Camera
|
|
Image Sensor
|
1/1.8" CMOS
|
|
Pixel
|
8 MP
|
|
Max. Resolution
|
3840 (H) x 2160 (V)
|
|
ROM
|
8 GB
|
|
RAM
|
2 GB
|
|
Electronic Shutter Speed
|
1/1 s–1/30,000 s
|
|
Scanning System
|
Progressive
|
|
Min. Illumination
|
Color: 0.005 lux@F1.4
B/W: 0.0005 lux@F1.4
0 lux@F1.4 (illuminator on)
|
|
Illumination Distance
|
500 m (1640.42 ft)
|
|
Illuminator On/Off Control
|
Zoom Prio; Manual; Smart IR
|
|
Illuminator Number
|
10 IR lights
|
|
Wiper
|
Smart wiper
|
|
Lens
|
|
Focal Length
|
5.6 mm–223 mm
|
|
Max. Aperture
|
F1.4–F4.5
|
|
Field of View
|
H: 63.9°–2.0°; V: 37.3°–1.1 °; D: 71.2°–2.3 °
|
|
Optical Zoom
|
40x
|
|
Focus Control
|
Auto; semi-auto; manual
|
|
Close Focus Distance
|
0.5 m–2 m (1.64 ft–6.56 ft)
|
|
Iris Control
|
Auto; manual
|
|
DORI Distance
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
4,400 m
(14,435.70 ft)
|
1,740 m
(5,708.66 ft)
|
880 m
(2,887.14 ft)
|
440 m
(1,443.57 ft)
|
|
PTZ
|
|
Pan/Tilt Range
|
Pan: 0° to 360°
Tilt: –30° to +90°, auto flip 180°
|
|
Manual Control Speed
|
Pan: 0.1°/s–240°/s
Tilt: 0.1°/s–100°/s
|
|
Preset Speed
|
Pan: 240°/s; Tilt: 120°/s
|
|
Preset
|
300
|
|
Tour
|
8 (up to 32 presets per tour)
|
|
Pattern
|
5
|
|
Scan
|
5
|
|
Speed Adjustment
|
Yes
|
|
Power-off Memory
|
Yes
|
|
Idle Motion
|
Preset; Tour; Pattern; Scanning
|
|
PTZ Protocol
|
DH-SD
Pelco-P/D (auto recognition)
|
|
Smart Event
|
|
Event Trigger
|
Motion detection, video tampering, scene changing, network disconnection, IP address conflict, illegal access, and storage anomaly
|
|
IVS
|
Object Abandoned/Missing
|
|
Intelligence
|
|
Video Metadata
|
Support human body, human face, motor vehicle and non-motor vehicle image capture and attributes extraction.
|
|
IVS (Perimeter Protection)
|
Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification
|
|
Face Recognition
|
Yes
|
|
Auto Tracking
|
Yes
|
|
Video
|
|
Video Compression
|
Smart H.265+; H.265; Smart H.264+; H.264; MJPEG (Sub Stream 1)
|
|
Streaming Capability
|
3 streams
|
|
Resolution
|
4K (3840 × 2160); 4M (2560 × 1440); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576);
CIF (352 × 288)
|
|
Video Frame Rate
|
Main stream: 4K/4M/1080p/1.3M/720p (1–25/30 fps)
Sub stream 1: D1/CIF (1–25/3
|
