 × 122 × 76 mm Net Weight 0.5 kg (1.1 lb) 0.5 kg (1.1 lb) Maximum Load 1 kg (2.2 lb) 1 kg (2.2 lb) Cable Management Internal channel · rubber gasket wall entry Internal channel · rubber gasket wall entry Operating Temperature −40 °C to +60 °C −40 °C to +60 °C Humidity < 90% RH < 90% RH Hardware Included 3 × M4 machine screws · 4 × ST4 self-tappers · 4 × plastic anchors · 1 × hex wrench 3 × M4 machine screws · 4 × ST4 self-tappers · 4 × plastic anchors · 1 × hex wrench Compatible Cameras Same list — see compatibility section below Same list — see compatibility section below Best For Default choice for the bulk of installs — white camera on light-coloured wall. Premium aesthetic install — keeps the dark camera and the dark wall as one visual element rather than a white "patch" floating on the façade. Installer tip: always pair the bracket colour to the camera body, not the wall. A white camera in a black bracket on a dark wall reads as visually broken; a black camera in a black bracket on the same wall disappears. The wall colour drives the camera choice; the camera colour drives the bracket choice. Compatible Dahua Cameras The PFB203W is the official wall-mount accessory for the bulk of Dahua's eyeball turret, mini-dome (HDBW), and selected compact box camera ranges sold in Australia. The list below is drawn directly from the Dahua Camera Accessories Selection guide; if your camera isn't shown but appears as an HDW/HDBW model with a circular base ~122 mm diameter, it's almost certainly supported. (If in doubt, message our Australian team with the model number — we'll confirm before you order.) Dahua PFB203W · Camera Compatibility (Australian Market Models) TiOC 3.0 Turrets (Active Deterrence) DH-IPC-HDW3849H-AS-PV-ANZ-S2 (8MP) · DH-IPC-HDW3649H-AS-PV-ANZ-S2 (6MP) · DH-IPC-HDW3549H-AS-PV (5MP) · DH-IPC-HDW3449H-AS-PV (4MP) · DH-IPC-HDW3249H-AS-PV (2MP) · DH-IPC-HDW3849H-AS-PV-PRO-ANZ (TiOC PRO 8MP) · DH-IPC-HDW3649H-AS-PV-PRO-ANZ (TiOC PRO 6MP) WizSense Motorised-Zoom Turrets DH-IPC-HDW3849H-ZAS-PV-ANZ-S2 · DH-IPC-HDW3649H-ZAS-PV-ANZ-S2 · DH-IPC-HDW3841T-ZAS · DH-IPC-HDW3441T-ZAS · DH-IPC-HDW3541T-ZAS · DH-IPC-HDW3241T-ZAS WizSense Fixed-Lens Turrets DH-IPC-HDW3841TM-AS · DH-IPC-HDW3441TM-AS · DH-IPC-HDW3541TM-AS · DH-IPC-HDW3241TM-AS · DH-IPC-HDW3849TM-AS-LED · DH-IPC-HDW3549TM-AS-LED · DH-IPC-HDW3449TM-AS-LED · DH-IPC-HDW3249TM-AS-NI · DH-IPC-HDW3449TM-AS-NI Lite 2-Series Turrets DH-IPC-HDW2831T-AS-S2 · DH-IPC-HDW2531T-AS-S2 · DH-IPC-HDW2431T-AS-S2 · DH-IPC-HDW2231T-AS-S2 · DH-IPC-HDW2439T-AS-LED-S2 · DH-IPC-HDW2239T-AS-LED-S2 · DH-IPC-HDW2831R-ZS-S2 · DH-IPC-HDW2531R-ZS-S2 5-Series Pro AI Turrets DH-IPC-HDW5541T-ZE · DH-IPC-HDW5241T-ZE · DH-IPC-HDW5442T-ZE · DH-IPC-HDW5541H-ASE-PV · DH-IPC-HDW5241H-ASE-PV · DH-IPC-HDW5842T-ZE-S2 · DH-IPC-HDW5242T-ZE-MF · DH-IPC-HDW5449H-ASE-D2 WizSense Mini-Domes (HDBW Eyeball-Style) DH-IPC-HDBW3841E-AS · DH-IPC-HDBW3441E-AS · DH-IPC-HDBW3541E-AS · DH-IPC-HDBW3241E-AS · DH-IPC-HDBW3449E-AS-NI · DH-IPC-HDBW3249E-AS-NI · DH-IPC-HDBW3841R-ZAS · DH-IPC-HDBW3441R-ZAS · DH-IPC-HDBW3541R-ZAS · DH-IPC-HDBW3241R-ZAS Lite 2-Series Mini-Domes DH-IPC-HDBW2831E-S-S2 · DH-IPC-HDBW2531E-S-S2 · DH-IPC-HDBW2431E-S-S2 · DH-IPC-HDBW2231E-S-S2 · DH-IPC-HDBW2231R-ZS-S2 · DH-IPC-HDBW2431R-ZS-S2 · DH-IPC-HDBW2531R-ZS-S2 · DH-IPC-HDBW2831R-ZS-S2 Cooper / Entry-Level Mini-Domes DH-IPC-HDBW1531E-S · DH-IPC-HDBW1431E-S · DH-IPC-HDBW1230E · DH-IPC-HDBW1420E · DH-IPC-HDBW1120E · DH-IPC-HDBW1531E · DH-IPC-HDBW1431E · DH-IPC-HDBW1230E-W (Wi-Fi) 5-Series Pro AI Mini-Domes DH-IPC-HDBW5541R-ASE · DH-IPC-HDBW5241R-ASE · DH-IPC-HDBW5442R-ASE · DH-IPC-HDBW5441R-ASE · DH-IPC-HDBW5842R-ASE-S2 · DH-IPC-HDBW5242R-ASE-MF · DH-IPC-HDBW5449R-ASE-LED HDCVI Turret Cameras HAC-HDW2802T-A-I8 · HAC-HDW2249T-A-LED · HAC-HDW2241T-A · HAC-HDW1500T-A · HAC-HDW1239T-A-LED · HAC-HDW1209T-A-LED · HAC-HDW2402T-A · HAC-HDW2801T-A · HAC-HDW1500EM-A HDCVI Mini-Domes HAC-HDBW2802R · HAC-HDBW2402R · HAC-HDBW2241R-Z · HAC-HDBW2231R-Z · HAC-HDBW1500R · HAC-HDBW1400R · HAC-HDBW1230R · HAC-HDBW1209R · HAC-HDBW1100R Compact Box / Cube Cameras DH-IPC-EB5541-AS · DH-IPC-EBW81242-AS-S2 (panoramic 12MP fisheye) · IPC-HDB4231C-AS · IPC-HDB4431C-AS NOT Compatible — use a different bracket Dahua bullet cameras (HFW series — use PFA152-E pole / PFA130-E junction) · Full-size PTZ cameras · Thermal cameras · Cameras over 1 kg load · Camera bases over 122 mm diameter Need a quick decision? If you're mounting an eyeball turret or a mini-dome on a vertical wall (not a soffit), and the camera weighs under 1 kg with a circular base around 110–122 mm, the PFB203W is the correct bracket. Pair the colour to the camera body, not the wall. Technical Specifications DH-AC-PFB203W · Full Specifications (White & Black) Model — White DH-AC-PFB203W Model — Black DH-AC-PFB203W-B Product Type Waterproof wall mount bracket for dome & turret cameras Material Aluminium body & SECC galvanised-steel base plate Finish — White Powder-coat · Dahua RAL White Finish — Black Powder-coat · Dahua RAL Black Dimensions (W × H × D) 160 × 122 × 76 mm (6.30 × 4.80 × 2.99 in) Net Weight 0.5 kg (1.1 lb) Maximum Load Bearing 1 kg (2.2 lb) Cable Management Internal cable channel with rubber gasket wall-entry seal Mounting Pattern Dahua HDW / HDBW circular base (3 × M4 machine screws) Operating Temperature −40 °C to +60 °C Humidity < 90% RH (non-condensing) Package Contents 1 × Wall-mount bracket · 3 × M4 machine screws · 4 × ST4 self-tappers · 4 × plastic anchors · 1 × hex wrench · installation sheet Compatible Camera Bases Most Dahua IPC-HDW (turret) · IPC-HDBW (mini-dome) · HAC-HDW · HAC-HDBW · selected IPC-EB / EBW box cameras (see compatibility table) Applicable Walls Brick · render · weatherboard · fibre cement · Colorbond · plasterboard (with appropriate fixings) Country of Origin China · Genuine Dahua factory accessory Australian Warranty 3-Year Australian Warranty (back-to-base) Installation Overview — From Box to Powered Up The PFB203W is one of the fastest brackets in the Dahua catalogue to fit — most installers have it on the wall and the camera powered up inside 10 minutes. The high-level sequence is below; the official video at the top of this page walks the exact procedure. 1. Mark & Drill the Wall Pattern Use the bracket's base-plate as the drilling template. Three or four ST4 self-tappers (supplied) into plastic anchors (also supplied) hold it on render, brick or fibre cement. For Colorbond or timber, drive the self-tappers direct into the substrate — no anchor needed. 2. Run the Cable Through the Arm Push the camera tail (RJ45 head + power if used) up through the bracket arm before bolting the base-plate to the wall — easier than threading after. The rubber gasket seats around the cable as it enters the wall hole, keeping wind-driven rain out of the cavity. 3. Bolt the Bracket to the Wall Tighten the four ST4 screws. Test the bracket is rigid before mounting the camera — a flex now means a flex with a camera on it. 4. Attach the Camera with 3 × M4 Screws Line up the camera's circular base on the bracket head, drive the three M4 machine screws (supplied) with the included hex wrench. The wrench is small — clip it to your tool tray, it's the only tool that fits the recess. 5. Plug In & Power Up Connect the RJ45 to the PoE switch or injector, the camera boots inside 30 seconds. Aim the gimbal with the camera live (using your phone or test monitor) before locking the bracket head. 6. Final Aesthetic Pass Silicone-bead the perimeter of the base-plate against the wall on outdoor installs — it's belt-and-braces over the gasket and gives a clean, water-tight finish that survives the next 10 years of weather. Frequently Asked Questions Is the PFB203W actually waterproof, and to what rating? The bracket itself is not assigned an IP code (it's a passive mounting accessory, not a sealed enclosure), but the cable-entry hole is fitted with a rubber gasket that seals the wall penetration against wind-driven rain — the same gasket Dahua uses on its IP66/IP67 cameras. With the gasket fitted correctly and a silicone bead around the base-plate, you have a fully water-tight outdoor install. Is the white bracket the same as the black bracket — just painted? Yes. Same casting, same load rating, same mounting pattern, same datasheet, same screw kit. The only difference is the powder-coat colour. Choose by camera body colour, not by spec. What's the maximum camera weight I can mount? 1 kg (2.2 lb). That comfortably covers every Dahua eyeball turret, every mini-dome, and most compact box cameras (350–700 g). Don't use it for PTZs, thermal cameras, or anything over 1 kg — those need a heavier bracket like the PFB220C or PFA152-E. Does this fit Dahua bullet cameras (HFW series)? No. Bullets have an integrated arm and don't use a separate wall-mount bracket — they bolt directly to the wall or to a junction box like the PFA130-E. The PFB203W is for cameras with a round base (HDW turrets, HDBW mini-domes). Will it fit a Hikvision turret or eyeball camera? Mechanically, no. The PFB203W's three-screw mounting pattern is sized for the Dahua HDW / HDBW base. Hikvision use a different bolt circle. For a Hikvision turret on a wall, use the Hikvision DS-1273ZJ-130-TRL or equivalent. Can I mount it on a fence post or pole? The PFB203W is designed for flat walls only. For pole, gutter or corner mounting, pair the PFB203W with a Dahua PFA152-E pole adapter, or use a dedicated pole-mount accessory. Will the cable be hidden, or does it run on the outside? Hidden. The arm is hollow with an internal channel — the camera tail-cable runs up through the arm and out the wall entry, with no exposed cable run. Does it ship with screws and anchors? Yes. Each PFB203W ships with 3 × M4 machine screws for the camera, 4 × ST4 self-tappers + 4 × plastic anchors for the wall, and a hex wrench for the M4 screws. You won't need anything extra unless the wall substrate calls for masonry anchors of a different size. Is it compatible with the Black BLK variants of the Dahua TiOC range? Yes — and that's exactly when you'd specify the Black PFB203W-B. The black bracket colour-matches the BLK / Black-body TiOC turrets (HDW3849H-AS-PV-ANZ-S2 Black, for example) for a seamless installed look against dark walls. Will it handle Australian sun and salt-air? Yes. The aluminium arm doesn't rust, the SECC steel base-plate is galvanised, and the powder-coat finish is UV-stable. The operating temperature is rated to +60 °C, well above any roof-mounted Australian summer day. For coastal sites (within 1 km of the surf), we still recommend an annual freshwater rinse to extend the powder-coat life — same advice we give for the camera itself. What is the warranty and where is it serviced? The bracket ships with a 3-year Australian warranty against material and finish defects, serviced back-to-base through CCTV Guru. Damage from over-tightening, drop, or installation error is excluded — standard for any mechanical accessory. Do you ship Australia-wide and is stock genuine? Yes — Australian stock from authorised Dahua Australia channels (not parallel imports). We dispatch the same business day for orders placed before 2 pm AEST to Sydney, Melbourne, Brisbane, Perth, Adelaide, Hobart, Canberra, Darwin and every regional address in between. Downloads & Resources DH-AC-PFB203W Datasheet Order the Dahua DH-AC-PFB203W from CCTV Guru CCTV Guru is an authorised Australian reseller of Dahua network cameras and genuine factory accessories. Order the PFB203W Waterproof Wall Mount Bracket today in White or Black for fast Australia-wide dispatch, real Dahua factory parts (not generic copies) and Australian-based technical support if you need help choosing between bracket variants for a multi-camera project. Buying ten or more for a commercial rollout? Request a project quote or contact our Australian team — we'll match the right bracket colour to your camera SKUs across the whole job.

Read more less

Bosch B426-M IP Ethernet Communication Module The Bosch B426-M is the essential upgrade for any modern security system. It allows your Bosch Solution 2000 or 3000 panel to communicate over the internet (NBN), enabling remote management and instant mobile alerts via the Bosch RSC+ Smartphone App. ✅ 100% Compatible With: Bosch Solution 2000 Kits Bosch Solution 3000 Kits Bosch Solution 6000 (Firmware v2.26+) Key Benefits of the B426-M: Remote Control: Arm and disarm your system from anywhere in the world using your smartphone. Live Status Updates: Check if your alarm is on or off in real-time. Push Notifications: Receive instant alerts if your alarm is triggered, providing faster response times than traditional sirens alone. NBN Ready: Replaces old-fashioned phone line monitoring which is being phased out across Australia. Simple Plug-and-Play: Connects directly to the control panel's bus and your home router via a standard Ethernet cable. Technical Specifications Connection Type 10/100 Base-T Ethernet (RJ45) Protocol Support IPv4, IPv6, HTTP, HTTPS, TCP, UDP Encryption Up to AES 256-bit Operating Voltage 12V DC (Powered by Panel) B426-M FAQ Q: Is there a monthly subscription fee for the RSC+ App? A: No. Unlike many competitors, the Bosch RSC+ app is currently free to download and use with the B426-M module. Q: Can I use Wi-Fi instead of an Ethernet cable? A: The B426-M requires a hardwired Ethernet connection. If you cannot run a cable to your router, we recommend using a Powerline Adaptor or looking at the B450-M (4G Cellular Module) instead.

