Description
TP-Link VIGI NVR2016H-16P 16-Channel PoE+ Network Video Recorder
Professional 16-Channel NVR Built for Australian Businesses
The TP-Link VIGI NVR2016H-16P is a purpose-built 16-channel PoE+ network video recorder designed for small to medium businesses across Australia. With 4K HDMI output, H.265+ compression, and 16 dedicated PoE+ ports, it simplifies IP camera deployment while delivering sharp, reliable surveillance around the clock.
Key Features
-
4K HDMI Output & 16MP Decoding: Supports up to 8MP (4K) resolution per camera with 8-channel simultaneous 2MP decoding for live view and playback.
-
16 × PoE+ Ports (90 W Total Budget): 802.3af/at-compliant ports power and connect IP cameras over a single Ethernet cable — no separate power adapters required.
-
16-Channel Simultaneous Playback: Review footage from all 16 cameras at once, with variable playback speed and timeline-based event search.
-
H.265+ Compression: Reduces file sizes significantly without compromising image quality, saving storage space and reducing network load.
-
ONVIF Compatibility: Integrates seamlessly with VIGI cameras and third-party ONVIF-compliant IP cameras for flexible system design.
-
Auto Initialise: One-click setup configures connected cameras and hard disk parameters, cutting installation time considerably.
-
24/7 Continuous Recording: Supports up to 20 TB of storage (up to 1,048 recording days) with customisable recording schedules.
-
Two-Way Audio: Built-in voice intercom lets you communicate through compatible cameras — ideal for deterring intruders remotely.
-
Remote Monitoring: Manage and view live feeds from anywhere via the VIGI app (iOS & Android) or desktop client.
Use Cases
-
Small Business Security: Ideal for retail shops, restaurants, warehouses, and financial institutions requiring reliable multi-camera coverage.
-
Commercial Installations: Suits professional CCTV installers deploying scalable IP camera systems with centralised management.
-
DIY Home Security: Straightforward setup and the VIGI app make it accessible for technically confident homeowners wanting professional-grade recording.
-
Remote Site Monitoring: Remote access via app or client enables monitoring of unmanned sites, storage facilities, and car parks.
Specifications
| Specification |
Detail |
| Model |
VIGI NVR2016H-16P |
| Channels |
16 |
| PoE Ports |
16 × 802.3af/at (PoE+) |
| Total PoE Budget |
90 W |
| Max Resolution |
8MP (4K) |
| Video Output |
HDMI (4K), VGA |
| Decoding Capacity |
16MP total; 8-ch @ 2MP |
| Simultaneous Playback |
16 channels |
| Video Compression |
H.265+, H.265, H.264+, H.264 |
| HDD Bays |
2 (up to 20 TB total) |
| Max Storage |
20 TB |
| Network Interface |
1 × RJ45 Gigabit Ethernet |
| Compatibility |
ONVIF, VIGI IP Cameras |
| Remote Access |
VIGI App (iOS & Android), VIGI Client (PC) |
| Two-Way Audio |
Yes (via compatible cameras) |
| Weight |
3.86 kg |
| Barcode (EAN) |
4895252504040 |
Downloads
Frequently Asked Questions
Does the NVR2016H-16P come with hard drives?
No, hard drives are sold separately. The unit supports up to two HDDs with a combined capacity of up to 20 TB. We recommend surveillance-grade drives such as Western Digital Purple or Seagate SkyHawk.
Can I use non-TP-Link cameras with this NVR?
Yes. The NVR2016H-16P supports ONVIF-compliant IP cameras from other manufacturers, giving you flexibility when designing or expanding your system.
How many cameras can I connect?
Up to 16 IP cameras can be connected simultaneously via the built-in PoE+ ports. Each port supports 802.3af/at standards, with a total PoE budget of 90 W shared across all ports.
Can I monitor cameras remotely?
Yes. The free VIGI app (available on iOS and Android) and the VIGI Security Manager desktop client allow remote live viewing, playback, and system management from anywhere with an internet connection.
What is the maximum storage capacity?
The NVR supports up to 20 TB of storage across two HDD bays, which can provide up to approximately 1,048 days of recording depending on camera resolution, frame rate, and compression settings.
Is this NVR suitable for outdoor use?
The NVR unit itself is designed for indoor installation. For outdoor surveillance, pair it with VIGI outdoor-rated IP cameras that connect back to the NVR via PoE cabling.
