Uniview UNV ED-525B-WB Dual-Camera Wi-Fi Video Doorbell — 3MP+2MP, Package Detection, Wi-Fi 6

Description

Uniview UNV · Video Doorbell

Uniview UNV ED-525B-WB Dual-Camera Wi-Fi Video Doorbell — 3MP+2MP, Package Detection, Wi-Fi 6

The Uniview ED-525B-WB pairs a 3MP visitor camera with a 2MP downward-facing camera for package monitoring. It offers two-way audio, built-in 8 GB storage, package detection and dual-band Wi-Fi 6. Select a transformer compatible with the chime configuration and follow the wiring guide before using the call button.

Specifications
Model ED-525B-WB
Cameras 3MP main visitor camera + 2MP ground/package camera
Main Field of View 116° horizontal / 82.5° vertical
Ground Camera Field of View 96.8° horizontal / 52.6° vertical
Night Vision IR up to 5 m; white light up to 2 m
WDR Main 80 dB / sub 58 dB; HDR and DWDR supported
Detection Motion, human-body and package detection
Audio Built-in microphone and speaker; two-way audio
Storage 8 GB built-in eMMC
Wireless Dual-band 2.4/5 GHz Wi-Fi 6 (802.11 b/g/n/ax); integrated BLE
Integration UNV-Link app and Uniview NVR; Uniview private protocol
Power Wireless chime: 12 VAC / 12 VA or 24 VAC / 12 VA. Mechanical chime: 24 VAC / 26 VA
Installation Requirement Connect the mechanical chime before pressing the call button. Follow the manufacturer wiring guide to prevent damage.
Power Kit 240 mAh lithium battery for mechanical-chime power kit
Protection IP65
Operating Temperature −30°C to 60°C
Dimensions 55.8 × 156.5 × 27.9 mm
Weight 142 g net
Warranty (Australia) 3 years · CCTV Guru Australia

Downloads

Manufacturer specifications Datasheet Quick Guide

Frequently Asked Questions

Why are there two cameras?

3MP main visitor camera + 2MP ground/package camera. The downward camera helps monitor packages near the doorstep.

Is this a battery-only doorbell?

No. It requires wired AC power matched to the chime: Wireless chime: 12 VAC / 12 VA or 24 VAC / 12 VA. Mechanical chime: 24 VAC / 26 VA. The small battery belongs to the mechanical-chime power kit.

What should I check before installation?

Connect the mechanical chime before pressing the call button. Follow the manufacturer wiring guide to prevent damage.

Does it need a memory card?

It has 8 GB built-in eMMC storage.

Can I speak to visitors?

Yes. Its built-in microphone and speaker provide two-way audio using the compatible Uniview system.

Which wireless networks does it support?

Dual-band 2.4/5 GHz Wi-Fi 6 (802.11 b/g/n/ax); integrated BLE.

Is it weather resistant?

It is rated IP65 and operates from −30°C to 60°C. Seal and install it as directed.

3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
