Hikvision 6MP + 4CH Kit: 4 AcuSense Turret Cameras + 4CH 4K NVR - GR-DS-46MP4CH
Upgrade your home security with the Hikvision 4 x 6MP Camera + 4 Channel NVR CCTV Kit. Featuring 4 AcuSense Turret Cameras and a 4K NVR, this bundle provides high quality imaging, low-light performance, efficient compression, and WDR technology. With deep learning classification and a built-in microphone, protect your property with confidence and ease.
This Hikvision CCTV kit comes with:
4 x DS-2CD2366G2-IU1 x DS-7604NI-I1/4P
System Overviews
4 x Hikvision DS-2CD2366G2-IU 6MP AcuSense Turret, IP67, IR, Built-in Mic, 2.8mm (2366)
High quality imaging with 6 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Focus on human and vehicle targets classification based on deep learning
Built-in microphone for real-time audio security(-U)
Water and dust resistant (IP67)
1 x Hikvision 4K NVR DS-7604NI-I1/4P, 4 Channel, 4 PoE (7604)
H.265+/H.265/H.264+/H.264 video formats
Up to 4-ch IP camera inputs
2-ch@12 MP (20fps)/4-ch@8 MP (25fps)
4-ch synchronous playback at up to 8MP resolution
Hikvision 4 x 6MP Strobe Light, Two-way Audio, Alarm Cameras & 4 Channel NVR CCTV Kit: 4 x ColorVu Turret Cameras + 4CH NVR Bundle.
4 x DS-2CD2367G2H-LISU-SLHikvision 6 MP Smart Hybrid Light with ColorVu Fixed Turret Network Camera
High quality imaging with 6 MP resolution
Smart Hybrid Light: advanced technology with long range
Clear imaging against strong back light due to 130 dB WDR technology
Efficient H.265+ compression technology
Focus on human and vehicle classification based on deep learning
Provide real-time security via built-in two-way audio
Active strobe light and audio alarm to warn intruders off
Support on-board storage up to 512 GB (SD card slot)
Water and dust resistant (IP67)
Audio and alarm interface available
1 x DS-7604NI-I1/4PHikvision 4K NVR DS-7604NI-I1/4P, 4 Channel, 4 PoE (7604)
H.265+/H.265/H.264+/H.264 video formats
Up to 4-ch IP camera inputs
2-ch@12 MP (20fps)/4-ch@8 MP (25fps)
4-ch synchronous playback at up to 8MP resolution
Hikvision 8MP + 8 Channel Kit: 4 AcuSense Turret Cameras + 8CH 8K NVR - GR-DS-48MP8CH
Protect your property with the powerful Hikvision 4 x 8MP Cameras & 8CH NVR CCTV Kit. It includes 4 AcuSense Turret Cameras that capture crystal-clear images with 8MP resolution and advanced technology for excellent low-light performance. With human and vehicle target classification based on deep learning, along with 120 dB true WDR technology, you can trust this kit to keep your property secure. The 8CH NVR supports up to 8-ch@8 MP for high-quality recording and has a storage capacity of 3TB for all your footage.
This Hikvision CCTV kit comes with:4 x Hikvision DS-2CD2386G2-I1 x DS-7608NI-M2/8P with 3TB
4 x Hikvision DS-2CD2386G2-I 8MP AcuSense Turret, IP67, IR, 4K, 2.8mm (2386)
High quality imaging with 8 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Efficient H.265+ compression technology
Clear imaging against strong back light by 120 dB true WDR technology
Focus on human and vehicle targets classification based on deep learning
Built-in microphone for real-time audio security(-U)
Water and dust resistant (IP67)
Hikvision M Series NVR DS-7608NI-M2/8P with 3TB storage, 8 Channel, 1U, 8 PoE, 8K 3TB HDD (7608)
H.265+/H.265/H.264+/H.264 video formats
Up to 8-ch IP camera inputs
Up to 8-ch@8 MP decoding capacity
Up to 128 Mbps incoming bandwidth
Hikvision 8MP + 4CH Kit: 4 AcuSense Turret Cameras + 4CH 4K NVR - GR-DS-48MP4CH
This kit comes with:
4 x Hikvision DS-2CD2386G2-I-2 8MP AcuSense Turret, IP67, IR, 4K, 2.8mm (2386)
High quality imaging with 8 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Efficient H.265+ compression technology
Clear imaging against strong back light by 120 dB true WDR technology
Focus on human and vehicle targets classification based on deep learning
Built-in microphone for real-time audio security(-U)
Water and dust resistant (IP67)
1 x Hikvision 4K NVR DS-7604NI-I1/4P, 4 Channel, 4 PoE (7604)
H.265+/H.265/H.264+/H.264 video formats
Up to 4-ch IP camera inputs
2-ch@12 MP (20fps)/4-ch@8 MP (25fps)
4-ch synchronous playback at up to 8MP resolution
Hikvision 4 x 8MP Strobe Light, Two-way Audio, Alarm Cameras & 8 Channel NVR CCTV Kit: 4 x ColorVu Turret Cameras + 8CH 8K NVR Bundle, GR-DS-4CSA8MP8CH
The Hikvision 4 x 8MP Strobe Light, Two-way Audio, Alarm Cameras & 8 Channel NVR CCTV Kit offers advanced technology and high-quality imaging with 4K resolution. With the smart hybrid light and 130 dB WDR technology, it provides clear imaging against strong back light. The built-in two-way audio, strobe light, and audio alarm provide real-time security and deter intruders.