Read more less

Dahua PoE Extender Passive work with PFT1200, connect up to 3x IPC Support passive PoE cascade power supply and Ethernet data exchange Support IEEE 802.3af/at standard power supply IP Camera Cooperate with High PoE Midspan PFT1200), able to cascade level 2 PoE Extender, connect to 3 IPC (total power consumption <=25W), max transmission distance 300m 1*RJ45 10/100M PoE power supply input; 1*RJ45 10/100M supply power for IP Cam; 1*RJ45 10/100M supply power for the next extender Installation mode: junction box internal mounting, DIN rail mounting Downloads PFT1300_datasheetPoE Extender_User's Manual_V1.0.3

Read more less

Hikvision Water-proof Junction Box (2366/2386/2h66/2h86/2346/2347/2387) - DS-1280ZJ-DM21 The Hikvision DS-1280ZJ-DM21 waterproof junction box is crafted from durable aluminum alloy, ensuring robust protection for your IPC-T269H-MU/SL cameras. Its compact design (137 mm × 42 mm) and lightweight build (280 g) facilitate easy installation while safeguarding connections from environmental elements. Finished in Hikvision white, this junction box combines functionality with a professional appearance, making it an essential accessory for secure and reliable surveillance setups. Features Junction Box Aluminum Alloy Hikvision White Suitable for IPC-T269H-MU/SL Weight: 280 g (0.62 lb.) Aluminum Alloy 137 mm × 42 mm (5.4" × 1.7") Download Quick Start Guide

Read more less

Dahua Corner Mount Bracket Material: SECC Corner mount bracket Aesthetic design Specifications CAMERA BRACKETS TYPE Corner Mount Bracket MATERIAL SECC COLOUR White DIMENSION 243mmx170mmx138mm (9.57''x6.69''x5.43'') Downloads DH-PFA151_datasheet

Read more less

Dahua Mount Junction Box DH-PFA134 Dahua Mount Box Features Aesthetic design Material: aluminum & SECC Junction box Specifications CAMERA BRACKETS TYPE Junction Box MATERIAL Aluminum & SECC COLOUR White DIMENSION 90.0mmx35.0mm (3.54''x1.38'') Downloads DH-PFA134_datasheet

Read more less

The Dahua PFB2203W is a professional-grade wall mount bracket designed to provide a secure and aesthetically pleasing mounting solution for Dahua dome cameras. Constructed from high-quality aluminum, this bracket is built to withstand harsh environments while ensuring your surveillance equipment remains stable and correctly positioned. Key Performance Features High-Quality Material: Manufactured from durable aluminum alloy, providing excellent structural integrity and corrosion resistance. Weatherproof Design: With an IP66 rating, this bracket is ideal for both indoor and outdoor installations, protecting connections from dust and water. Integrated Junction Box: Features a hollow center design that allows for clean cable management, hiding connectors and wires from view and protecting them from tampering. High Load Capacity: Engineered to support up to 1.0kg (2.2lb), ensuring compatibility with a wide range of Dahua mini-dome and turret cameras. Why Use the PFB2203W Bracket? Professional Finish: Provides a clean, "factory" look for residential and commercial security installations. Easy Installation: The bracket features pre-drilled holes for standard wall mounting and simple camera attachment points. Optimized Viewing: Extends the camera away from the wall to reduce reflections and provide a better angle of the monitored area. The Dahua PFB2203W wall mount bracket is highly versatile, designed primarily for dome and eyeball (turret)cameras. Based on Dahua’s technical compatibility data, it is compatible with a wide range of series. Compatible Camera Series & Models The PFB2203W is typically used for cameras with a base diameter that matches its mounting plate (approx. 122mm to 129mm). Key compatible series include: WizMind & WizSense Series: IPC-HDW5X59 Series: (e.g., IPC-HDW5859H-ZE-PV-PRO, IPC-HDW5459TM-ASE-IL) IPC-HDBW5X41 Series: (e.g., IPC-HDBW5441R-ASE) IPC-HDW3X49 Series: (e.g., IPC-HDW3849QM-S-IL TiOC models) IPC-HDBW3X41/3X49 Series: (e.g., IPC-HDBW3849E-AS-IL) IPC-HDW2X49 Series: (e.g., IPC-HDW2549T-S-IL) HDCVI (Analog) Series: HAC-HDW1249 Series: (e.g., HAC-HDW1249X-A-PRO) HAC-HDBW Series: Most standard size vandal-proof domes. Specialty Models: IPC-PDW3849-A180-AS-PV: 180° Duo Splicing cameras. How to Confirm Compatibility Because Dahua frequently updates their camera housings, the most accurate way to confirm is to check the Camera Accessory Selection guide or the specific camera's datasheet under the "Accessories" section. General Compatibility Rule: If your camera is compatible with the PFA137 or PFA130-E junction boxes, it is almost certainly compatible with the PFB2203W wall mount, as they share the same mounting hole patterns. Key Specs for Installation: Load Bearing: Supports up to 1.0 kg (2.2 lb). Material: Aluminum alloy & SGCC (provides high durability and corrosion resistance). Dimensions: 162.0 mm × 129.4 mm × 80.0 mm. Technical Specifications Feature Specification Model PFB2203W Material Aluminum Alloy Dimensions 160.0mm x 122.0mm x 76.0mm Pipe Thread G1/2" Load Bearing 1.0kg (2.2lb) Weight 0.49kg (1.08lb) Color White Operating Temp. -40ºC to +60ºC (-40ºF to +140ºF) Protection Rating IP66 Guru Tip: To ensure a fully waterproof seal for outdoor use, always use the included G1/2” pipe thread or applicable conduit and apply waterproof tape to the cable entry points.

Read more less

Hikvision Aluminum Alloy Wall Mount - DS-1273ZJ-130-TRL The Hikvision Aluminum Alloy Wall Mount DS-1273ZJ-130-TRL is designed specifically for secure dome camera installation. Crafted from durable aluminum alloy and finished in Hikvision white, this bracket includes an adaptor plate for compatibility with models IPC-T361H-MU, IPC-T381H-MU, and IPC-T289H-MU/SL. Measuring 130×182×120mm and weighing 900g, it ensures a robust and professional mounting solution for wall installations, enhancing camera stability and positioning precision. Features Wall Mount Bracket With adaptor plate Aluminum alloy Hikvision White or Black Suitable for IPC-T361H-MU, IPC-T381H-MU, IPC-T289H-MU/SL Weight: 900g Aluminum Alloy 130×182×120mm Suitable for wall mounting Wall Mounting Bracket with adaptor plate Download Quick Start Guide

Read more less

Uniarch 22-inch Wall-hanging Mounts Downloads HB-4022-A Wall-hanging Mounts V4.0

Read more less

Hikvision Water-proof Junction Box - DS-1280ZJ-DM8 The Hikvision DS-1280ZJ-DM8 Junction Box is crafted from durable aluminum alloy, ensuring robust protection and water resistance for your surveillance setup. Designed specifically for models IPC-T361H-MU, IPC-T381H-MU, and IPC-T289H-MU/SL, it offers a secure and neat installation solution. With compact dimensions of 126.7 mm by 35 mm and a lightweight build of approximately 210 grams, this junction box combines strength and convenience for professional-grade CCTV installations. Features Junction Box Aluminum Alloy Hikvision White Suitable for IPC-T361H-MU, IPC-T381H-MU, IPC-T289H-MU/SL Weight: Approx.: 210 g (0.46 lb.) Aluminum Alloy 126.7 mm × 35 mm (4.99" × 1.38") Download Quick Start Guide

