Does the TSW010 require any configuration?
No. The TSW010 is fully unmanaged — no web interface, no software, and no setup required. Connect power, plug in your devices, and it works immediately.
What power supply does the TSW010 use?
The TSW010 accepts 9–30 V DC via a 2-pin connector, compatible with most industrial DIN rail power supplies. A suitable AU power supply is available separately in the Teltonika accessories range.
Can I use the TSW010 with a Teltonika router?
Absolutely. The TSW010 is designed to complement Teltonika routers such as the RUT241, RUTX11, and RUTX50, forming a compact DIN rail-mounted networking solution ideal for CCTV cabinets and industrial enclosures.
Is the TSW010 suitable for harsh or outdoor environments?
The TSW010 is rated for −40 °C to +75 °C and features anodised aluminium housing, making it well-suited for industrial enclosures. It is not rated for direct outdoor exposure without an appropriate IP-rated enclosure.
Does the TSW010 support PoE?
No. The TSW010 does not support Power over Ethernet. For PoE switching, consider the Teltonika TSW101 or TSW110 from the CCTV Guru Teltonika range.
How many devices can I connect to the TSW010?
Up to five devices via the five RJ45 ports. For larger installations, multiple TSW010 units can be daisy-chained or a larger Teltonika switch such as the TSW110 or TSW200 can be used.
Will the TSW010 work with Hikvision, Dahua, or Uniview cameras?
Yes. The TSW010 provides standard 10/100 Mbps Ethernet connectivity compatible with all major IP camera brands including Hikvision, Dahua, Uniview, and Tiandy.
Is the TSW010 RCM certified for Australia?
Yes. The TSW010 carries CE and RCM certification, confirming compliance with Australian electromagnetic compatibility and electrical safety requirements.