This Hikvision CCTV Kit includes
4 x DS-2CD2387G2H-LISU/SL
1 x DS-7608NI-M2/8P
Overview
4 x DS-2CD2387G2H-LISU/SLHikvision 8 MP Smart Hybrid Light with ColorVu Fixed Turret Network Camera
High quality imaging with 8 MP resolution
Smart Hybrid Light: advanced technology with long range
Clear imaging against strong back light due to 130 dB WDR technology
Efficient H.265+ compression technology
Focus on human and vehicle classification based on deep learning
Provide real-time security via built-in two-way audio
Active strobe light and audio alarm to warn intruders off
Support on-board storage up to 512 GB (SD card slot)
Water and dust resistant (IP67)
Audio and alarm interface available
1 x DS-7608NI-M2/8P Hikvision Ultra M Series NVR DS-7608NI-M2/8P, 8 Channel, 1U, 8 PoE, 8K, 2 x HDD Bay (7608)
H.265+/H.265/H.264+/H.264 video formats
Up to 8-ch IP camera inputs
Up to 8-ch@8 MP decoding capacity
Up to 128 Mbps incoming bandwidth
Hikvision 4 Cameras & 8 Channel Kit: 4 x ColorVu Turret Cameras + 8CH 4K NVR, GR-DS-4C8MP8CH-3TB
This Hikvision CCTV kit includes four ColorVu cameras, optimised for outdoor use with audio alarm capabilities and full-colour night vision for improved visibility with the M Series NVR ensures high performance surveillance functionality.
What’s ColorVu Technology?
When it comes to ensuring security and safety, seeing every detail is critical – especially in low light conditions.
Hikvision’s industry-leading ColorVu technology captures high-quality, full-color video 24/7 which enables businesses and homeowners to protect people and property at night with the same sharp rendering as in daylight.
For a broad range of security scenarios, ColorVu technology empowers a diverse set of products and solutions to meet users’ growing needs. Read on to learn more.
This CCTV Kit includes:
4 x Hikvision DS-2CD2387G2-LSU/SL-2 1 x Hikvision NVR DS-7608NI-M2/8P with 3TB storage
4 x Hikvision DS-2CD2387G2-LSU/SL-2 8MP ColorVu Turret, White Light, AcuSense, Built-in Mic, Speaker, Strobe Light, 2.8mm (2387)
High quality imaging with 8 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 130 dB WDR technology
Focus on human and vehicle targets classification based on deep learning
24/7 colourful imaging
Active strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
Audio and alarm interface available
Water and dust resistant (IP67)
1 x Hikvision M Series NVR DS-7608NI-M2/8P with 3TB storage, 8 Channel, 1U, 8 PoE, 8K 3TB HDD (7608)
H.265+/H.265/H.264+/H.264 video formats
Up to 8-ch IP camera inputs
Up to 8-ch@8 MP decoding capacity
Up to 128 Mbps incoming bandwidth
You can store surveillance footage for an extended period of time by upgrading the hard disk drive (HDD).
Hikvision 4K Powered-by-DarkFighter Fixed Turret Network Camera, DS-2CD2385G1-I comes with 2.8mm and 4mm.
