Axis Q6225-LE 1080p 31x PTZ Camera with IR (02316-006)

Description

NDAA Compliant • 1080p 31x PTZ • Long-Range IR

AXIS Q6225-LE 50 Hz (02316-006) — Australian Stock & 5-Year Warranty

The AXIS Q6225-LE is a heavy-duty outdoor PTZ engineered for the harshest sites. It pairs HDTV 1080p and a larger 1/2″ sensor with 31x optical zoom and long-range OptimizedIR reaching 400 m, so it sees clearly in total darkness across vast distances. MIL-STD-810G and NEMA TS 2 certified, IK10 vandal-rated and able to withstand wind up to 245 km/h, it combines Lightfinder, Forensic WDR up to 120 dB, Autotracking 2 and electronic image stabilisation for reliable, actionable footage in extreme conditions.

Optical Zoom
31x (372x total)
IR Range
Up to 400 m
Durability
MIL-STD-810G
Tracking
Autotracking 2

Long-range vision built to survive anything

With 360° endless pan and a full -90° to +90° tilt at speeds up to 150°/s plus 300 presets, the Q6225-LE covers expansive perimeters from a single mounting point. Long-range OptimizedIR illuminates targets up to 400 m away, while a silicone wiper keeps the lens clear in rain and dust. Built-in AXIS Object Analytics and Autotracking 2 detect and follow people and vehicles automatically, and the rugged aluminium IP66/IP68 casing keeps running from -50 °C to 55 °C.

Long-Range OptimizedIR

Power-efficient 850 nm LEDs reach 400 m or more, delivering 0 lux night vision over long distances.

31x Optical Zoom

6.91–214.64 mm lens with autofocus and P-iris brings distant subjects into sharp focus.

Military-Grade Build

MIL-STD-810G, NEMA TS 2, IK10 and IP66/IP68 with wind resistance to 245 km/h.

Smart Detection

AXIS Object Analytics and Autotracking 2 classify and follow humans and vehicles in real time.

Technical Specifications

Camera & Lens
Image Sensor 1/2″ progressive scan CMOS
Resolution HDTV 1080p (1920×1080) to 320×180
Lens 6.91–214.64 mm, F1.36–F4.6, autofocus, P-iris
Field of View 63.8°–2.2° horizontal
Zoom 31x optical, 12x digital
Frame Rate Up to 50/60 fps in all resolutions
Min. Illumination Colour 0.05 lux; B/W 0.001 lux; 0 lux with IR on
WDR Forensic WDR up to 120 dB depending on scene
Light Technology Axis Lightfinder 2.0
Stabilisation Electronic Image Stabilization (EIS)
IR & PTZ
IR Illumination OptimizedIR 850 nm LEDs, range up to 400 m
Pan 360° endless, 0.05°/s to 150°/s
Tilt -90° to +90°, 0.05°/s to 150°/s
Presets 300 preset positions, preset accuracy 0.10°
Tours Tour recording, guard tour, control queue, orientation aid
Autotracking Autotracking 2
Analytics, Audio & Video
Compression H.264, H.265, Motion JPEG; Axis Zipstream
Included Analytics AXIS Object Analytics, Scene Metadata, Video Motion Detection, autotracking, gatekeeper
Supported Analytics AXIS Perimeter Defender, AXIS License Plate Verifier
Audio Two-way full duplex via speaker pairing / portcast; audio detection
I/O Alarm inputs/outputs via API; supports network share & SD recording
Network, Power & Storage
Power High PoE IEEE 802.3bt Type 4, max 90 W (midspan included); typical 16 W, max 71 W
Connectors RJ45 10/100/1000BASE-T PoE
Local Storage SD/SDHC/SDXC with AES-XTS 256-bit encryption; NAS recording
ONVIF Profile G, Profile M, Profile S, Profile T
Cybersecurity Signed OS, secure boot, TPM 2.0, FIPS 140-2 Level 2, Axis Edge Vault
Environmental
Ratings IP66/IP68, NEMA 4X, NEMA TS 2, IK10, MIL-STD-810G
Operating Temp. -50 °C to 55 °C (full power); Arctic startup to -40 °C
Wind Resistance Sustained up to 245 km/h (150 mph)
Casing Aluminium with silicone wiper; PVC free; urban grey
Dimensions / Weight 210 × 330 × 313 mm; 8.7 kg
Warranty 5-year Axis warranty (Australian stock)

Downloads

AXIS Q6225-LE DatasheetAxis PTZ Camera Quick Start GuideAxis PTZ Camera User Manual

Frequently Asked Questions

How far does the Q6225-LE see at night?

Its long-range OptimizedIR reaches up to 400 m (1300 ft) or more depending on the scene, giving 0 lux night vision over long distances.

What zoom and resolution does it offer?

HDTV 1080p (1920×1080) with 31x optical zoom and 12x digital, on a larger 1/2″ sensor for stronger low-light performance.

How tough is this camera?

It is MIL-STD-810G and NEMA TS 2 compliant, IK10 vandal-rated, IP66/IP68 sealed, and tested to withstand wind up to 245 km/h.

What is the pan and tilt range?

360° endless pan and -90° to +90° tilt at up to 150°/s, with 300 preset positions and 0.10° preset accuracy.

What power does it require?

High PoE (IEEE 802.3bt Type 4, max 90 W). A 90 W midspan is included; camera draw is typically 16 W, max 71 W.

Does it track and detect automatically?

Yes. Autotracking 2 plus AXIS Object Analytics detect and follow people and vehicles, and it supports AXIS License Plate Verifier and Perimeter Defender.

Is it NDAA and TAA compliant?

Yes. As an Axis Communications camera it is NDAA Section 889 and TAA compliant, suitable for government and critical-infrastructure deployments.

Which ONVIF profiles are supported?

ONVIF Profile G, M, S and T, ensuring broad compatibility with third-party VMS platforms.

What warranty applies in Australia?

Axis provides a 5-year warranty. CCTV Guru supplies genuine Australian stock (50 Hz, P/N 02316-006) with local tech support.

5-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support

Axis Q6225-LE 1080p 31x PTZ Camera with IR (02316-006)

Product form

SKU: 02316-006

$6,500.00 Incl. GST

    • PayPal
    • Apple Pay
    • Visa
    • Mastercard
    • American Express
    • Zip
    • Afterpay

    Add Ons & Accessories

    • Warranty: 60 months
    • 30 day Money Back Guarantee
    • Australian Stocks & Express Delivery
    • Back-to-base Warranty & Tech Support
    • FREE Shipping over $180
