Description
8-Port Gigabit PoE+ Smart Switching for Small Business and Installers
The TP-Link Omada ES208GP is an 8-port Gigabit PoE+ Easy Smart Switch with a 65W PoE power budget, designed for small businesses, installers, and home office environments that need to power and connect access points, IP cameras, VoIP phones, and other PoE devices without the complexity of a fully managed switch.
Combining 802.3at PoE+ on all eight ports with essential smart features — including 802.1Q VLAN, QoS, IGMP snooping, and loop prevention — the ES208GP delivers the right balance of capability and simplicity for everyday network deployments.
Key Features
- 8× Gigabit RJ45 PoE+ ports — IEEE 802.3at/af compliant, up to 30W per port
- 65W total PoE power budget for powering multiple devices simultaneously
- 802.1Q VLAN support for network segmentation (up to 32 VLANs)
- QoS (Quality of Service) — 802.1p, DSCP, and port-based traffic prioritisation
- IGMP snooping v1/v2 for efficient multicast traffic management
- Loop prevention to protect against broadcast storms
- Web-based management interface — no software installation required
- Plug-and-play with optional browser-based configuration
- Fanless, silent operation — suitable for office, retail, and home environments
- Desktop metal housing with LED indicators per port
- IEEE 802.3x flow control for reliable data transfer
Use Cases
-
Wi-Fi Access Point Deployment: Power and connect Omada EAP access points directly from the switch — no separate PoE injectors required.
-
IP Camera & CCTV Networks: Power up to eight IP cameras from a single switch, with VLAN support to isolate surveillance traffic from the main business network.
-
VoIP Phone Systems: Power and prioritise VoIP handsets using 802.1p QoS to ensure consistent call quality.
-
Small Business Networks: Segment staff, guest, and IoT device traffic onto separate VLANs without the cost or complexity of a full managed switch.
-
Retail & Hospitality: Power POS terminals, access points, and IP cameras from a single compact switch while keeping network traffic logically separated.
-
Home Office & Power Users: Eliminate PoE injector clutter by powering all PoE devices directly from one switch with smart traffic management.
Technical Specifications
| Specification |
Detail |
| Model |
ES208GP |
| Ports |
8× 10/100/1000 Mbps Gigabit RJ45 (all PoE+) |
| PoE Standard |
IEEE 802.3at (PoE+), backward compatible with 802.3af |
| PoE Power per Port |
Up to 30W |
| Total PoE Budget |
65W |
| Switching Capacity |
16 Gbps |
| Forwarding Rate |
11.9 Mpps |
| MAC Address Table |
4K |
| Packet Buffer |
4 Mbit |
| Jumbo Frame |
Up to 9216 bytes |
| VLAN |
802.1Q VLAN, Port-based VLAN (up to 32 VLANs) |
| QoS |
802.1p, DSCP, Port-based |
| IGMP Snooping |
v1, v2 |
| Loop Prevention |
Yes |
| Flow Control |
IEEE 802.3x |
| Management |
Web-based GUI (browser) |
| Power Input |
AC 100–240V, 50/60 Hz (AU plug) |
| Max Power Consumption |
78.18W (with full PoE load) |
| Fanless |
Yes — silent operation |
| Operating Temperature |
0°C to 40°C |
| Form Factor |
Desktop, metal housing |
| Certifications |
CE, RoHS, FCC |
| In the Box |
ES208GP switch, power cord, quick installation guide |
Recommended Accessories & Compatible Products
-
Omada EAP670 (AX5400 Wi-Fi 6 Access Point): Power and connect directly from the ES208GP — no PoE injector needed
-
Omada EAP225 (AC1350 Wi-Fi 5 Access Point): Budget-friendly 802.3af access point compatible with all ES208GP PoE ports
-
Omada ES208G (8-Port Gigabit Easy Smart Switch, non-PoE): Non-PoE sibling for locations where PoE is not required
-
Omada TL-SG2210MP (8-Port Smart Switch with PoE+): Step up to a fully managed switch with higher PoE budget and advanced features
-
Omada MC212CS Gigabit Media Converter: Add a fibre uplink to your ES208GP-based network for longer backbone runs
-
Cat6 Patch Cables: Ensure full Gigabit and PoE performance with quality patch leads
Downloads
Frequently Asked Questions
Can all 8 ports deliver PoE+ power simultaneously?
Yes, all eight ports support 802.3at PoE+ (up to 30W per port). However, the total PoE power budget is 65W shared across all ports. If all eight ports are in use, the average available power per port is approximately 8W. For deployments requiring higher per-port power, plan your device power draw against the 65W budget accordingly — for example, four 15W devices would consume 60W, leaving 5W for additional low-power devices.
What is the difference between the ES208GP and the ES208G?
The ES208GP adds PoE+ (802.3at) power delivery on all eight ports with a 65W budget, allowing you to power access points, IP cameras, and VoIP phones directly from the switch. The ES208G is a non-PoE version with identical smart switching features but no power delivery. Choose the ES208GP if any of your connected devices require PoE power.
Does the ES208GP support Omada SDN or cloud management?
No. The ES208GP is managed via a local web browser interface only and does not support the Omada SDN Controller or Omada Cloud management. For centralised cloud or controller-based management, consider the Omada TL-SG2210MP or a switch from the TL-SG2xxx/TL-SG3xxx managed series.
How many access points can I power from the ES208GP?
This depends on the power draw of each access point. A typical Omada EAP225 (802.3af) draws around 12.95W, meaning you could power up to four simultaneously within the 65W budget with headroom to spare. Higher-power APs such as the EAP670 (802.3at, up to 22W) would allow up to two or three units before approaching the budget limit. Always check the PoE draw of your specific devices before planning the deployment.
Is the ES208GP fanless and suitable for quiet environments?
Yes. The ES208GP operates without a fan, making it completely silent — ideal for office desks, reception areas, retail counters, and home environments where fan noise would be disruptive.
Can I use the ES208GP with non-TP-Link PoE devices?
Yes. The ES208GP is compliant with IEEE 802.3at (PoE+) and 802.3af standards, making it compatible with any standards-compliant PoE-powered device regardless of brand — including third-party access points, IP cameras, VoIP phones, and IoT devices.