High quality imaging with 8 MP resolution
Excellent low-light performance via powered-by-DarkFighter technology
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Water and dust resistant (IP67)
Robust structure design with full metal materials
Downloads
DS-2CD2385G1-I Datasheet
DS-2CD2385G1-I Quick Start Guide
DS-2CD2385G1-I User Manual
This kit includes two ColorVu cameras, optimised for outdoor use with audio alarm capabilities and full-colour night vision for improved visibility. Additionally, the four AcuSense cameras come equipped with built-in microphones, allowing users to hear activity within the scene for both indoors and outdoors. Last but not least, the M Series NVR ensures high performance surveillance functionality.
Hikvision 6 Cameras & 8CH Kit: 2 x ColorVu & 6 AcuSense Turret Cameras + 8CH 4K NVR, GR-DS-2C4A8MP8CH
This CCTV package contains:2 x Hikvision DS-2CD2387G2-LSU/SL-2 8MP ColorVu Turret Cameras4 x Hikvision DS-2CD2366G2-IU-2 6MP AcuSense Turret Camera1 x Hikvision NVR DS-7608NI-M2/8P with 3TB storage
2 x Hikvision DS-2CD2387G2-LSU/SL-2 8MP ColorVu Turret, White Light, AcuSense, Built-in Mic, Speaker, Strobe Light, 2.8mm (2387)
High quality imaging with 8 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 130 dB WDR technology
Focus on human and vehicle targets classification based on deep learning
24/7 colourful imaging
Active strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
Audio and alarm interface available
Water and dust resistant (IP67)
4 x Hikvision DS-2CD2366G2-IU-2 6MP AcuSense Turret Camera, IP67, IR, Built-in Mic, 2.8mm (2366)
High quality imaging with 6 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Focus on human and vehicle targets classification based on deep learning
Built-in microphone for real-time audio security(-U)
Water and dust resistant (IP67)
1 x Hikvision M Series NVR DS-7608NI-M2/8P with 3TB storage, 8 Channel, 1U, 8 PoE, 8K 3TB HDD (7608)
H.265+/H.265/H.264+/H.264 video formats
Up to 8-ch IP camera inputs
Up to 8-ch@8 MP decoding capacity
Up to 128 Mbps incoming bandwidth
You can store surveillance footage for an extended period of time by upgrading the hard disk drive (HDD).
Hikvision 6 MP Varifocal 2.8mm Turret Network Camera, DS-2CD2H65G1-IZS
High quality imaging with 6 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Water and dust resistant (IP66) and vandal proof (IK10)
Motorized vari-focal lens for easy installation and monitoring
Audio and alarm interface available
Robust structure design with full metal materials
Downloads
DS-2CD2H65G1-IZS User Manual
Hikvision 6 x 8MP Cameras + 8 Channel NVR CCTV Kit: 6 AcuSense Turret Cameras + 8CH 8K NVR Bundle
This kit comes with:
6 x DS-2CD2386G2-I
1 x DS-7608NI-M2/8P
Hikvision CCTV Kit Hightlights
6 x Hikvision DS-2CD2386G2-I-2 8MP AcuSense Turret, IP67, IR, 4K, 2.8mm (2386)
High quality imaging with 8 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Efficient H.265+ compression technology
Clear imaging against strong back light by 120 dB true WDR technology
Focus on human and vehicle targets classification based on deep learning
Built-in microphone for real-time audio security(-U)
Water and dust resistant (IP67)
Hikvision M Series NVR DS-7608NI-M2/8P, 8 Channel, 1U, 8 PoE, 8K 3TB HDD (7608)
H.265+/H.265/H.264+/H.264 video formats
Up to 8-ch IP camera inputs
Up to 8-ch@8 MP decoding capacity
Up to 128 Mbps incoming bandwidth
Hikvision 6MP AcuSense Motorised Varifocal Turret DS-2CD2H66G2T-IZS, IR, 2.8-12mm, Pigtail (2H66)
The Hikvision 6MP AcuSense Motorised Varifocal Turret offers high-quality 6 MP resolution, powered-by-DarkFighter technology for excellent low-light performance, and H.265+ compression technology for efficient storage. With deep learning capabilities, this camera can accurately classify human and vehicle targets. Its durable, weather-resistant design makes it ideal for any environment.