Read more less

Dahua Wall Mount Bracket Neat & Integrated design Wall mount bracket Material: Aluminum Safety rope hook attached, secure and reliable Specifications CAMERA BRACKETS TYPE Wall Mount Bracket MATERIAL Aluminum COLOUR White DIMENSION 200mmx160mmx115mm (7.87''x6.3''x4.53'') Downloads DH-PFB305W Datasheet

Read more less

Dahua Wall Mount Bracket Aesthetic design Wall mount bracket Material: aluminum Specifications CAMERA BRACKETS TYPE Water-proof Wall Mount Bracket MATERIAL Aluminum COLOUR White DIMENSION 115mmx160mmx255mm (4.53''x6.3''x10.04'') Downloads DH-PFB303W Datasheet

Read more less

Dahua HDMI Extender The Dahua HDMI Extender DH-PFM700-E enables real-time transmission of HDMI video signals up to 50 meters using a single CAT6 cable, ensuring minimal delay and strong anti-interference performance. Designed for HDMI 1.3 compatibility, it supports local loop output and EDID management. The device also includes one-way infrared remote control signal transmission and offers robust protection against thunder, static, and interference without needing driver installation or network configuration. Powered by DC5V, it is optimized for reliable and straightforward HDMI extension in professional setups. Features Power supply: Input voltage DC5V, only supply for transmitter. Transmission effect: Real-time transmission HDMI video signal, no delay, strong anti-interference. Transmission distance: HDMI transmission distance 50m (max.164ft), with CAT6 of pure copper cable(DC impedance is less than 9.5 ohm for every 100 meters(328ft)). Infrared function: support to transmit one-way infrared remote control signal. Main functions: Use single UTP (CAT-5E and CAT-6) to transmit 1-ch HDMI video signal, support HDMI 1.3; Support HDMI local loop output; Support EDID. Protection and anti-interference: Excellent anti-thunder, anti-static and anti-interference capabilities. Appearance structure: No need to install driver program and set network parameters, easy to use and convenient to install. Downloads PFM700-E Datasheet_20190906

Read more less

Dahua Mount Adapter Aesthetic design Material: aluminum Mount adapter Specifications CAMERA BRACKETS TYPE Mount Adapter MATERIAL Aluminum COLOUR White DIMENSION 60mmx49mm (2.36''x1.93'') Downloads DH-PFA111_datasheet

Read more less

Steel corner mount for all PTZ cameras

Read more less

Dahua Waterproof Junction Box Aesthetic design Material: aluminum Junction box Specifications CAMERA BRACKETS TYPE Junction Box MATERIAL Aluminum COLOUR White DIMENSION 115.0mmx160.0mmx38.8mm (4.53''x6.30''x1.53'') Downloads DH-PFA120_datasheet

Read more less

Uniview UNV Junction Box TR-JB03-I-IN for IPC36XXL Series (Wall-Mount) The Uniview UNV junction box for IPC36XXL series provides a clean, secure way to mount Uniview fixed dome/turret cameras while concealing and protecting cables. Built from durable aluminum alloy with tidy rear/side cable entries, it delivers a professional finish for indoor or sheltered outdoor installations. Key Features Brand: Uniview UNV; made for IPC36XXL series (and selected UNV turrets/domes) Integrated junction box cavity for neat cable management Aluminum construction for strength and longevity Suitable for indoor or sheltered outdoor wall installations Compact profile; pre-drilled pattern for fast mounting Technical Specifications Specification Details Brand Uniview UNV Compatibility UNV IPC36XXL series (and selected fixed dome/turret models) Mount Type Wall-mount bracket with integrated junction box Material Aluminum alloy Cable Management Rear/side cable entries; internal junction cavity Environment Indoor or sheltered outdoor use Finish/Color White (UNV standard finish) Typical Use Neat wall installations under eaves, entries, and corridors What’s Included Uniview UNV junction box & wall-mount bracket Mounting hardware & quick guide Customer Requirements Compatible UNV camera (e.g., IPC36XXL series) RJ45 Cat6 network cable (if camera uses PoE) Appropriate fasteners for your wall surface Sealant/gasket where required for weather protection

