NDAA Compliant • Palm-Sized Indoor PTZAXIS M5075 (02346-001) — Australian Stock & 5-Year Warranty
The AXIS M5075 is a discreet, palm-sized PTZ camera that fits in almost anywhere while delivering sharp HDTV 1080p video. With 5x optical zoom plus 12x digital zoom you get sweeping overviews and the ability to zoom in for detail, and a built-in microphone with scream detection adds audio awareness to this plug-and-play camera.
Zoom
5x Optical, 12x Digital
Frame Rate
Up to 50/60 fps
Discreet PTZ for Tight Spaces
Measuring just ø130 x 63 mm and weighing 380 g, the AXIS M5075 brings full pan/tilt/zoom coverage to spaces where a full-size PTZ would be too obtrusive — boutique retail, hospitality, healthcare and small offices. It pans ±179° and tilts 90° at 100°/s, with autofocus and WDR keeping every scene crisp, and Axis Zipstream cutting bandwidth and storage without sacrificing detail.
Autofocus & WDR
A varifocal 2.2–11 mm F1.4 lens with autofocus and wide dynamic range delivers sharp, well-balanced images down to 0.1 lux, even in scenes mixing bright windows and shadow.
Built-In Microphone & Analytics
An integrated microphone enables AXIS Scream Detection and audio detection, alongside Video Motion Detection, active tampering alarm, gatekeeper and AXIS Removed Object Detection.
Plug-and-Play Edge Recording
Records to a microSD/SDHC/SDXC card with AES-XTS 256-bit encryption or to NAS, with a quick plug-and-play install aided by a leveling assistant and pixel counter.
Built-In Cybersecurity
Signed OS, secure boot, brute-force delay protection, IEEE 802.1X and HTTPS/HSTS help prevent unauthorized access and keep your system protected.
Technical Specifications
Camera & Lens
| Image Sensor |
1/2.8″ progressive scan RGB CMOS |
| Lens |
Varifocal 2.2–11.0 mm, F1.4–F2.5, autofocus |
| Field of View |
Horizontal 14°–71°, vertical 8°–40° |
| Min. Illumination |
0.1 lux at 30 IRE F1.4 (colour) |
| WDR |
Wide dynamic range |
Pan / Tilt / Zoom
| Pan |
±179° at 100°/s |
| Tilt |
90° at 100°/s |
| Zoom |
5x optical, 12x digital |
| Presets |
256 preset positions, control queue, on-screen directional indicator, focus recall |
Video
| Compression |
H.265 & H.264 (Main/High/Baseline), Motion JPEG, Axis Zipstream |
| Resolution |
1920x1080 to 320x180 (16:9) |
| Frame Rate |
Up to 50/60 fps in all resolutions |
| SoC |
ARTPEC-7, 1024 MB RAM, 512 MB Flash |
Audio, Analytics & Integration
| Audio |
One-way, built-in microphone |
| Analytics |
AXIS Scream Detection, Video Motion Detection, audio detection, active tampering alarm, gatekeeper, Removed Object Detection, ACAP |
| ONVIF |
Profile G, M, S and T |
| Cybersecurity |
Signed OS, secure boot, brute-force delay protection, IEEE 802.1X, HTTPS/HSTS |
Power, Storage & General
| Power |
PoE IEEE 802.3af/802.3at Type 1 Class 3 (typ. 4.2 W, max 9.3 W) |
| Connectors |
RJ45 10BASE-T/100BASE-TX PoE |
| Storage |
microSD/SDHC/SDXC with AES-XTS 256-bit encryption, NAS support |
| Casing |
IP51-rated, PVC free, clear dome, white |
| Operating Temp |
0 °C to 45 °C (32 °F to 113 °F) |
| Dimensions / Weight |
ø130 x 63 mm / 380 g |
| Part Number |
02346-001 |
Downloads
Frequently Asked Questions
How small is the AXIS M5075?It is a palm-sized PTZ measuring just ø130 x 63 mm and weighing 380 g, designed to be discreet in tight or sensitive indoor spaces.
What resolution and zoom does it offer?It streams HDTV 1080p (1920x1080) with 5x optical zoom plus 12x digital zoom, at up to 50/60 fps in all resolutions.
Does it have a microphone?Yes. It has a built-in microphone for one-way audio, enabling AXIS Scream Detection and audio detection analytics.
What is the pan and tilt range?It pans ±179° and tilts 90°, both at 100°/s, with 256 preset positions and focus recall.
What power does it use?It is powered over Ethernet (IEEE 802.3af/802.3at Type 1 Class 3), drawing typically 4.2 W and a maximum of 9.3 W.
Is the AXIS M5075 NDAA compliant?Yes. As an Axis Communications product it is NDAA Section 889 and TAA compliant for government and enterprise use.
Is it suitable for outdoor use?No. The M5075 is an indoor camera rated IP51, designed to operate from 0 °C to 45 °C in protected environments.
Does it record to a memory card?Yes. It supports microSD/SDHC/SDXC cards with AES-XTS 256-bit encryption, plus recording to network-attached storage (NAS).
What warranty applies in Australia?Genuine Axis stock from CCTV Guru includes a 5-year Australian warranty backed by local tech support.