Features
High quality imaging with 6 MP resolution
Motorized varifocal lens for easy installation and monitoring
Excellent low-light performance via powered-by-DarkFighter technology
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Focus on human and vehicle targets classification based on deep learning
Audio and alarm interface available
Water and dust resistant (IP67) and vandal proof (IK10)
Downloads
DS-2CD2H66G2T-IZS DatasheetDS-2CD2H66G2T-IZS Quick Start GuideDS-2CD2H66G2T-IZS User Manual
Hikvision 6MP DS-2CD2366G2-I Outdoor AcuSense Gen 2 Turret Camera, H.265, WDR, 30m IR, IP67, 2.8mm (2366)
Capture crystal clear images day and night with the Hikvision 6MP Outdoor AcuSense Gen 2 Turret Camera. Its powered-by-DarkFighter technology ensures excellent low-light performance, while efficient H.265+ compression technology reduces storage needs. With deep learning-based human and vehicle target classification and a built-in microphone for audio security, this camera provides comprehensive security. Its IP67 waterproof and dust-proof rating makes it perfect for outdoor use.
Features
High quality imaging with 6 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Focus on human and vehicle targets classification based on deep learning
Built-in microphone for real-time audio security(-U)
Water and dust resistant (IP67)
Camera
Image Sensor
1/2.4" Progressive Scan CMOS
Max. Resolution
3200 × 1800
Min. Illumination
Color: 0.003 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°
Lens
Lens Type
Fixed lens, 2.8, 4, and 6 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV 105°, vertical FOV 55°, diagonal FOV 127°;
4 mm, horizontal FOV 78°, vertical FOV 38°, diagonal FOV 96°;
6 mm, horizontal FOV 51°, vertical FOV 26°, diagonal FOV 59°
Lens Mount
M12
Iris Type
Fixed
Aperture
F1.6
DORI
DORI
2.8 mm: D: 76 m, O: 30 m, R: 15 m, I: 7 m;
4 mm: D: 115 m, O: 45 m, R: 23 m, I: 11 m;
6 mm: D: 164 m, O: 65 m, R: 32 m, I: 16 m
Illuminator
Supplement Light Type
IR
Supplement Light Range
Up to 30 m
Smart Supplement Light
Yes
IR Wavelength
850 nm
Video
Main Stream
50 Hz: 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (1280 x 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 x 720, 640 × 480, 640 × 360)
Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360),
*Third stream is supported under certain settings.
Video Compression
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264 (*Third stream is supported under certain settings.)
Video Bit Rate
32 Kbps to 16 Mbps
H.264 Type
Baseline Profile,Main Profile,High Profile
H.265 Type
Main Profile
Bit Rate Control
CBR,VBR
Scalable Video Coding (SVC)
H.264 and H.265 encoding
Region Of Interest (ROI)
1 fixed region(s) for main stream and sub-stream
Audio
Audio Type
-U: Mono sound
Audio Compression
-U: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate
-U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate
-U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering
-U: Yes
Network
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets, SRTP, SFTP
Simultaneous Live View
Up to 6 channels
API
Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK, ISUP
User/Host
Up to 32 users
3 user levels: administrator, operator, and user
Security
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
Network Storage
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client
iVMS-4200, Hik-Connect, Hik-Central
Web Browser
Plug-in required live view: IE 10, IE 11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Image Parameters Switch
Yes
Image Settings
Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Day/Night Switch
Day,Night,Auto,Schedule
Wide Dynamic Range (WDR)
120 dB
SNR
≥ 52 dB
Image Enhancement
BLC,HLC,3D DNR
Privacy Mask
4 programmable polygon privacy masks
Interface
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Built-In Microphone
-U: Yes
Reset Key
Yes
Event
Basic Event
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Smart Event
Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)), scene change detection
Linkage
Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture
Deep Learning Function
Face Capture
Yes
General
Power
12 VDC ± 25%, 0.45 A, max. 5.4 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 6.5 W
Material
Metal except for trim ring
Dimension
Ø138.3 mm × 111.4 mm (Ø5.4" × 4.4")
Package Dimension
170 mm × 170 mm × 150 mm (6.7" × 6.7" × 5.9")
Weight
Approx. 740 g (1.6 lb.)
With Package Weight
Approx. 1070 g (2.4 lb.)