Read more less

Dahua PFA136 · Waterproof Junction Box · White & Black Dahua DH-PFA136 Waterproof Junction Box — White (PFA136) & Black (PFA136-B) The Dahua DH-PFA136 is the factory waterproof junction box engineered for Dahua's eyeball turret, mini-dome and selected fisheye cameras — the back-of-camera disc Australian installers reach for whenever a cable needs to terminate cleanly behind the camera body, conceal an RJ45 join, and pass through a wall in a sealed, weather-tight finish. Available in both White (DH-PFA136) and Black (DH-PFA136-B) to colour-match the camera body, the PFA136 is a single-piece aluminium housing with an M20 (G½") water-tight cable gland, a rubber gasket, and a three-screw bolt-circle that fits the standard Dahua HDW / HDBW base. Dimensions are a compact Φ110.0 × 34.0 mm, the assembly weighs just 0.19 kg, and the load rating of 1.0 kg covers every Dahua turret and mini-dome currently sold in Australia (most weigh 350–700 g). The operating window of −40 °C to +60 °C with humidity up to 90% RH means it handles every Australian climate — Hobart winters, Brisbane summers, Karratha cyclones and Tasmanian alpine — without warping, cracking or pitting. Each box ships ready to install: three M4×10 camera screws, three ST4×25 self-tappers, three plastic anchors, one water-joint gland and the hex wrench, all included. DH-PFA136 — WhiteMatches Dahua white-housing turrets & mini-domes (HDW3849H, HDBW3441E, HDW2231R-ZS-S2, etc.) DH-PFA136-B — BlackMatches the BLK / Black-body Dahua TiOC turrets, dark render, charcoal Colorbond or stained timber facades. Material Aluminium Alloy Dimensions Φ110 × 34 mm Load Bearing 1.0 kg (2.2 lb) Cable Entry M20 (G½") Water-Tight Colour Options White & Black Operating Temp −40 °C to +60 °C 3-Year Australian Warranty Fast Australia-Wide Shipping Australian Tech Support Why Choose the Dahua DH-PFA136 for Your Eyeball or Dome Camera Mounting a turret or mini-dome straight onto a wall or soffit with the bare base looks rough, leaves the RJ45 join exposed inside the wall cavity, and almost always leaks water down the cable run during heavy rain. The PFA136 is the cleaner, weather-tight answer — it sits behind the camera as a 110 mm disc, hides the RJ45 connector and pigtail inside its sealed cavity, takes the cable in through a proper M20 gland, and lets the camera bolt onto the disc with the same three M4 screws as a direct mount. For Australian installers, it's the small accessory that turns a quick fit-off into a job that won't come back as a leak callout six months later. Genuine Dahua Engineering — Exact Bolt-Circle Fitment The three M4×10 mounting holes match the Dahua HDW eyeball turret and HDBW mini-dome base exactly. The box ships with the correct M4 screws for the camera, the correct ST4 self-tappers for the wall, plastic anchors and the hex wrench — no rummaging in the van for the right thread pitch. White or Black to Match the Camera Body The White PFA136 matches every Dahua white-housing turret and mini-dome. The Black PFA136-B colour-matches the BLK variants of the TiOC range (e.g. HDW3849H-AS-PV-ANZ-S2 Black) and disappears against dark render, charcoal Colorbond, stained timber or black-painted feature walls. M20 (G½") Water-Tight Cable Gland The supplied water-joint gland threads into the side of the box at M20, sealing the cable entry against wind-driven rain — the same gland Dahua uses on its IP66/IP67 cameras. The internal cavity gives you space to dress the RJ45 join, the power tail and any audio/alarm leads cleanly behind the camera. Single-Piece Aluminium — Built for Australian Conditions One-piece cast aluminium with a powder-coat finish — won't rust, won't crack under UV, won't warp in roof-cavity summer heat. The Australian coastal salt-air tolerance is the same as Dahua's IP67 camera housings (which use the same alloy). Compact Φ110 mm Profile Just 110 mm in diameter and 34 mm deep — the box sits flush behind the camera with almost no visible offset. From the ground, the camera looks like it's mounted directly to the wall — except now you have a proper sealed cable termination behind it. Load-Rated for the Full Dahua Turret & Dome Range 1 kg load rating covers every Dahua eyeball turret, every mini-dome and most compact fisheye cameras (350–700 g typical). Not for full-size PTZs, thermal cameras or anything over 1 kg — those need a heavier bracket like the PFB203W or PFB710W. White PFA136 vs Black PFA136-B — Which Should You Choose? Mechanically the two variants are identical — same Dahua aluminium casting, same load rating, same M20 thread, same screw kit, same datasheet. The only difference is the powder-coat finish colour. Use the table below to choose the right SKU for the camera and wall colour combination. DH-PFA136 (White) vs DH-PFA136-B (Black) Feature DH-PFA136 (White) DH-PFA136-B (Black) Colour / Finish White powder-coat Black powder-coat Best Matched Camera Body White Dahua HDW / HDBW turrets & mini-domes (default colour) BLK / Black-body Dahua TiOC turrets & mini-domes (e.g. HDW3849H-AS-PV-ANZ-S2 Black) Best Matched Surface White render, light brick, painted weatherboard, fibre cement, white soffit Dark render, charcoal Colorbond, stained timber, dark face brick, black soffit, black-painted ceiling Material Aluminium alloy Aluminium alloy Dimensions (Ø × H) Φ110.0 × 34.0 mm Φ110.0 × 34.0 mm Net Weight 0.19 kg (0.42 lb) 0.19 kg (0.42 lb) Maximum Load 1.0 kg (2.2 lb) 1.0 kg (2.2 lb) Cable Gland M20 (G½") · water-tight · rubber gasket M20 (G½") · water-tight · rubber gasket Operating Temperature −40 °C to +60 °C −40 °C to +60 °C Humidity Tolerance 0–90% RH (non-condensing) 0–90% RH (non-condensing) Hardware Included 3 × M4×10 machine screws · 3 × ST4×25 self-tappers · 3 × plastic anchors · 1 × M20 water-joint gland · 1 × hex wrench 3 × M4×10 machine screws · 3 × ST4×25 self-tappers · 3 × plastic anchors · 1 × M20 water-joint gland · 1 × hex wrench Compatible Cameras Same list — see compatibility section below Same list — see compatibility section below Best For Default choice for the bulk of installs — white camera on light-coloured wall or soffit. Premium aesthetic install — keeps the dark camera and the dark wall as one visual element rather than a white "patch" floating on the façade. Installer tip: always pair the junction-box colour to the camera body, not the wall. A white camera on a black junction box on a dark wall reads as visually broken; a black camera on a black box on the same wall disappears. The wall colour drives the camera choice; the camera colour drives the junction-box choice. PFA136 Junction Box vs PFB203W Wall-Mount Bracket — Which Do I Need? These two are the most-confused Dahua accessories. They look similar in the catalogue, fit the same cameras, and both come in White and Black — but they solve different problems. Use the PFA136 when the camera is going on a flat wall or soffit and you just need a sealed cable termination behind it. Use the PFB203W when the camera needs to angle outward from a vertical wall, like a horizontal turret mounted on an external wall looking along the driveway. PFA136 Junction Box vs PFB203W Wall-Mount Bracket Use Case PFA136 (Junction Box) PFB203W (Wall-Mount Bracket) Form Factor Flat round disc (Φ110 × 34 mm) Wall-arm bracket (160 × 122 × 76 mm) Best Mounting Surface Soffit, eave, ceiling, flat wall (camera flush) Vertical wall (camera projecting outward, horizontal aim) Camera Orientation Standard — camera looks down or straight out Side-on — camera angled along the wall surface Cable Concealment Internal cavity · M20 gland for sealed wall entry Internal cable channel through the arm Visual Footprint Minimal — looks almost like a direct mount Visible arm — adds depth and aim flexibility Typical Install Eaves looking down, front door, ceiling-mounted internal turret Driveway camera on side wall, perimeter turret on fence-line, gable end Load Rating 1.0 kg 1.0 kg Colour Options White & Black White & Black Need both? On many sites the answer is "one of each" — a PFA136 on the eave for the front-door turret, and a PFB203W on the side wall for the driveway turret. View the PFB203W combined product page → Compatible Dahua Cameras The PFA136 is the official rear-cavity junction box for the bulk of Dahua's eyeball turret and mini-dome (HDBW) range sold in Australia. The list below is drawn directly from the Dahua Camera Accessories Selection guide. If your camera isn't shown but appears as an HDW/HDBW model with a circular base ~110 mm in diameter, it's almost certainly supported. (If in doubt, message our Australian team with the model number — we'll confirm before you order.) Dahua PFA136 · Camera Compatibility (Australian Market Models) TiOC 3.0 Eyeball Turrets (Active Deterrence) DH-IPC-HDW3849H-AS-PV-ANZ-S2 (8MP) · DH-IPC-HDW3649H-AS-PV-ANZ-S2 (6MP) · DH-IPC-HDW3549H-AS-PV (5MP) · DH-IPC-HDW3449H-AS-PV (4MP) · DH-IPC-HDW3249H-AS-PV (2MP) · DH-IPC-HDW3849H-AS-PV-PRO-ANZ (TiOC PRO 8MP) · DH-IPC-HDW3649H-AS-PV-PRO-ANZ (TiOC PRO 6MP) · DH-IPC-HDW3849/3549/3449H-AS-PV-S3 WizSense Motorised-Zoom Eyeball Turrets DH-IPC-HDW3849H-ZAS-PV-ANZ-S2 · DH-IPC-HDW3649H-ZAS-PV-ANZ-S2 · DH-IPC-HDW3841T-ZAS · DH-IPC-HDW3441T-ZAS · DH-IPC-HDW3541T-ZAS · DH-IPC-HDW3241T-ZAS WizSense Fixed-Lens Eyeball Turrets DH-IPC-HDW3841TM-AS · DH-IPC-HDW3441TM-AS · DH-IPC-HDW3541TM-AS · DH-IPC-HDW3241TM-AS · DH-IPC-HDW3849TM-AS-LED · DH-IPC-HDW3549TM-AS-LED · DH-IPC-HDW3449TM-AS-LED · DH-IPC-HDW3249TM-AS-NI · DH-IPC-HDW3449TM-AS-NI Lite 2-Series Eyeball Turrets DH-IPC-HDW2831T-AS-S2 · DH-IPC-HDW2531T-AS-S2 · DH-IPC-HDW2431T-AS-S2 · DH-IPC-HDW2231T-AS-S2 · DH-IPC-HDW2439T-AS-LED-S2 · DH-IPC-HDW2239T-AS-LED-S2 · DH-IPC-HDW2831R-ZS-S2 · DH-IPC-HDW2531R-ZS-S2 · DH-IPC-HDW2431R-ZS-S2 · DH-IPC-HDW2231R-ZS-S2 5-Series Pro AI Eyeball Turrets DH-IPC-HDW5541T-ZE · DH-IPC-HDW5241T-ZE · DH-IPC-HDW5442T-ZE · DH-IPC-HDW5541H-ASE-PV · DH-IPC-HDW5241H-ASE-PV · DH-IPC-HDW5842T-ZE-S2 · DH-IPC-HDW5242T-ZE-MF · DH-IPC-HDW5449H-ASE-D2 WizSense Mini-Domes (HDBW) DH-IPC-HDBW3841E-AS · DH-IPC-HDBW3441E-AS · DH-IPC-HDBW3541E-AS · DH-IPC-HDBW3241E-AS · DH-IPC-HDBW3449E-AS-NI · DH-IPC-HDBW3249E-AS-NI · DH-IPC-HDBW3841R-ZAS · DH-IPC-HDBW3441R-ZAS · DH-IPC-HDBW3541R-ZAS · DH-IPC-HDBW3241R-ZAS Lite 2-Series Mini-Domes DH-IPC-HDBW2831E-S-S2 · DH-IPC-HDBW2531E-S-S2 · DH-IPC-HDBW2431E-S-S2 · DH-IPC-HDBW2231E-S-S2 · DH-IPC-HDBW2231R-ZS-S2 · DH-IPC-HDBW2431R-ZS-S2 · DH-IPC-HDBW2531R-ZS-S2 · DH-IPC-HDBW2831R-ZS-S2 Cooper / Entry-Level Mini-Domes DH-IPC-HDBW1531E-S · DH-IPC-HDBW1431E-S · DH-IPC-HDBW1230E · DH-IPC-HDBW1420E · DH-IPC-HDBW1120E · DH-IPC-HDBW1531E · DH-IPC-HDBW1431E 5-Series Pro AI Mini-Domes DH-IPC-HDBW5541R-ASE · DH-IPC-HDBW5241R-ASE · DH-IPC-HDBW5442R-ASE · DH-IPC-HDBW5441R-ASE · DH-IPC-HDBW5842R-ASE-S2 · DH-IPC-HDBW5242R-ASE-MF · DH-IPC-HDBW5449R-ASE-LED HDCVI Turret Cameras HAC-HDW2802T-A-I8 · HAC-HDW2249T-A-LED · HAC-HDW2241T-A · HAC-HDW1500T-A · HAC-HDW1239T-A-LED · HAC-HDW1209T-A-LED · HAC-HDW2402T-A · HAC-HDW2801T-A · HAC-HDW1500EM-A HDCVI Mini-Domes HAC-HDBW2802R · HAC-HDBW2402R · HAC-HDBW2241R-Z · HAC-HDBW2231R-Z · HAC-HDBW1500R · HAC-HDBW1400R · HAC-HDBW1230R · HAC-HDBW1209R · HAC-HDBW1100R NOT Compatible — use a different accessory Dahua bullet cameras (HFW series — use PFA135 / PFA130-E junction box) · Full-size PTZ cameras · Thermal cameras · Cameras over 1 kg load · Camera bases over 110 mm diameter · Cameras with non-circular bases Need a quick decision? If you're mounting an eyeball turret or a mini-dome flat onto a wall, soffit or ceiling, and the camera weighs under 1 kg with a circular base around 110 mm, the PFA136 is the correct junction box. Pair the colour to the camera body, not the wall. Technical Specifications DH-PFA136 · Full Specifications (White & Black) Model — White DH-PFA136 Model — Black DH-PFA136-B Product Type Waterproof rear-cavity junction box for dome & turret cameras Material Aluminium alloy · powder-coated Finish — White Powder-coat · Dahua RAL White Finish — Black Powder-coat · Dahua RAL Black Dimensions (Ø × H) Φ110.0 × 34.0 mm (Φ4.33 × 1.34 in) Net Weight 0.19 kg (0.42 lb) Maximum Load Bearing 1.0 kg (2.2 lb) Cable Gland M20 (G½") water-tight · supplied with rubber gasket / water-joint Mounting Pattern Dahua HDW / HDBW circular base (3 × M4 machine screws) Operating Temperature −40 °C to +60 °C Humidity 0–90% RH (non-condensing) Package Contents 1 × Junction box · 3 × M4×10 machine screws · 3 × ST4×25 self-tappers · 3 × plastic anchors · 1 × M20 water-joint gland · 1 × hex wrench · installation sheet Compatible Camera Bases Most Dahua IPC-HDW (eyeball turret) · IPC-HDBW (mini-dome) · HAC-HDW · HAC-HDBW (see compatibility table) Applicable Surfaces Render · brick · weatherboard · fibre cement · Colorbond · plasterboard soffits (with appropriate fixings) Country of Origin China · Genuine Dahua factory accessory Australian Warranty 3-Year Australian Warranty (back-to-base) Installation Overview — From Box to Powered Up The PFA136 is one of the fastest Dahua accessories to fit — most installers have it on the wall and the camera powered up inside 10 minutes. The high-level sequence is below. 1. Mark the Three-Hole Pattern Use the PFA136's base as a drilling template. Three ST4×25 self-tappers (supplied) into plastic anchors (also supplied) hold it on render, brick or fibre cement. For Colorbond or timber soffits, drive the self-tappers direct into the substrate — no anchor needed. 2. Drill the Cable Entry Hole Drill the wall behind the box for the cable run-through. Thread the camera tail-cable through the wall and into the back of the box, then through the M20 gland on the side (or out the back if the install is internal/dry). 3. Bolt the Box to the Wall Tighten the three ST4 screws. The aluminium body is rigid — test that the box doesn't flex against the wall before adding the camera. 4. Make the Cable Connections Inside the Cavity Crimp or pre-terminate the RJ45 inside the cavity (the box is large enough for a coupler join, or for a pre-made tail join). The internal cavity also fits the supplied 12 V power lead or audio/alarm pigtails on cameras that include them. 5. Mount the Camera with 3 × M4 Screws Line up the camera's circular base on the PFA136, drive the three M4×10 machine screws (supplied) with the included hex wrench. The wrench is small — clip it to your tool tray, it's the only tool that fits the recess. 6. Power Up & Aim Connect the RJ45 to the PoE switch or injector; the camera boots in under 30 seconds. Aim the gimbal with the camera live (using DMSS on your phone or a test monitor) before locking the camera head. Optional: silicone-bead the perimeter of the box-to-wall join for a belt-and-braces seal on exposed outdoor installs. Frequently Asked Questions What's the difference between the PFA136 and the PFB203W? The PFA136 is a flat round junction box (Φ110 × 34 mm) that sits behind the camera as a sealed cable termination — used when the camera mounts flat against a wall, eave or soffit. The PFB203W is a wall-mount bracket with a projecting arm — used when the camera needs to angle outward from a vertical wall to look along a driveway or perimeter. They fit the same cameras but solve different installation geometries. Is the PFA136 actually waterproof, and to what rating? The box itself is not assigned an IP code (it's a passive enclosure, not a sealed electronics product), but the M20 cable gland and supplied rubber gasket seal the cable entry against wind-driven rain — the same gland Dahua uses on its IP66/IP67 cameras. With the gland fitted correctly and a silicone bead around the perimeter on exposed outdoor installs, you have a fully water-tight termination. Is the white box the same as the black box — just painted? Yes. Same Dahua aluminium casting, same M20 thread, same load rating, same mounting pattern, same datasheet, same screw kit. The only difference is the powder-coat colour. Choose by camera body colour, not by spec. What's the maximum camera weight I can mount on the PFA136? 1.0 kg (2.2 lb). That comfortably covers every Dahua eyeball turret, every mini-dome, and most compact fisheye cameras (350–700 g typical). Don't use it for PTZs, thermal cameras, or anything over 1 kg — those need a heavier accessory. Does this fit Dahua bullet cameras (HFW series)? No. Bullet cameras use a different junction box — the PFA135 (no gasket, internal use) or PFA130-E (outdoor, waterproof). The PFA136 is shaped for the round base of HDW turrets and HDBW mini-domes. Will it fit a Hikvision turret or mini-dome? Mechanically, no. The PFA136's three-screw bolt-circle is sized for the Dahua HDW / HDBW base. Hikvision use a different bolt pattern. For a Hikvision turret junction box, use the Hikvision DS-1280ZJ-DM18 or equivalent. Can I use it on a soffit or ceiling, not just a wall? Yes — and that's one of its most common uses in Australia. Eave-mounted front-door turrets and ceiling-mounted internal dome installs both use the PFA136 to hide the cable join behind the camera. Same three-screw fitment, same M20 gland. Does it ship with screws, anchors and the gland? Yes. Each PFA136 ships with 3 × M4×10 machine screws for the camera, 3 × ST4×25 self-tappers + 3 × plastic anchors for the wall, the M20 water-joint gland, and a hex wrench for the M4 screws. Nothing extra to order — open the box and install. Is it compatible with the Black BLK variants of the Dahua TiOC range? Yes — and that's exactly when you'd specify the Black PFA136-B. The black junction box colour-matches the BLK / Black-body TiOC turrets (HDW3849H-AS-PV-ANZ-S2 Black, for example) for a seamless installed look against dark walls and ceilings. Will it handle Australian sun and salt-air? Yes. The aluminium body doesn't rust, and the powder-coat finish is UV-stable. Operating temperature is rated to +60 °C, comfortably above any roof-mounted Australian summer day. For coastal sites (within 1 km of the surf), we still recommend an annual freshwater rinse to extend the powder-coat life — same advice as for the camera itself. What is the warranty and where is it serviced? The box ships with a 3-year Australian warranty against material and finish defects, serviced back-to-base through CCTV Guru. Damage from over-tightening, drop, or installation error is excluded — standard for any mechanical accessory. Do you ship Australia-wide and is stock genuine? Yes — Australian stock from authorised Dahua Australia channels (not parallel imports). We dispatch the same business day for orders placed before 2 pm AEST to Sydney, Melbourne, Brisbane, Perth, Adelaide, Hobart, Canberra, Darwin and every regional address in between. Downloads & Resources DH-PFA136 Datasheet Dahua Junction Box Quick Start Guide Dahua Junction Box User Manual Order the Dahua DH-PFA136 from CCTV Guru CCTV Guru is an authorised Australian reseller of Dahua network cameras and genuine factory accessories. Order the PFA136 Waterproof Junction Box today in White or Black for fast Australia-wide dispatch, real Dahua factory parts (not generic copies) and Australian-based technical support if you need help choosing between junction-box and wall-bracket options for a multi-camera project. Buying ten or more for a commercial rollout? Request a project quote or contact our Australian team — we'll match the right junction-box colour to your camera SKUs across the whole job.

