Uniview UNV IPC6828EL-X42-W-VH1 8MP 4K 42× Pro PTZ Camera — LightHunter, Auto-Tracking, IR 500m

Description

Uniview UNV · IP PTZ Camera

Uniview UNV IPC6828EL-X42-W-VH1 8MP 4K 42× Pro PTZ Camera — LightHunter, Auto-Tracking, IR 500m

The Uniview IPC6828EL-X42-W-VH1 is an 8MP Pro Series PTZ camera with 42× optical zoom, intelligent target tracking and IR illumination rated up to 500 m. Gyroscope stabilisation, defog and a wiper support monitoring of large outdoor areas. Its 67 W maximum load requires a suitable 24 V supply or 802.3bt PoE source.

Specifications
Model IPC6828EL-X42-W-VH1
Image Sensor 1/1.8″ CMOS
Resolution 8MP, 3840 × 2160, up to 30 fps
Lens 6–252 mm, F1.2–F4.6; 42× optical zoom and 16× digital zoom
Night Vision IR up to 500 m
WDR 120 dB
Smart Features Intelligent auto-tracking with human, vehicle and non-motor-vehicle filtering; Smart Intrusion Prevention; multi-target detection; people counting
Image Features Gyroscope EIS, optical and digital defog, wiper
Local Storage MicroSD up to 512 GB
Audio 1 input / 1 output; two-way audio using external audio devices
Alarm I/O 7 inputs / 2 outputs
Network 1 × RJ45 10/100 Mbps; ONVIF S/G/T/M
Power AC 24 V ±25%, DC 24 V ±25% or IEEE 802.3bt PoE; maximum 67 W
Protection IP67, 6 kV surge protection
Operating Temperature −40°C to 70°C
Dimensions Ø226.7 × 440.3 mm
Weight 6.9 kg
Warranty (Australia) 3 years · CCTV Guru Australia

Downloads

Manufacturer specifications Datasheet Quick Guide

Frequently Asked Questions

How far does it zoom?

6–252 mm, F1.2–F4.6; 42× optical zoom and 16× digital zoom. Identification distance depends on scene lighting, target size and camera setup.

Does it automatically track targets?

Intelligent auto-tracking with human, vehicle and non-motor-vehicle filtering; Smart Intrusion Prevention; multi-target detection; people counting.

What power supply is required?

AC 24 V ±25%, DC 24 V ±25% or IEEE 802.3bt PoE; maximum 67 W. Check the PoE source and cable run can support the camera load.

Can it record locally?

MicroSD up to 512 GB.

Does it have two-way audio?

1 input / 1 output; two-way audio using external audio devices.

Is it suitable for outdoor use?

IP67, 6 kV surge protection; operating temperature −40°C to 70°C.

3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support

Uniview UNV IPC6828EL-X42-W-VH1 8MP 4K 42× Pro PTZ Camera — LightHunter, Auto-Tracking, IR 500m

Product form

SKU: IPC6828EL-X42-W-VH1

$2,919.00 Incl. GST