Storage Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General Function
Heartbeat,mirror,flash log,password reset via email,pixel counter,anti-flicker
Approval
EMC
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
RCM: AS/NZS CISPR 32: 2015,
KC: KN32: 2015, KN35: 2015
Safety
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017
Environment
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
Protection
IP67: IEC 60529-2013
Download
DS-2CD2366G2-I Datasheet
Hikvision 8 x 6MP Cameras Kit: 8 AcuSense Turret Cameras + 8CH 8K NVR
Upgrade your security system with the reliable and efficient Hikvision 8 x 6MP Cameras Kit. Featuring 8 AcuSense Turret Cameras with high quality 6MP resolution, DarkFighter technology for low-light performance, and true WDR technology for clear imaging. The 8CH 8K NVR includes 3TB storage and 8 PoE ports for easy installation and H.265+ compression technology for optimized storage. Protect your property with advanced deep learning human and vehicle target classification and IP67 water and dust resistant cameras.
This CCTV package contains:
8 x Hikvision DS-2CD2366G2-IU-2 6MP AcuSense Turret, IP67, IR, Built-in Mic, 2.8mm (2366)
High quality imaging with 6 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Focus on human and vehicle targets classification based on deep learning
Built-in microphone for real-time audio security(-U)
Water and dust resistant (IP67)
1 x Hikvision M Series NVR DS-7608NI-M2/8P with 3TB storage, 8 Channel, 1U, 8 PoE, 8K 3TB HDD (7608)
H.265+/H.265/H.264+/H.264 video formats
Up to 8-ch IP camera inputs
Up to 8-ch@8 MP decoding capacity
Up to 128 Mbps incoming bandwidth
You can store surveillance footage for an extended period of time by upgrading the hard disk drive (HDD).
Hikvision 8MP AcuSense Motorised Varifocal Turret DS-2CD2H86G2T-IZS, 2.8-12mm, Pigtail (2H86)
Get precision surveillance and enhanced security with the Hikvision 8MP AcuSense Motorised Varifocal Turret DS-2CD2H86G2T-IZS. This advanced camera features an 8 MP resolution, motorized varifocal lens for easy installation, and excellent low-light performance with Powered-by-DarkFighter technology. With 120 dB true WDR technology, H.265+ compression, and deep learning-based human and vehicle target classification, you'll get clear, efficient surveillance and protection. Plus, with water and dust resistance (IP67) and vandal proofing (IK10), this camera can withstand any environment.
Features
High quality imaging with 8 MP resolution
Motorised varifocal lens for easy installation and monitoring
Excellent low-light performance via powered-by-DarkFighter technology
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Focus on human and vehicle targets classification based on deep learning
Audio and alarm interface available
Water and dust resistant (IP67) and vandal proof (IK10)
Downloads
DS-2CD2H86G2T-IZS DatasheetDS-2CD2H86G2T-IZS Quick Start GuideDS-2CD2H86G2T-IZS User Manual
Hikvision 8MP AcuSense Turret DS-2CD2386G2-IU, IP67, IR, Built-in Mic, 2.8mm (2386)
The Hikvision 8MP AcuSense Turret DS-2CD2386G2-IU-2 is a top-of-the-line surveillance camera designed for high-quality imaging with 8 MP resolution. With advanced features such as powered-by-DarkFighter technology and 120 dB true WDR technology, it delivers excellent low-light performance and clear imaging even against strong backlighting. Additionally, its deep learning technology allows for the classification of human and vehicle targets. The built-in microphone provides real-time audio security, and its IP67 rating makes it water and dust resistant for outdoor use.
Features
High quality imaging with 8 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Efficient H.265+ compression technology
Clear imaging against strong back light by 120 dB true WDR technology
Focus on human and vehicle targets classification based on deep learning
Built-in microphone for real-time audio security(-U)
Water and dust resistant (IP67)
Downloads
DS-2CD2386G2-IU DatasheetDS-2CD2386G2-IU Quick GuideDS-2CD2386G2-IU Manual
Hikvision AcuSense Turret DS-2CD2346G2-ISU-SL-2, 4MP, IP67, IR, Built-in Mic, Speaker, Strobe Light, 2.8mm (2346)
DS-2CD2346G2-ISU/SL(2.8mm)
High quality imaging with 4 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Clear imaging against strong backlight due to 120 dB true WDR technology
Efficient H.265+ compression technology
Focus on human and vehicle targets classification based on deep learning
Active strobe light and audio alarm to warn intruders off
Provides real-time security via built-in two-way audio
Water and dust resistant (IP67)
Downloads
Datasheet
Hikvision AcuSense Turret, 4MP DS-2CD2346G2-ISU-SL-4, IP67, IR, Built-in Mic, Speaker, Strobe Light, 4mm (2346)
DS-2CD2346G2-ISU/SL(4mm)
High quality imaging with 4 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Clear imaging against strong backlight due to 120 dB true WDR technology
Efficient H.265+ compression technology
Focus on human and vehicle targets classification based on deep learning
Active strobe light and audio alarm to warn intruders off
Provides real-time security via built-in two-way audio
Water and dust resistant (IP67)
Downloads
Datasheet
Hikvision AIS Bundle: Keep your home or office secure and monitored with our comprehensive Security System, which includes an Alarm, Video Intercom, and CCTV Kit. With this professional starter kit, receive notifications on your mobile and monitor footage on your television or computer monitors. Expand the system by adding more CCTV cameras or PIR sensors in the future.
