Ubiquiti LOCOM5 · 5GHz Outdoor CPE · 13dBi MIMO · 10+ km · airMAX · PoE Included · Single Unit
⚠️ Single unit — not a pair. For a point-to-point (P2P) wireless link you need two units — one at each end. Add 2 to cart for a complete P2P bridge.
Ubiquiti NanoStation Loco M5 — 5GHz Outdoor CPE for Long-Range Wireless Links
The Ubiquiti NanoStation Loco M5 (LOCOM5) is one of the most widely deployed outdoor CPEs in Australia — and for good reason. It delivers 150Mbps throughput, a 13dBi integrated MIMO antenna, and 10+ km range in a compact, weatherproof housing that costs a fraction of enterprise wireless alternatives. Whether you’re bridging two buildings, extending a network to a remote shed, connecting a CCTV camera location back to a recorder, or building a WISP access point, the LocoM5 gets the job done reliably.
Operating on the 5GHz band with Ubiquiti’s airMAX TDMA protocol, the LocoM5 cuts through interference and delivers consistent, low-latency throughput even in congested RF environments. Managed via the airOS web interface or airControl, it’s straightforward to configure for station, access point, or bridge modes. PoE adapter included. Australian stock. Fast dispatch.
Frequency
5GHz · 802.11a/n
Australian Stock · Fast Dispatch
Expert Australian Tech Support
What’s in the Box
1 × Ubiquiti NanoStation Loco M5 (LOCOM5)5GHz outdoor CPE with integrated 13dBi dual-polarisation MIMO antenna. Weatherproof housing rated for outdoor deployment. Single unit — buy 2 for a complete P2P bridge.
1 × PoE Adapter (24V Passive)Ubiquiti 24V passive PoE injector included — powers the LocoM5 over the Ethernet cable run. No separate power supply required at the device end.
Mounting HardwarePole/wall mounting bracket and hardware included for standard outdoor installation. Compatible with the optional NS-WM window/wall mount for indoor-facing deployments.
Quick Start GuideUbiquiti quick start documentation. Full configuration is performed via the airOS web interface — accessible from any browser on the same network segment.
Key Features
5GHz Band — Less Interference, More ThroughputThe LocoM5 operates on the 5GHz band — far less congested than 2.4GHz in most Australian environments. Ideal for high-throughput applications like CCTV video streaming, VoIP, and data backhaul where interference from neighbouring Wi-Fi networks would degrade a 2.4GHz link.
13dBi Integrated MIMO Antenna — 10+ km RangeThe integrated 13dBi dual-polarisation MIMO antenna delivers strong, focused signal for long-range point-to-point links up to 10+ km in line-of-sight conditions. No external antenna required — the LocoM5 is a complete, self-contained unit.
airMAX TDMA — Low Latency, High EfficiencyUbiquiti’s proprietary airMAX TDMA protocol schedules transmissions to eliminate hidden node interference and reduce latency — even when multiple LocoM5 units share the same frequency. Essential for WISP deployments and multi-client access point scenarios.
Up to 150Mbps Real ThroughputDelivers up to 150Mbps of real-world throughput — more than sufficient for HD CCTV streams, VoIP, and general data backhaul across a wireless bridge. Actual throughput depends on distance, line of sight, and RF environment.
airOS Web Management — Simple ConfigurationConfigured via the airOS web interface — accessible from any browser. Supports station, access point, bridge, and router modes. Advanced users can also manage multiple units centrally via airControl. No proprietary software required for basic setup.
24V Passive PoE — Single Cable InstallationPowered by the included 24V passive PoE adapter — power and data travel over the same Ethernet cable, eliminating the need for a separate power outlet at the device location. Ideal for rooftop, pole, and remote installations.
Weatherproof Outdoor HousingThe LocoM5’s compact housing is designed for permanent outdoor deployment in Australian conditions — UV-stabilised, rain-resistant, and rated for operation from −30°C to +75°C. Suitable for coastal, tropical, and outback environments.
Compact CPE Form FactorSignificantly smaller and lighter than the full NanoStation M5, the LocoM5 is ideal for residential rooftops, small building deployments, and installations where a low-profile device is preferred. Easy to mount and aim.
Common Use Cases
Building-to-Building Wireless Bridge (P2P)Connect two buildings with a high-speed wireless link — office to warehouse, house to shed, main building to outbuilding. Buy 2 units — one configured as access point, one as station. Delivers up to 150Mbps over 10+ km line of sight.
