AXIS I SERIES · NDAA & TAA COMPLIANT
Streamlined Security & Communications Hub
The AXIS I5304 is a sleek, highly versatile network answering unit engineered explicitly for enterprise lobbies, secure commercial reception desks, and concierge operations. Running on the robust 2N OS, this indoor IP terminal gives security personnel immediate control over structural access, offering sharp visual verification and reliable communication capabilities to cross-examine incoming visitors before granting facilities entrance.
Resolution
7" LCD (1024x600)
Optics / Input
Capacitive Touch
Audio Support
Full-Duplex 2-Way
System Power
PoE Class 3 / 12V
Advanced VoIP Integration & Visual Verification
Engineered to work seamlessly alongside modern security architectures, this unit features deep SIP 2.0 protocol support, making it simple to link into your overarching commercial Voice over IP (VoIP) telephone infrastructure or direct peer-to-peer configurations. Operators can quickly view real-time H.264 video up to 720p at 30 frames per second straight from connected video door stations. To find out more about how it fits inside your enterprise layout, look up the axis-i5304-network-answering-unit-ndaa-compliant system configuration data.
Crystal Clear Full-Duplex Audio
Equipped with an integrated premium microphone and an optimized built-in speaker delivering up to 84 dBC at 1 meter, the unit implements enterprise-grade echo cancellation. This ensures voice interactions with outside guests remain completely intelligible even in high-traffic reception zones.
Flexible Industrial Forms
With its high-end tempered glass interface surface and sleek, minimalistic physical casing, the device adapts seamlessly to modern corporate styling. A range of dedicated hardware options makes it simple to execute flush recessed wall placement, surface mounts, or active desktop stand deployments.
Technical Specification Matrix
| Camera Model |
AXIS I5304 |
| Display Screen |
7-inch Capacitive Multi-Touch LCD (1024 x 600) |
| Video Formats |
H.264 (MPEG-4 Part 10/AVC), Motion JPEG up to 720p @ 30fps |
| Audio Interface |
Built-in Mic & Speaker with Line-Out for Hearing Loops (600 mV RMS) |
| VoIP Protocol |
SIP 2.0 (RFC3261), SIPS, DTMF (RFC2833) Support |
| Network Interfaces |
1x 10BASE-T/100BASE-T RJ45 Port, 1x Doorbell Input Relay (NO) |
| Power Supply |
PoE IEEE 802.3af Type 1 Class 3 (Typical 2.9W, Max 12W) or 12 VDC 1A |
| Cybersecurity |
IEEE 802.1X (EAP-TLS), HTTPS, TLS v1.2, X.509 Certificate PKI |
| Dimensions & Weight |
193 mm x 157 mm x 37 mm; 555 g (1.2 lbs) |
Can this unit remotely trigger door locks?
Yes. The interactive capacitive touchscreen layout allows front desk staff to execute HTTP control commands or toggle connected network relays directly from the active view panel, letting them open doors instantly during an intercom call.
Does it require a separate power cord if connected via network?
No. Thanks to Power over Ethernet (PoE IEEE 802.3af Class 3) support, a single standard network cable delivers both communication data streams and physical electrical operating power directly to the device.
Is it compatible with non-Axis intercom systems?
Yes. Because the unit is powered by the flexible 2N OS, it boasts broad integration compatibility, supporting Axis, 2N, and generic third-party IP intercom devices that implement standard SIP 2.0 video and audio streams.
What accessories are required to mount the device?
Depending on the environment, the device can be installed via the AXIS TI5201 Recessed Mount for flush walls, the AXIS TI5601 Surface Wall Mount, or the AXIS TI5602 Desk Stand (all sold separately).