Read more less

Dahua Pole Mount Bracket Material: SECC & SUS304 Pole mount bracket Aesthetic design Specifications CAMERA BRACKETS TYPE Pole Mount Bracket MATERIAL SECC & SUS304 COLOUR White DIMENSION 130.4mmx170mmx45mm (5.13''x6.69''x1.77'') Downloads DH-PFA150_datasheet

Read more less

Dahua Ceiling Mount Bracket Neat & Integrated design Ceiling mount bracket Material: Aluminum Specifications CAMERA BRACKETS TYPE Ceiling Mount Bracket of Mini Dome & Eyeball Camera MATERIAL Aluminum COLOUR White DIMENSION 128.8mmx767.0mm(5.07''x30.2'') Downloads DH-PFB220C_datasheet

Read more less

AXIS TQ1501-E Crane and Traffic Mount, 02384-001 AXIS TQ1501-E Crane and Traffic Mount is a great mount for reducing vibrations and offering more stability to your camera installations in demanding situations, such as mounting on cranes or traffic lights. It’s robust and corrosion resistant with its IK10- and NEMA 4X-ratings. The mount can be tilted up to 45 degrees. Fewer vibrations and more stability Alleviates vibrations Pivot mount for more stability Robust, IK10 Coating in corrosion resilient material Designed for demanding situations Downloads AXIS TQ1501-E Datasheet

Read more less

Hikvision Water-proof Rain Shade (AVPIT3ZF) - DS-1250ZJ Rain Shade for Outdoor Dome Camera Plastic Hikvision White Parameters Weight 199g Appearance Hikvision White Material Composite Fibre Dimension 264.7*152*189.6 mm Description Rain Shade for Outdoor Dome Camera Download Quick Start Guide

Read more less

Dahua Integrated Mount Tester DH-PFM907-E Dahua Integrated Mount Tester Features Supports HDCVI, AHD, HDTVI and CVBS digital surveillance system PoE or 12 VDC power supply Support Onvif protocol to configure IP address Audio/RS-485 control Digital multimeter function TDR network cable test Wi-Fi signals test Download PFM907-E_datasheetPFM907-E_User 's manualDH-PFM907-E_DIMENSIONS

Read more less

Dahua Mount Adapter Neat & Integrated design Material: Aluminum Specifications CAMERA BRACKETS TYPE Adapter Plate of PT Network Camera MATERIAL Aluminum COLOUR White DIMENSION 134.1mmx83.5mm(5.28''x3.29'') Downloads DH-PFA107_datasheet

Read more less

Dahua PoE Switch for IP System with Dahua Network Protocol, Connect up to 6 Indoor Monitor Features Decent appearance Protocol network power supply switch Connect max 6 indoor monitors with the Cat 5e cable, transfer the signal and power together Specifications PoE SWITCH ETHERNET PORT 6 OPTICAL PORT Not support UPLINK PORT 2 POE BUDGET Max 45W LAYER Layer 2 TYPE Unmanaged Downloads Datasheet of DHI-VTNS1060A-A User Manual

Read more less

Dahua Ceiling Mount Bracket Aesthetic design Material: aluminium & PC Ceiling mount bracket Specifications CAMERA BRACKETS TYPE Ceiling Mount Bracket MATERIAL Aluminum & PC COLOUR White DIMENSION 133.6mm x 235.5mm (5.26''x16.54'') Downloads DH-PFB300C_datasheet

Read more less

Dahua Wall Mount Bracket Aesthetic design Wall mount bracket Material: aluminum Specifications CAMERA BRACKETS TYPE Wall Mount Bracket MATERIAL Aluminum COLOUR White DIMENSION 58mmx88mmx190.5mm (2.28''x3.46''x7.50'') Downloads DH-PFB121W Datasheet

Read more less

Dahua Waterproof Black Junction Box DH-PFA130-E-B Neat & Integrated design Material: Aluminum IP66 junction box Specifications CAMERA BRACKETS TYPE Water-proof Junction Box MATERIAL Aluminum COLOUR Black DIMENSION 124mmx41mm(4.88''x1.61'') Downloads DH-PFA130-E_datasheet

Read more less

Dahua Waterproof Junction Box White Aesthetic design Material: aluminum Junction box Specifications CAMERA BRACKETS TYPE Junction Box MATERIAL Aluminum COLOUR White DIMENSION 90.0mmx34.1mm (3.54''x1.34'') Downloads DH-PFA135 Datasheet

