TP-Link TL-SL1311MP 8-Port PoE+ Desktop Switch with Gigabit & SFP Uplinks
8-Port PoE+ Switch with Gigabit Uplinks & 250m Extend Mode
The TP-Link TL-SL1311MP is a compact desktop PoE+ switch with 8 Fast Ethernet PoE+ ports, 2 Gigabit RJ45 uplinks, and 1 Gigabit SFP uplink — all in a fanless, plug-and-play form factor. With a 124 W total PoE budget, up to 30 W per port, Extend Mode for PoE transmission up to 250 m, and PoE Auto Recovery, it’s a practical and cost-effective solution for powering IP cameras, VoIP phones, and wireless access points in small Australian business and residential installations.
Key Features
- 8 × 10/100 Mbps PoE+ ports — 802.3af/at compliant, up to 30 W per port
- 124 W total PoE budget across all 8 ports
- 2 × Gigabit RJ45 uplink ports + 1 × Gigabit SFP uplink port
- Extend Mode — extends PoE data and power transmission up to 250 m at 10 Mbps (ports 1–4 or 1–8)
- PoE Auto Recovery — automatically reboots unresponsive PoE devices without manual intervention
- Isolation Mode — one-click client traffic separation for improved security and performance
- Fanless design — silent operation, suitable for offices, reception areas, and noise-sensitive environments
- Plug-and-play — no configuration or software required
- Physical security lock — prevents unauthorised removal
- 7.6 Gbps switching capacity, 5.6544 Mpps forwarding rate
- 16 KB Jumbo Frame support
Use Cases
-
IP CCTV Systems: Power and connect up to 8 PoE IP cameras without separate power supplies. Use Extend Mode to push PoE up to 250 m for remote camera positions.
-
Small Office Networks: Connect PoE VoIP phones and wireless access points while using the Gigabit uplinks to connect to a core switch or router.
-
Wireless Access Points: Deploy PoE-powered APs throughout a small office or retail space without additional power cabling.
-
Retail & Hospitality: Isolation Mode separates guest and staff device traffic on the same switch for improved security.
-
Fibre Uplink Installations: The Gigabit SFP port allows connection to a fibre uplink or fibre-connected core switch for longer-distance backbone runs.
Specifications
| Specification |
Detail |
| Model |
TL-SL1311MP |
| PoE Ports |
8 × 10/100 Mbps RJ45 (802.3af/at PoE+) |
| Uplink Ports |
2 × Gigabit RJ45 + 1 × Gigabit SFP |
| PoE Power Per Port |
Up to 30 W |
| Total PoE Budget |
124 W |
| Extend Mode |
Up to 250 m @ 10 Mbps (ports 1–4 or 1–8) |
| Switching Capacity |
7.6 Gbps |
| Packet Forwarding Rate |
5.6544 Mpps |
| MAC Address Table |
2K |
| Jumbo Frame |
16 KB |
| Transfer Method |
Store-and-Forward |
| Power Supply |
External adapter — 53.5 V DC / 2.43 A |
| Max Power Consumption |
5.95 W (no PoE load) / 140.92 W (full 124 W PoE load) |
| Cooling |
Fanless |
| Dimensions (W × D × H) |
209 × 126 × 26 mm |
| Weight |
1.56 kg |
| Physical Security Lock |
Yes |
Frequently Asked Questions
How many PoE cameras can I connect to the TL-SL1311MP?
Up to 8 PoE-powered devices on ports 1–8. The total PoE budget is 124 W — if each camera draws 15 W, all 8 ports can run simultaneously. Higher-draw devices (e.g., PTZ cameras at 25–30 W) will reduce the number of simultaneous powered ports. Plan your PoE budget based on the actual wattage of your connected devices.
What is Extend Mode and when should I use it?
Extend Mode reduces port speed to 10 Mbps to extend PoE data and power transmission up to 250 m. It is useful for remote camera positions where the cable run exceeds the standard 100 m Ethernet limit. Activate it via the hardware button on the switch — it can be applied to ports 1–4 or ports 1–8.
What is PoE Auto Recovery?
PoE Auto Recovery monitors connected PoE devices and automatically power-cycles any device that becomes unresponsive — similar to unplugging and replugging the device. This is particularly useful for IP cameras or access points that may occasionally freeze or lock up, reducing the need for on-site intervention.
What is Isolation Mode?
Isolation Mode separates client traffic between PoE ports so that devices connected to different ports cannot communicate directly with each other — only with the uplink. This improves security in environments where you don’t want devices to see each other, such as guest Wi-Fi APs or public-facing kiosks.
Can I use the SFP port for a fibre uplink?
Yes. The Gigabit SFP port accepts standard SFP MSA-compliant transceivers, including TP-Link’s SM311LS (single-mode, 10 km) and compatible multi-mode modules, allowing you to connect the switch to a fibre-based core switch or backbone over longer distances.
