AXIS Q63 SERIES · NDAA & TAA COMPLIANT
Ultra-high-definition precision tracking with lightning-fast laser focus
The AXIS Q6358-LE sets a new standard for high-tier long-range surveillance by combining breathtaking 4K UHD resolution with an aggressive 31x optical zoom. Engineered with an advanced 1/2" sensor and a dedicated laser focus system, this powerhouse tracking asset achieves pin-sharp alignment in milliseconds, even in complete darkness or fast-moving tactical scenarios. Designed specifically for critical infrastructure, airports, border control, and wide city spaces, it transforms sprawling perimeters into perfectly clear forensic data zones.
Resolution
4K UHD @ 30 FPS
Night Vision
OptimizedIR Zoom
Climate Ready
IP66 & NEMA 4X
Uncompromising analytics processing at the secure network edge
Built on the next-generation ARTPEC-8 chip architecture, the AXIS Q6358-LE runs a highly specialized Deep Learning Processing Unit (DLPU). This allows the camera to deliver granular, real-time object classification to easily distinguish between vehicles and humans. The system features a built-in cryptographic hardware engine running AXIS Edge Vault. This ensures safe cryptographic keys, secure boot validation, and a verified physical identity signature to defend enterprise networks from unauthorized zero-day configuration attempts.
Adaptive OptimizedIR illumination
The highly responsive built-in infrared illumination automatically tracks the focal depth of the 31x zoom lens system, delivering optimal lighting parameters over incredible distances without washing out close-range subjects.
Laser focus distance mapping
By throwing out an eye-safe laser pulse to measure absolute physical distances, the focus tracking elements lock onto vehicles or humans instantly. This removes the common contrast focus lag found in dark or low-visibility outdoor environments.
Technical Specification Matrix
| Camera Model |
AXIS Q6358-LE |
| Image Sensor |
1/2” progressive scan RGB CMOS |
| Optical Lens Array |
6.9–214 mm, F1.35–4.6 with 31x optical zoom and laser autofocus |
| PTZ Coverage |
360° endless pan; -20° to +90° tilt with auto-flip tracking mechanics |
| Resolution Target |
4K Ultra HD (3840 x 2160 pixels) at up to 30 frames per second |
| Low-Light Metrics |
Lightfinder 2.0; Forensic WDR; OptimizedIR coverage up to 200m+ (650ft) |
| Cybersecurity Suite |
AXIS Edge Vault, Signed Firmware, Secure Boot, FIPS 140-2 level 3 storage |
| Enclosure Ratings |
IP66, IP67, NEMA 4X, IK10 impact armor rating |
Frequently Asked Questions
What are the operational safety benefits of the laser focus engine?
Traditional PTZ tracking systems rely on visual pixel contrast to calculate focus, which often fails in low contrast, thick mist, or dark environments. The AXIS Q6358-LE uses a dedicated laser rangefinder to map target distance instantly, providing perfect focus under any condition.
Does the camera support tilt profiles above the horizon line?
Yes. The camera frame layout provides an extended tilt profile ranging up to +90 degrees. This allows operators to look straight up into high elevations, bridges, and multi-tier industrial infrastructures without blind spots.
Can the AXIS Q6358-LE withstand freezing and scorching environments?
Absolutely. The hard shell enclosure features active temperature control and weather sealing, enabling the internal PTZ mechanics to run smoothly in temperatures between -50 °C to 50 °C (-58 °F to 122 °F).
What power supply options are required for operation?
The unit requires High Power over Ethernet (High PoE) or 60W PoE injectors complying with standard 802.3at/bt power distribution architectures to run the built-in sensor, motorized mechanisms, and heater components.