1 x DS-KIS603-PHikvision IP Intercom Kit, Gen 2, 1 to 1 Villa Plastic Surface Mount, Wi-Fi, Black, 12VDC (KIS)
IP video intercom kit for villa or house, only one call button
DS-KV6113-WPE1 x1
DS-KH6320-WTE1 x1
PSU x 2
1 x DS-PWA96-Kit-WBHikvision Wireless AX PRO Alarm Kit 433MHz
DS-PWA96-M-WB x 1
DS-PKF1-WB x 1
DS-PDP15P-EG2-WB x 1
DS-PDMC-EG2-WB x 1 433MHz
1 x GR-DS-4CSA8MP8CH-4TBHikvision 4 x 8 Megapixels ColorVu Cameras with Strobe Light, Two-way Audio & Audio Alarm comes with 4TB 8 Channel NVR
4 x DS-2CD2387G2H-LISU/SLHikvision 8 MP Smart Hybrid Light with ColorVu Fixed Turret Network Camera
High quality imaging with 8 MP resolution
Smart Hybrid Light: advanced technology with long range
Clear imaging against strong back light due to 130 dB WDR technology
Efficient H.265+ compression technology
Focus on human and vehicle classification based on deep learning
Provide real-time security via built-in two-way audio
Active strobe light and audio alarm to warn intruders off
Support on-board storage up to 512 GB (SD card slot)
Water and dust resistant (IP67)
Audio and alarm interface available
1 x DS-7608NI-M2/8PHikvision Ultra M Series NVR DS-7608NI-M2/8P, 8 Channel, 1U, 8 PoE, 8K, 2 x HDD Bay (7608)
H.265+/H.265/H.264+/H.264 video formats
Up to 8-ch IP camera inputs
Up to 8-ch@8 MP decoding capacity
Up to 128 Mbps incoming bandwidth
Hikvision ColorVu Turret DS-2CD2347G2-LSU/SL, 4MP, White Light, AcuSense, Built-in Mic, Speaker, Strobe Light, 2.8mm (2347)
The Hikvision ColorVu Turret DS-2CD2347G2-LSU/SL offers high-quality 4 megapixel resolution imaging with efficient H.265+ compression technology. With 130 dB WDR technology, it can take clear images even in strong backlight. It features deep learning based classification for human and vehicle targets and provides 24/7 colorful imaging. The built-in two-way audio, strobe light, and audio alarm help enhance security measures. This IP67 water and dust resistant camera is perfect for both indoor and outdoor use.
