AXIS C-SERIES · NDAA & TAA COMPLIANT
Convert Passive Speakers Into Smart Network Audio Systems
The AXIS C8210 Network Audio Amplifier is a compact, smart migration tool that bridges the gap between traditional analog audio and modern IP technology. By delivering up to 15W of high-quality digital audio, it transforms any passive speaker—regardless of brand—into a fully feature-rich network speaker. Ideal for commercial offices, retail outlets, educational institutions, and healthcare facilities, this intelligent amplifier deploys easily on existing networks to provide zoned background music, clear voice announcements, and scheduled audio paging.
Advanced Edge-Based Intelligence and Integration
Built on open IP standards, the AXIS C8210 provides robust integration pathways with leading Video Management Systems (VMS), VoIP protocols (using SIP), and unified network infrastructure. With built-in features such as an internal pre-configured equalizer, onboard microSD slot for edge-storage playback, and customizable I/O ports for physical trigger sensors, this amplifier acts as an all-in-one system controller. Its network compliance ensures zero reliance on proprietary servers, allowing your enterprise to manage multi-zone audio streaming directly from a local interface.
All-In-One Audio Edge Management
Comes pre-installed with AXIS Audio Manager Edge, enabling decentralized control over zones, volume parameters, scheduling presets, and user permissions without requiring an external controller license.
Proactive Device Health Monitoring
Supports automated microphone-free testing via impedance verification and network pings, alerting your administrative dashboard instantly if a passive speaker connection becomes disconnected or degraded.
Technical Specification Matrix
| Camera Model |
AXIS C8210 |
| Amplifier Technology |
Built-in Class D digital amplifier |
| Power Output |
15W with PoE+ (Class 4) / 7W with PoE (Class 3) |
| Supported Speakers |
Passive speakers (Minimum impedance 4-16 Ohms) |
| Network Audio Protocols |
SIP (VoIP/IP-PBX integration), RTP/RTSP, Axis Audio Streaming |
| Edge Storage |
microSD/microSDHC/microSDXC card slot (up to 128 GB supported) |
| Power Input |
Power over Ethernet (PoE) IEEE 802.3af/at Type 1 Class 3/Type 2 Class 4 |
| Audio Processing |
Configurable High-pass filter, Equalizer, Dynamic Range Control |
Can I use any third-party passive speaker with the AXIS C8210?
Yes. The AXIS C8210 is designed to work with any 4 to 16 Ohm passive speaker, regardless of brand, transforming it directly into a network speaker.
Is the audio management software included for free?
Absolutely. The device comes pre-installed with AXIS Audio Manager Edge, giving you full control of scheduling, volume, zones, and playlists without additional license costs.
How is the unit powered?
The unit is powered via Power over Ethernet (PoE). For full 15W output power performance, PoE+ (IEEE 802.3at Type 2 Class 4) is highly recommended.
Does this amplifier support standard SIP/VoIP systems?
Yes. It supports SIP protocols for direct registration with PBX and VoIP telephony environments, letting you page speakers using IP phones.
