IDIS MICRADOME DUO SERIES · NDAA & TAA COMPLIANT
Advanced Multi-Sensor Surveillance with the Next-Gen MicroDome Duo
The IDIS AV10956DN-28 sets a new standard for high-density, multi-angle commercial surveillance by packing two independent camera sensors into a single, low-profile dome housing. Engineered specifically for complex structural environments such as retail corridors, logistics intersections, financial institutions, and public transit terminals, this multi-directional powerhouse delivers comprehensive coverage without the structural footprint or cost of installing multiple separate enclosures. By utilizing a single network drop to stream two high-definition fields of view, it lowers infrastructural overhead while providing complete situational awareness across expansive commercial spaces.
Resolution
10MP (5MP x 2) Ultra HD
Optics
Dual 2.8mm Fixed Lenses
Night Vision
True Day/Night ICR
Protection
IP66 & IK10 Vandal-Proof
Uncompromising Technical Versatility & Enterprise Efficiency
The core intelligence of the IDIS AV10956DN-28 lies in its multi-sensor configuration, operating two independent 5MP streams at 2560 x 2048 resolution each. Equipped with True Wide Dynamic Range (WDR), this camera accurately balances extreme highlights and harsh backlighting simultaneously across both scenes, making it a stellar solution for modern storefront tracking or multi-directional corridor surveillance. Designed for flawless native optimization, it seamlessly interfaces with enterprise architectures via optimized compression codecs, cutting bandwidth consumption and storage footprints in half without decreasing high-fidelity tracking resolution. It acts as an optimal solution for corporate and public sector facilities requiring strict compliance verification profiles.
Two-in-One Multi-Sensor Efficiency
By executing high-fidelity dual-angle tracking using a singular network port drop and IP configuration profile, this unit replaces multiple legacy housings. It substantially reduces your VMS licensing overhead, deployment cabling runs, and active maintenance costs while expanding overlapping security perimeters.
Vandal-Proof Tactical Design
Housed inside an ultra-rugged, low-profile dome assembly, the hardware carries verified IP66 weatherproofing and IK10 kinetic impact ratings. This ensures continuous video capture and operational resilience against intentional physical damage, extreme environmental elements, and high-impact contact risks.
Technical Specification Matrix
| Camera Model |
AV10956DN-28 |
| Image Sensor Size |
1/1.8" Progressive Scan CMOS (Per Sensor) |
| Total Resolution Output |
10 Megapixel Total (5MP + 5MP Dual Configuration) |
| Focal Length & Lens Type |
Dual 2.8mm Fixed-focal Optical Lenses |
| Wide Dynamic Range (WDR) |
True WDR Baseline Dynamic Contrast Enhancement |
| Day & Night Mechanical Cut |
IR Cut Filter with Automated Switching Mechanism (ICR) |
| Video Compression Codecs |
H.265 / H.264 Main Profile Support |
| Ingress & Impact Protection |
IP66 Weather-Proof & IK10 Vandal-Resistant Enclosure |
| Power Architecture |
Power over Ethernet (PoE IEEE 802.3af Class 3) / 12V DC |
| Regulatory Approvals |
NDAA Compliant, TAA Certified, FCC, CE, KC |
Does this camera require two network cables to run both sensors?
No. The AV10956DN-28 utilizes an internal network switch architecture that pipes both distinct 5MP video sensor streams over a singular Ethernet connection line. This eliminates extra cable pulls and infrastructure overhead.
Is this model fully compliant for federal and military facility deployment?
Yes. This product is fully NDAA and TAA compliant. It meets all strict security and supply chain sourcing criteria required for deployment in US government facilities, defense sectors, and federally funded commercial projects.
Does the device require separate software licenses for each lens?
Licensing parameters depend entirely on your chosen Video Management Software (VMS). However, when paired natively with an IDIS DirectIP NVR environment or the IDIS Solution Suite, licensing metrics are deeply optimized for multi-sensor hardware footprints.
Can the individual sensors be manually adjusted inside the housing?
Yes. Each internal camera block module features independent multi-axis positioning mechanics. This flexibility allows technicians to precisely align and fine-tune distinct viewing vectors during ceiling or wall installations.