Features
High quality imaging with 4 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 130 dB WDR technology
Focus on human and vehicle targets classification based on deep learning
24/7 colorful imaging
Active strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
Audio and alarm interface available
Water and dust resistant (IP67)
Downloads
DS-2CD2347G2-LSU/SL DatasheetDS-2CD2347G2-LSU/SL Quick Start GuideDS-2CD2347G2-LSU/SL User ManualDS-2CD2347G2-LSU/SL FAQ
Hikvision ColorVu Turret DS-2CD2347G2-LU-4, 4MP, White Light, AcuSense, Mic, 4mm (2347)
High quality imaging with 4 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 130 dB WDR technology
Built-in microphone for real-time audio security(-U)
Focus on human and vehicle targets classification based on deep learning
24/7 colorful imaging
Water and dust resistant (IP67)
Camera
Image Sensor
1/1.8" Progressive Scan CMOS
Max. Resolution
2688 × 1520
Min. Illumination
Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Time
1/3 s to 1/100,000 s
Angle Adjustment
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Lens
Lens Type
Fixed focal lens, 2.8, 4, and 6 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV 112°, vertical FOV 61°, diagonal FOV 134°
4 mm, horizontal FOV 95°, vertical FOV 51°, diagonal FOV 115°
6 mm, horizontal FOV 58°, vertical FOV 31°, diagonal FOV 69°
Lens Mount
M16
Iris Type
Fixed
Aperture
F1.0
Depth Of Field
2.8 mm, 2.5 m to ∞
4 mm, 3.5 m to ∞
6 mm, 7.5 m to ∞
DORI
DORI
2.8 mm, D: 58 m, O: 23 m, R: 11 m, I: 2 m
4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m
6 mm, D: 115 m, O: 45 m, R: 23 m, I: 11 m
Illuminator
Supplement Light Type
White Light
Supplement Light Range
30 m
Smart Supplement Light
Yes
Video
Main Stream
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings.
Video Compression
Main stream: H.265/H.264/H.265+/H.264+
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
*Third stream is supported under certain settings.
Video Bit Rate
32 Kbps to 8 Mbps
H.264 Type
Baseline Profile/Main Profile/High Profile
H.265 Type
Main Profile
Bit Rate Control
CBR/VBR
Scalable Video Coding (SVC)
H.264 and H.265 encoding
Region Of Interest (ROI)
1 fixed region for main stream and sub-stream
Audio
Audio Compression
-U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate
-U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate
-U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering
-U: Yes
Network
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets
Simultaneous Live View
Up to 6 channels
API
Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
User/Host
Up to 32 users. 3 user levels: administrator, operator and user
Security
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network Storage
MicroSD/microSDHC/microSDXC card (512 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Together with high-end Hikvision memory card, memory card encryption and health detection are supported
Client
iVMS-4200, Hik-Connect, Hik-Central
Web Browser
Plug-in required live view: IE 10, IE 11
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Image Parameters Switch
Yes
Image Settings
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night Switch
Auto, Schedule
Wide Dynamic Range (WDR)
130 dB
SNR
≥ 52 dB
Image Enhancement
BLC, HLC, 3D DNR
Interface
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Built-In Microphone
-U: Yes
Reset Key
Yes
Event
Basic Event
Motion detection (human and vehicle targets classification), video tampering alarm, exception
Smart Event
Line crossing detection, intrusion detection, region entrance detection, region exiting detection
Scene change detection
Linkage
Upload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email
Deep Learning Function
Face Capture
Yes
General
Power
12 VDC ± 25%, 0.55 A, max. 6.6 W, Ø5.5 mm coaxial power plug, reverse polarity protection
PoE: 802.3af, Class 3, 36 V to 57 V, 0.22 A to 0.13 A, max. 7.6 W
Dimension
Ø138.3 mm × 125.2 mm (Ø5.4" × 4.9")
Package Dimension
170 mm × 170 mm × 150 mm (7" × 7" × 5.9")
Weight
Approx. 750 g (1.7 lb.)
With Package Weight
Approx. 1055 g (2.3 lb.)
Storage Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language
33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General Function
Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
Approval
EMC
FCC SDoC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);
RCM (AS/NZS CISPR 32: 2015);
IC VoC (ICES-003: Issue 6, 2016);
KC (KN 32: 2015, KN 35: 2015)
Safety
UL (UL 60950-1);
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);
LOA (IEC/EN 60950-1)
Environment
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection
IP67 (IEC 60529-2013)
Download
DS-2CD2347G2-LU Datasheet
DS-2CD2347G2-LU Quick Start GuideDS-2CD2347G2-LU User Manual
Hikvision 6 MP AcuSense Strobe Light and Audible Warning Fixed Turret Network Camera - DS-2CD2366G2-ISU/SL Available in 2.8mm and 4mm.
The Hikvision DS-2CD2366G2-ISU/SL 6MP AcuSense Turret offers high quality imaging with 6 MP resolution and excellent low-light performance thanks to powered-by-DarkFighter technology. With 120 dB true WDR technology and efficient H.265+ compression, this camera provides clear imaging against strong back light. It also features deep learning-based human and vehicle target classification, and active strobe light and audio alarms to deter intruders. The built-in two-way audio allows for real-time security, and the camera is water and dust resistant with an IP67 rating.
