AXIS TM3101 · NDAA & TAA COMPLIANT
Discreet, Architectural-Grade Mount for Mini Fixed Dome Cameras
The AXIS TM3101 Pendant Wall Mount delivers a sophisticated, professional finish to indoor surveillance installations. Designed to integrate seamlessly with the modern aesthetics of retail spaces, offices, and high-end commercial interiors, this accessory features an elegant profile with completely concealed mounting screws and internal cable routing. By mimicking a clean pendant style directly from the wall, the TM3101 eliminates visual clutter while keeping security infrastructure clean, professional, and physically protected.
Compatibility
M20, M30, M31, M42
Integrated Storage
Device Compartment
Environment
Indoor Flush Mount
Sustainability
PVC-Free / 22% Recycled
Innovative Storage & Directional Versatility
Beyond aesthetics, the AXIS TM3101 Pendant Wall Mount serves as an operational hub. It is engineered with a built-in, ingress-protected storage compartment that safely houses vital connectivity accessories, including the AXIS T6101 Audio & I/O Interface, AXIS Device Microphone A, or AXIS T8643 PoE+ over Coax compact adapters. This design empowers operators to add advanced high-fidelity audio capture and network conversion tools directly at the camera's mounting point without cluttering the ceiling line. Highly adaptable, the TM3101 can be mounted on walls, counters, or hard ceilings—making it the ideal choice for entrance analytics, facial recognition, and retail checkout point-of-sale monitoring.
Paintable, Seamless Wall Integration
The contemporary casing has no visible mounting screws or cables, giving it a streamlined appearance that appears as an extension of the wall. Constructed with premium eco-friendly materials, the plastic cover can easily be repainted to perfectly match your establishment's interior brand palette.
Optimized Placement for Retail Analytics
Install the bracket in varying orientations—including downward-facing angles over doorways—to optimize the field of view for high-accuracy retail intelligence, such as automated people-counting and facial recognition software.
Technical Specification Matrix
| Camera Model |
AXIS TM3101 |
| Supported Products |
AXIS M20, M30, M31, and M42 Series |
| Casing Material |
PC/ABS cover; Glass fiber-reinforced polyamide bottom bracket |
| Maximum Load Capacity |
1.5 kg (3.3 lbs) |
| Physical Dimensions |
175 x 124 x 39 mm (6.9 x 4.9 x 1.5 in) |
| Weight |
159 g (0.35 lb) |
| Sustainability |
PVC-free, composed of 22% recycled plastics |
| Operating Conditions |
-10 °C to 50 °C (14 °F to 122 °F), Humidity 10–85% RH (non-condensing) |
| Manufacturer Warranty |
5-Year AXIS Limited Hardware Warranty |
Which cameras are compatible with the AXIS TM3101 mount?
The TM3101 is specifically designed for indoor mini fixed dome network cameras. This includes the AXIS M20, M30, M31, and M42 Series. It is also compatible with the AXIS P39 Series when the camera is not intended for onboard vehicle use.
What accessories can fit inside the integrated compartment?
The secure, integrated back-compartment is designed to cleanly house network and audio additions. Recommended accessories include the AXIS T6101 Audio and I/O Interface, AXIS Device Microphone A, and the AXIS T8643 PoE+ over Coax Compact unit.
Can this mount be installed outdoors or in harsh environments?
No, the AXIS TM3101 is strictly rated for indoor environments. It features an operating temperature range of -10 °C to 50 °C (14 °F to 122 °F) and does not carry weatherproof IP ratings required for outdoor exposures.
Can I paint the AXIS TM3101 to match my interior walls?
Yes. The exterior plastic PC/ABS cover can easily be painted with standard plastic-safe paint. This allows you to completely customize the aesthetic to blend seamlessly with any wall color or retail background.