Read more less

Hikvision Video Intercom Accessory Hikvision DS-KABV6114-RS Rain Shield for Villa Door Stations The Hikvision DS-KABV6114-RS is a genuine protective rain shield designed for compatible Hikvision villa door stations. It helps protect the outdoor intercom from direct rain exposure while giving the installation a cleaner, more professional surface-mounted finish. This accessory is ideal when installing a Hikvision door station on an exposed wall, front gate pillar, entryway or outdoor-facing surface where extra protection and a neater finish are required. Protection Rain Shield Cover Compatibility KV6114 / KV6124 Series Mounting Surface Mount Material PC Protective Body Why Use the DS-KABV6114-RS? Helps Protect Outdoor Door Stations Adds a protective cover around the compatible Hikvision villa door station to help reduce direct exposure to rain and outdoor conditions. Cleaner Surface-Mounted Finish Gives the installation a more finished look, especially on rendered walls, brickwork, gate pillars and exposed entrance areas. Made for Compatible Hikvision Models Designed for Hikvision KV6114 and KV6124 series villa door stations, including popular 4MP Hikvision villa intercom door stations. Ideal for Homes and Small Businesses A simple but useful add-on for front doors, gates, offices, townhouses, duplexes and small commercial entry points. Key Specifications Model DS-KABV6114-RS Product Type Rain shield / protective shield for Hikvision villa door stations Installation Surface mounting Compatible Series Hikvision DS-KV6114 / DS-KV6124 series villa door stations Material PC Dimensions 194.49 mm × 84.62 mm × 47 mm Working Temperature -40°C to 60°C Working Humidity 10% to 95%, non-condensing Compatible Hikvision Door Stations The DS-KABV6114-RS is commonly used with Hikvision villa door stations from the KV6114 and KV6124 series. It is especially useful when the door station is installed outdoors or in an area with partial weather exposure. DS-KV6114 Series Suitable for compatible Hikvision DS-KV6114 villa door stations where a surface-mounted rain shield is required. DS-KV6124 Series Suitable for compatible Hikvision DS-KV6124 keypad villa door stations where extra outdoor protection is preferred. Recommended Add-ons Hikvision Villa Door Station Pair this rain shield with a compatible Hikvision DS-KV6114 or DS-KV6124 villa door station. Hikvision Indoor Monitor Complete the intercom setup with a compatible Hikvision indoor station for video calling and door release control. Electric Strike or Gate Relay Add door or gate release hardware so visitors can be granted access from the indoor monitor or app. PoE Switch or Power Supply Depending on your intercom design, a PoE switch, power supply or compatible network hardware may be required. FAQs What is the DS-KABV6114-RS used for? It is a rain shield / protective shield for compatible Hikvision villa door stations. Is this a Hikvision genuine accessory? Yes. The DS-KABV6114-RS is a Hikvision video intercom accessory. Does it suit the DS-KV6114 series? Yes. It is designed for compatible Hikvision KV6114 series villa door stations. Does it suit the DS-KV6124 series? Yes. It is also commonly listed for compatible KV6124 series villa door stations. Is this for surface mounting? Yes. The DS-KABV6114-RS is designed for surface-mounted installations. Is it suitable for outdoor intercom installs? Yes. It is designed to help protect compatible outdoor villa door stations from direct weather exposure. Genuine Hikvision Australia-Wide Shipping Fast Dispatch

Read more less

Dahua DH-PFH101 Rack Mount Tray The Dahua DH-PFH101 Rack Mount Tray is made of durable SPCC material and is highly compatible with standard storage devices. Designed to fit into a 19'' rack, this tray provides convenient and organized storage for your equipment. Streamline your setup with this reliable and versatile rack mount tray. Features Material: SPCC High compatibility for standard storage device 19'' standard rack mount tray Downloads DH-AC-PFH101 Datasheet

Read more less

Dahua PFA101 Mount Adapter Features Aesthetic design Material: aluminum  Mount adapter Specifications Dahua Camera Bracket Type Mount adapter Material Aluminum Colour White Dimension 159mmx159mmx35mm (6.26''x6.26''x1.38'') Downloads DH-AC-PFA101 Datasheet

Read more less

Hikvision PTZ Wall mount DS-1602ZJ Wall Mount Aluminum alloy Hikvision White Parameters Description Wall Mount Bracket In/Outdoor Appearance Hik white Material Aluminum alloy Dimension 97.3 mm × 182.6 mm × 306.4 mm (3.83” × 7.19” × 12.06”) Weight 925 g (2.04 lb.) DownloadQuick Start Guide

Read more less

Hikvision Wall Mount Bracket With Integrated Junction Box (2365/2366/2385G1/2h65/2H85/2346/2347/2386) - DS-1273ZJ-140B Wall Mount With Junction Box Aluminum alloy Hikvision White Parameters Weight 1488g Appearance Hikvision White Material Aluminum Alloy Dimension Φ140×182×120mm Range Of Application Suitable for DS-2CC51xxP(N) dome camera wall mounting Description DS-2CC51xxP(N) Wall Mounting Bracket for Dome Camera Download Quick Start Guide

Read more less

Dahua Mini Dome and Turret Mount Adapter Neat & Integrated design Material: Aluminum Specifications CAMERA BRACKETS TYPE Adapter Plate of Mini Dome & Eyeball Camera MATERIAL Aluminum COLOUR White DIMENSION 134.1mm x 83.5mm (5.28''x3.29'') Downloads DH-PFA106 Datasheet

Read more less

Dahua Hi-PoE Midspan, Support PoE for Hi-PoE 60W high power consumption speed dome Support PoE for Hi-PoE 60W high power consumption speed dome Indicator status: power (normal power on), PoE (normal power supply) Cooperate with PoE Extender (PFT1300), able to cascade level 2 PoE Extender, connect to 3 IPC (power consumption Installation mode: wall mount Downloads PFT1200_Datasheet_20170728PFT1200_User Manual

Read more less

Dahua Waterproof Junction Box White DH-PFA121 Aesthetic design Material: aluminum IP66 junction box Specifications CAMERA BRACKETS TYPE Water-proof Junction Box MATERIAL Aluminum COLOUR White DIMENSION 134.0mmx133.5mmx56.0mm (5.28''x5.25''x2.20'') Downloads DH-PFA121 Datasheet

Read more less

The Dahua PFB5310C is a reliable in-ceiling mount bracket designed to provide a clean and secure mounting solution for compatible network and PTZ cameras. The bracket supports a variety of recessed ceiling installations, offering a neat finish with minimal intrusion into the camera’s field of view. Built with rugged materials and an anti-drop safety rope, it ensures secure, safe installation even in commercial environments.  Installation is quick and simple, and the bracket design allows easy disassembly and maintenance when needed — making it ideal for offices, retail spaces, warehouses, schools, and other professional CCTV installations. Key Features Designed for in-ceiling mounting of compatible Dahua cameras Screws embedded in the frame — clean installation with full visual range Includes anti-drop rope for added safety Works with standard recessed ceiling types Durable SECC & PC construction for long-lasting reliability White finish blends with most ceilings Easy to install and maintain Specifications Specification Details Model / SKU PFB5310C Mount Type In-ceiling mount bracket Material SECC and PC (polycarbonate) Colour White Product Dimensions Ø 238.0 mm × 78.0 mm (Ø 9.37″ × 3.07″) Net Weight 0.35 kg (0.77 lb) Gross Weight 0.62 kg (1.37 lb) Load Bearing Capacity Up to 3.0 kg (6.61 lb) Installation In-ceiling mount for recessed ceilings Operating Temp. –40 °C to +60 °C (–40 °F to +140 °F) Operating Humidity < 90 % RH Storage Temp. –40 °C to +60 °C (–40 °F to +140 °F) Storage Humidity 10 %–90 % RH Anti-corrosion Level Basic Protection

Read more less

Uniview UNV Junction Box Bracket – White & Black Variants The Uniview UNV Junction Box Bracket delivers a professional, secure mounting solution for Uniview dome and bullet cameras. Available in white and black, it blends with your camera finish for a clean, coordinated look while protecting and hiding cables. Built from durable aluminum alloy, the bracket features an internal junction cavity with rear and side cable entries for neat routing. Ideal for indoor or sheltered outdoor installations, it provides quick service access and a polished result on walls, eaves, and façades. Key Features Brand: Uniview UNV Color options: White or Black to match your camera Aluminum alloy construction with weather-resistant finish Internal cavity conceals wiring; rear & side cable entries Pre-drilled mounting pattern for fast, secure installs Compatible with Uniview dome & bullet camera bases (model dependent) Technical Specifications Specification Details Brand Uniview UNV Product Type Junction Box Bracket Color Options White / Black Material Aluminum alloy Cable Routing Internal cavity; rear & side entries Mounting Pre-drilled hole pattern; wall/eave installs Environment Indoor / Sheltered outdoor Finish Weather-resistant powder coating Compatibility Uniview UNV dome & bullet bases (check specific model) In the Box Junction box bracket, mounting screws, quick guide What’s Included Uniview UNV junction box bracket (White or Black) Mounting hardware Quick guide Customer Requirements Compatible Uniview UNV camera/base RJ45 Cat6 cable (for PoE cameras) Appropriate wall fasteners and sealant for your surface
