IDIS AV20576RS 20MP Multi-Sensor Remote Setup Omni-Directional IP Camera

Description

IDIS CONTERAIP OMNI LX SERIES · NDAA & TAA COMPLIANT

Zero-Touch 360-Degree Panoramic Security with Remote Setup

The IDIS AV20576RS redefines enterprise-grade panoramic surveillance by packing four independent 5MP motorized sensor streams into a single structural dome architecture. Delivering a combined 20MP ultra-high-definition field of view over one network line, this cutting-edge multi-sensor system is built for critical commercial environments including airport terminals, corporate campuses, logistics hubs, and massive retail intersections. Engineered with a game-changing "No Touch Setup" mechanical ecosystem, technicians can track, position, and focus all four independent internal camera gimbals remotely across a 360-degree rail track, eliminating physical configuration labor entirely.

Resolution
20MP (5MP x 4) Ultra HD
Optics
4x Motorized 3.3-6.6mm Lenses
Night Vision
NightView™ Low-Light Technology
Protection
IP66 Weather & IK10 Vandal

Unparalleled Bandwidth Optimization & Smart Edge Analytics

The operational intelligence inside the IDIS AV20576RS utilizes advanced on-camera processing frameworks to balance maximum multi-angle capture with system efficiency. Backed by proprietary SNAPstream+™ compression engines, the camera intelligently trims data load profiles by dynamically adapting to scene movement, slashing enterprise storage footprints and data transmission rates by over 50% without dropping pixel-density fidelity. Each individual sensor features independent DOL True Wide Dynamic Range (120dB WDR) and a native suite of standard video diagnostics, such as line crossing, loitering, intrusion detection, and camera tamper alerts. This ensures strict federal regulatory profile compliance for major critical infrastructure builds.

No Touch Remote Configuration

Eliminate costly bucket truck callouts and manual adjustments. The camera allows users to remotely pan, tilt, zoom, and focus all 4 independent varifocal motorized lens assemblies directly through the VMS client, allowing seamless adaptation to physical environment changes post-deployment.

Customizable Multi-Angle Presets

Quickly deploy optimized site coverage footprints with built-in layout presets. Configure the four sensor tracks instantaneously into standard 180-degree, 270-degree, or full 360-degree panoramic setups, or build and recall multi-directional user configurations stored safely in edge flash memory.

Technical Specification Matrix
Camera Model AV20576RS
Image Sensor Type 1/2.8" Progressive Scan CMOS (x4 Sensors)
Total System Resolution 20 Megapixel Total Output (5MP x 4 Configuration)
Max Full FOV Matrix 10368 H x 1944 V (Combined Sensor Array Grid)
Lens Specification 4x Motorized Varifocal 3.3mm-6.6mm Lens Assemblies (F1.8)
Remote Setup Gimbal 3-Axis Remotely Adjustable Mechanical Tracking (360° Pan / 135° Tilt)
Wide Dynamic Range DOL True WDR Hardware Multi-Exposure Mode (120dB)
Streaming Profile Speed Up to 30fps at Maximum 20MP Resolution Matrix
Data Transmission Encoding H.265 / H.264 / MJPEG with SNAPstream+™ Codec Protection
Power Architecture PoE+ (IEEE 802.3at Class 4) / Auxiliary 24-48V DC, 24V AC
Edge Storage Capabilities Onboard MicroSDXC Expansion Port Slot up to 1TB Capacity
Enclosure Architecture IP66 Weatherproof / IK10 Vandal-Resistant Die-Cast Aluminum Body
Compliance Standard Profiles NDAA Compliant, TAA Certified Sourcing, ONVIF Profiles S, G, M, T
What does Remote Setup (RS) mean in real-world deployment?

Remote Setup gives you a fully motorized 3-axis internal gimbal system for each of the four lens sensors. Once fixed to a structural location, installers never have to manually position the lens; you can zoom, track focus, and glide sensors via your software UI.

How does this camera handle power footprints across four independent sensors?

The AV20576RS architecture uses an efficient integrated structural setup that handles power and analytics for all four 5MP feeds using a single PoE+ (IEEE 802.3at Class 4) network line connection run, capping maximum draws at 25.5W.

Does this model feature native IR illumination?

No. The baseline AV20576RS version leverages advanced NightView™ tracking optimization to maintain high-definition, low-noise color images in extreme low-light environments without using active IR. For active 850nm infrared light projection arrays, look at the AV20576RSIR version.

Is the camera fully safe for installation under open weather environments?

Yes. Housed in a heavy-duty die-cast aluminum chassis wrapped in an IK10-rated vandal proof polycarbonate bubble shield, this camera features complete IP66 ingress sealing certified to withstand temperatures from -40°C up to +50°C.

Technical Datasheet Quick Start Guide
Operation Manual Installation Manual
Official IDIS Stock
NDAA & TAA Certified
Aust-Wide Delivery
