Hikvision DS-2CD3766G2HT-LIZSUY 6MP DarkFighter Varifocal Dome IP Camera

Description

Hikvision ULTRA SERIES

Next-Generation 6MP Commercial Intelligence & Low-Light Performance

The DS-2CD3766G2HT-LIZSUY represents Hikvision's flagship Ultra Series engineering, engineered specifically for high-demand commercial environments, critical infrastructure, and harsh perimeter deployments. Combining a high-definition 6MP sensor with Hikvision DarkFighter technology, this motorized varifocal dome camera delivers exceptional image clarity even in near-total darkness. Enhanced by AcuSense deep-learning algorithms, it accurately classifies human and vehicle targets to dramatically reduce false alarms, making it the ideal security anchor for enterprise sites, transportation hubs, and industrial facilities.

Resolution & Imaging
6MP Ultra HD (3200 × 1800)
Optics & Zoom
2.8–12mm Motorized Varifocal
Night Vision Technology
Smart Hybrid Light (IR & White)
Protection & Climate
IP67 / IK10 / NEMA 4X

Advanced Smart Hybrid Illumination & Environmental Resilience

Designed to adapt dynamically to changing surveillance conditions, the Hikvision DS-2CD3766G2HT-LIZSUY integrates Smart Hybrid Light technology, allowing operators to choose between covert Infrared, full-color supplemental white light, or intelligent event-triggered illumination mode. Equipped with dynamic 140 dB Wide Dynamic Range (WDR), this model handles severe backlighting and extreme contrast effortlessly. Furthermore, its specialized anti-corrosion coating (NEMA 4X certified) ensures extreme durability against harsh chemicals, saltwater environments, and demanding outdoor climates while maintaining vandal resistance via its IK10 housing.

AcuSense Deep Learning Analytics

Utilizes advanced deep-learning hardware algorithms to distinguish humans and vehicles from benign motion sources like rain, leaves, or animals. Detections trigger precise alerts and streamline post-event investigation searching.

NEMA 4X Anti-Corrosion Protection

Engineered with specialized protective anti-corrosion treatment meeting NEMA 4X standard specifications. Safeguards internal components against corrosive maritime atmospheres, chemical environments, and extreme weather.

Smart Hybrid Light System

Offers three flexible light modes: discrete IR illumination for long-range night monitoring, bright white light for visual deterrence and full-color recording, or Smart Mode which automatically switches IR to white light upon target detection.

Efficient H.265+ Compression & Storage

Optimizes bandwidth utilization and storage consumption by up to 75% compared to standard H.264 without sacrificing image quality. Includes onboard microSD storage expansion up to 512 GB for redundant local retention.

Technical Specification Matrix
Camera Model DS-2CD3766G2HT-LIZSUY
Max. Resolution 6 Megapixel (3200 × 1800 @ 30 fps)
Image Sensor 1/1.8" Progressive Scan CMOS (DarkFighter)
Lens & FoV 2.8 to 12 mm Motorized Varifocal Lens; Horizontal FoV 108.8° to 44.2°
Supplemental Light Range IR Range: Up to 40 m; White Light Range: Up to 40 m
Wide Dynamic Range (WDR) 140 dB WDR (True Wide Dynamic Range)
Video Compression H.265+ / H.265 / H.264+ / H.264 / MJPEG
Audio & Alarm Interfaces Built-in Microphone; 1 Audio Input / 1 Output; 1 Alarm Input / 1 Output
On-Board Storage Built-in microSD/SDHC/SDXC slot, up to 512 GB
Protection Standards IP67 (Water & Dust), IK10 (Vandal Resistance), NEMA 4X (Anti-Corrosion)
Power Supply & Output 12 VDC ± 25% or PoE (802.3af, Class 3)
How does Smart Hybrid Light technology operate?

Smart Hybrid Light allows you to select between standard IR night vision, continuous full-color white light, or Smart Mode. In Smart Mode, the camera operates silently using invisible IR light until a human or vehicle is detected by AcuSense, at which point it activates visible white light to capture full-color evidence and deter intruders.

What benefits does the NEMA 4X anti-corrosion rating provide?

The NEMA 4X rating guarantees that the camera housing features special surface coatings and anti-corrosive treatments designed to withstand harsh elements such as salt spray, chemical airborne pollutants, and intense moisture, ensuring long-term hardware longevity in coastal or industrial settings.

How does the motorized varifocal lens function remotely?

The 2.8mm to 12mm motorized zoom lens allows security administrators to easily adjust the field of view and focal point remotely via the Hikvision Web Browser interface, iVMS-4200, or NVR software without requiring physical access to the camera mounting location.

Does this camera support built-in audio recording?

Yes, the DS-2CD3766G2HT-LIZSUY includes a high-sensitivity built-in microphone for real-time audio security monitoring along with physical external audio input and output terminal ports for two-way audio applications.

Technical Datasheet User Manual
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery
