Professional IP65 & IK10 Outdoor Smart IoT Enclosure
The WI-TEK Smart IoT Box series is a professional-grade, all-weather protection solution designed for outdoor electrical equipment. Engineered for durability in harsh environments, these enclosures are the ideal choice for CCTV surveillance, WLAN deployments, and Industrial IoT projects.
Key Technical Features
-
Rugged IK10 Impact Resistance: Featuring a seamless welding box body, this enclosure is built to withstand significant external force without deformation.
-
IP65 Weatherproof Rating: Complete protection against dust ingress and high-pressure water jets, ensuring your internal hardware remains dry and functional.
-
Advanced Material Science: Constructed from SUS430 stainless steel with an electrostatic powder spraying finish to resist UV damage, salt spray, and acid/alkali corrosion.
-
Active Thermal Management: Includes an integrated top-mounted cooling fan and bottom ventilation ports that create a natural air duct for superior heat dissipation.
-
Modular Installation: A highly flexible design featuring a detachable top cover, side panels, and mounting plates to accommodate vertical or horizontal equipment layouts.
-
Enhanced Security: Equipped with a secure lock cartridge and a door microswitch that can be integrated with cloud or buzzer alarms to prevent unauthorized access.
Product Variants & Dimensions
| Specification |
WI-IOTBOX01 |
WI-IOTBOX02 |
WI-IOTBOX03 |
| Overall Dimensions |
300 x 400 x 206.5 mm |
400 x 600 x 256.5 mm |
500 x 720 x 286.5 mm |
| Inner Dimensions |
250 x 350 x 180 mm |
350 x 560 x 230 mm |
450 x 650 x 260 mm |
| Net Weight |
7.2 kg |
12.6 kg |
17.1 kg |
Modular Application Support
This series supports a wide range of industrial equipment to decrease project deployment costs through modular installation:
- CCTV and NVR protection
- Industrial 4G LTE Routers and M2M Gateways
- Outdoor Wireless Transmitters and Mesh APs
- Solar Powered PoE Switches and Battery Controllers
Package Contents
- 1x Smart IoT Box Enclosure
- 1x CHNT NXB-63 (63A) Miniature Circuit Breaker
- 1x 12V DC Cooling Fan
- 1x Door Microswitch Accessory
- 4x M25 Waterproof Ethernet Connectors
- Wall and Pole Mounting Accessory Kits
