Uniview UNV NVR508-64E-IQ 64 Channel 4K AI NVR — 32MP, 8-Bay RAID, N+1 Hot Spare

Description

Uniview UNV · Network Video Recorder

Uniview UNV NVR508-64E-IQ 64 Channel 4K AI NVR — 32MP, 8-Bay RAID, N+1 Hot Spare

The Uniview NVR508-64E-IQ is a 64-channel network video recorder with 8 SATA drive bays and recording support up to 32MP. It connects to cameras over the network and requires an external PoE switch for PoE cameras. Incoming bandwidth is 512 Mbps (Smart Off); 200 Mbps (Smart On); storage and analytics should be sized for the intended camera configuration.

Specifications
Model NVR508-64E-IQ
IP Camera Inputs 64 channels
Maximum Recording Resolution 32MP
Compression Ultra 265, H.265, H.264
Incoming Bandwidth 512 Mbps (Smart Off); 200 Mbps (Smart On)
Outgoing Bandwidth 512 Mbps (Smart Off); 200 Mbps (Smart On)
Built-in PoE None; use an external PoE switch or separately powered cameras
Network 2 × RJ45 10/100/1000 Mbps
SATA Bays 8
HDD Capacity Up to 24 TB per drive; 192 TB raw total. Maximum capacity requires ambient temperature no higher than 40°C; supported HDD size and usable capacity depend on configuration.
RAID RAID 0, 1, 5, 6, 10
Power AC 100–240 V
Power Consumption ≤ 35 W without HDDs
Reliability ANR (automatic network replenishment); disk group and redundant storage
Video Outputs 2 × HDMI + 2 × VGA. HDMI/VGA pairs are simultaneous; pairs are independent. HDMI up to 4K/60 Hz
N+1 Hot Spare Supported
AcuSearch / AcuTrack All channels with compatible UNV SIP/UMD cameras
NVR Analytics SIP with normal cameras: up to 8 × 2MP, 4 × 4MP or 2 × 4K. UMD: up to 16 × 2MP, 8 × 4MP or 4 × 4K. Analytics modes cannot run simultaneously.
Dimensions 442 × 432 × 86 mm; 2U
Weight ≤ 5.5 kg without HDDs
Warranty (Australia) 3 years · CCTV Guru Australia

Downloads

Manufacturer datasheet

Frequently Asked Questions

How many cameras and what resolution are supported?

Up to 64 IP cameras, recording at up to 32MP. Total incoming bitrate must stay within 512 Mbps (Smart Off); 200 Mbps (Smart On).

Does it power cameras directly?

No. This model has no built-in PoE ports. Use an external PoE switch or a suitable separate camera power supply.

How much storage can it support?

Up to 24 TB per drive; 192 TB raw total. Maximum capacity requires ambient temperature no higher than 40°C; supported HDD size and usable capacity depend on configuration.

Does it support RAID?

RAID 0, 1, 5, 6, 10. RAID usable capacity depends on drive count and the selected RAID level.

What video outputs does it have?

2 × HDMI + 2 × VGA. HDMI/VGA pairs are simultaneous; pairs are independent. HDMI up to 4K/60 Hz.

What does ANR do?

With compatible cameras and configured camera-side storage, ANR can replenish recorder footage after a network interruption.

What power supply does it require?

AC 100–240 V. Consumption is ≤ 35 W without HDDs.

Does analytics change its bandwidth limit?

Yes. Incoming and outgoing bandwidth are up to 512 Mbps with Smart Off and 200 Mbps with Smart On. AcuSearch/AcuTrack require compatible UNV SIP/UMD cameras.