CCTV Camera BackhaulStream HD CCTV footage from a remote camera location back to an NVR or DVR over a wireless link where cabling is impractical. The LocoM5’s 5GHz band handles multiple HD streams without congestion.
Rural & Remote Internet ExtensionExtend internet connectivity to a remote location — farm shed, granny flat, remote office, or caravan park amenities block — without trenching cable. Pair with a router at the remote end for full network access.
WISP Access Point / ClientDeploy as a WISP (Wireless Internet Service Provider) access point or subscriber CPE. airMAX TDMA handles multiple simultaneous clients efficiently with low latency and fair bandwidth allocation.
Construction Site & Temporary NetworksFast to deploy and easy to reposition — the LocoM5 is ideal for temporary wireless networks on construction sites, events, and remote worksites where permanent cabling is not viable.
Network Backhaul for Access PointsUse a LocoM5 pair to backhaul traffic from a remote Wi-Fi access point back to the main network switch — extending your network coverage without running cable.
Technical Specifications
Ubiquiti NanoStation Loco M5 — LOCOM5
| SKU |
LOCOM5 |
| Frequency Band |
5GHz (5.170 – 5.875 GHz) |
| Standard |
IEEE 802.11a/n |
| Antenna |
13dBi dual-polarisation MIMO · Integrated |
| Max Throughput |
Up to 150Mbps |
| Range |
10+ km (line of sight) |
| Protocol |
airMAX TDMA |
| Wireless Modes |
Station · Access Point · Bridge · Router |
| Management |
airOS web interface · airControl |
| Power |
24V passive PoE (adapter included) |
| Power Consumption |
Approx. 5.5W |
| Ethernet Port |
1 × 10/100 Mbps |
| Operating Temp |
−30°C to +75°C |
| Housing |
Outdoor weatherproof · UV-stabilised |
| Weight |
Approx. 520g (with mount) |
| In the Box |
LocoM5 unit · 24V PoE adapter · Mounting hardware · Quick start guide |
Frequently Asked Questions
Do I need one or two units for a wireless bridge?
You need two units for a point-to-point wireless bridge — one at each end. This listing is for a single unit only. Add 2 to cart for a complete P2P link. One unit is configured as an access point, the other as a station.
What is the maximum range of the LocoM5?
The LocoM5 can achieve 10+ km in clear line-of-sight conditions. Real-world range depends on terrain, obstructions, RF interference, and antenna alignment. For links over 5 km, precise alignment and a clear Fresnel zone are important.
What is the difference between the LocoM5 and the NanoStation M5?
The LocoM5 is smaller and has a 13dBi antenna, making it ideal for shorter to medium-range links and residential deployments. The NanoStation M5 has a higher-gain antenna and is better suited for longer links and higher-density WISP deployments. Both use airMAX TDMA.
Does the LocoM5 include a PoE adapter?
Yes — a 24V passive PoE adapter is included in the box. You do not need to purchase a separate PoE injector. Run a single Cat5e or Cat6 cable from the PoE adapter to the LocoM5.
Can I use the LocoM5 for CCTV camera backhaul?
Yes — the LocoM5 is widely used for CCTV backhaul in Australia. The 5GHz band handles multiple HD video streams without congestion. Pair two units to create a wireless link between a remote camera location and your NVR.
How do I configure the LocoM5?
Configuration is done via the airOS web interface — connect a laptop to the same network segment as the LocoM5 and access it via browser. The default IP is 192.168.1.20. No proprietary software is required for basic setup.
Is the LocoM5 compatible with other brands of wireless equipment?
The LocoM5 supports standard 802.11a/n, so it can connect to other 802.11a/n devices in standard Wi-Fi mode. However, airMAX TDMA features require both ends to be Ubiquiti airMAX devices for optimal performance.
Do you ship Australia-wide?
Yes — fast dispatch to every state and territory from Australian stock. Same-day dispatch on orders placed before 2pm AEST (business days).
Order the Ubiquiti NanoStation Loco M5 from CCTV Guru
CCTV Guru stocks the Ubiquiti NanoStation Loco M5 (LOCOM5) in Australia for fast nationwide dispatch. Whether you’re building a point-to-point wireless bridge, extending CCTV backhaul to a remote location, or deploying a WISP CPE, the LocoM5 delivers reliable 5GHz performance at an unbeatable price point. Need two for a P2P link? Add 2 to cart. Contact our Australian technical team for advice on link planning, antenna alignment, and airOS configuration.
