Dahua ARM7012-W2 Wireless WallSwitch Smart Alarm Relay Module 13A 240V for Dahua Wireless Alarm Systems

Description

Dahua Wireless WallSwitch

Dahua DHI-ARM7012-W2 Wireless WallSwitch Smart Relay

The Dahua DHI-ARM7012-W2 Wireless WallSwitch is a compact smart power switch for compatible Dahua wireless alarm systems, designed to remotely control 100–240VAC power while monitoring voltage, current and energy consumption.

Why Choose the Dahua ARM7012-W2?

⚡ Remote Power Control

Remotely controls 100–240VAC power through the built-in relay.

📊 Energy Monitoring

Monitors voltage, current and power consumption.

🔐 Secure Communication

Supports AES128 encryption and jamming detection.

📡 Stable Wireless Link

Frequency hopping and two-way communication help maintain stability.

🛡 Built-in Protection

Includes protection against overvoltage, overload and overheating.

☁ Cloud Update

Supports cloud updates and automatic recovery if an update fails.

Technical Specifications

Specification Details
Model DHI-ARM7012-W2
Product Type Dahua Wireless WallSwitch
Relay Output 1 × NO/NC, 100–240VAC, Max 13A
Power Supply 100–240VAC, 50/60Hz
Carrier Frequency 433.1MHz–434.6MHz
Communication Two-way wireless communication
Wireless Distance Up to 800m in open areas
Encryption AES128
Frequency Hopping Yes
Jamming Detection Supported
Protection Overvoltage, overload and overheating protection
Monitoring Voltage, current and energy consumption
Operating Temperature -10°C to +55°C indoor
Dimensions 39mm × 33mm × 19mm
Installation Wall mount
Certification CE

Downloads

Resource Link
Dahua DHI-ARM7012-W2 Datasheet Download PDF

Frequently Asked Questions

What does the Dahua ARM7012-W2 do?
It remotely controls 100–240VAC power through a built-in relay and can monitor voltage, current and energy consumption.

Does it support 240V power?
Yes. It supports 100–240VAC, 50/60Hz power input.

What is the maximum relay output?
The relay output supports up to 13A maximum load.

Is it suitable for outdoor installation?
No. The datasheet lists the operating environment as indoor.

Does it work with Dahua wireless alarm systems?
Yes. It communicates wirelessly with compatible Dahua alarm hubs using RF433.

Upgrade Your Dahua Wireless Alarm System

Add remote power control, energy monitoring and secure wireless relay switching to your Dahua alarm setup.

Shop Dahua Alarm Systems
Australian Support
Fast Shipping
Installer Friendly

Dahua ARM7012-W2 Wireless WallSwitch Smart Alarm Relay Module 13A 240V for Dahua Wireless Alarm Systems