Features
High quality imaging with 6 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Clear imaging against strong back light due to 120 dB true WDR technology
Efficient H.265+ compression technology
Focus on human and vehicle targets classification based on deep learning
Active strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
Water and dust resistant (IP67)
Downloads
DS-2CD2366G2-ISU/SL Datasheet
Hikvision DS-2CD2366G2-IU 6MP AcuSense Turret, IP67, IR, Built-in Mic, Fixed, 2.8mm (2366)
Experience high-quality imaging with the Hikvision DS-2CD2366G2-IU 6MP AcuSense Turret. Powered by DarkFighter technology, it offers excellent low-light performance. Its 120 dB true WDR technology ensures clear imaging against strong backlight. With deep learning-based classification, it focuses on human and vehicle targets. Enjoy real-time audio security with the built-in microphone and IP67 water and dust resistance.
Features
High quality imaging with 6 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Focus on human and vehicle targets classification based on deep learning
Built-in microphone for real-time audio security(-U)
Water and dust resistant (IP67)
Downloads
DS-2CD2366G2-IU DatasheetDS-2CD2366G2-IU Quick GuideDS-2CD2366G2-IU Manual
Hikvision DS-2CD2367G2-LU 6MP ColorVu Turret, White Light, AcuSense, Mic, (2367) Fixed Network Security comes with 2.8mm and 4mm lens
Experience high quality imaging day and night with Hikvision DS-2CD2367G2-LU 6MP ColorVu Turret Camera. With 24/7 colorful imaging and advanced features such as efficient H.265+ compression, 130 dB WDR technology, and deep learning-based human and vehicle target classification, this camera offers clear and reliable security. Plus, the built-in microphone allows for real-time audio monitoring.
Features
High quality imaging with 6 MP resolution
24/7 colorful imaging
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 130 dB WDR technology
Focus on human and vehicle targets classification based on deep learning
-U: Built-in microphone for real-time audio security
Water and dust resistant (IP67)
Downloads
DS-2CD2367G2-LU Datasheet
Hikvision DS-2CD2367G2H-LISU/SL 6 MP Smart Hybrid Light with ColorVu Fixed Turret Network Camera
Capture crystal clear images with the Hikvision 6 megapixel Smart Hybrid Light with ColorVu Fixed Turret Network Camera. Featuring advanced technology, including long range Smart Hybrid Light and 130 dB WDR, this camera provides high-quality imaging in any situation. With deep learning-based human and vehicle classification, real-time security via two-way audio, and built-in strobe light and audio alarm, you'll have peace of mind knowing your property is protected. Plus, with IP67 water and dust resistance, on-board storage up to 512 GB, and audio and alarm interface, this camera is designed for reliable security.
Features
High quality imaging with 6 MP resolution
Smart Hybrid Light: advanced technology with long range
Clear imaging against strong back light due to 130 dB WDR technology
Efficient H.265+ compression technology
Focus on human and vehicle classification based on deep learning
Provide real-time security via built-in two-way audio
Active strobe light and audio alarm to warn intruders off
Support on-board storage up to 512 GB (SD card slot)
Water and dust resistant (IP67)
Audio and alarm interface available
Accessories
Wall Mount Brackets
Downloads
DS-2CD2367G2H-LISU/SL DS-2CD2367G2H-LISU/SL DatasheetDS-2CD2367G2H-LISU/SL User’s Manual DS-2CD2367G2H-LISU/SL Quick Start Guide
Hikvision DS-2CD2367G2H-LIU-2 6MP ColorVu Turret, Hybrid Light, Built-in Mic, 2.8mm Lens
Capture clear and detailed footage with the Hikvision DS-2CD2367G2H-LIU 6MP ColorVu Turret camera. Its advanced Hybrid Light technology provides long range vision, while the 130 dB WDR technology ensures clear imaging even in strong back light. With efficient H.265+ compression technology, focus on human and vehicle classification, and a built-in microphone for real-time audio security, this camera is perfect for protecting your home or business. Its water and dust resistant design (IP67) ensures durability and reliability.
Features
High quality imaging with 6 MP resolution
Smart Hybrid Light: advanced technology with long range
Clear imaging against strong back light due to 130 dB WDR technology
Efficient H.265+ compression technology
Focus on human and vehicle classification based on deep learning
-U: Built-in microphone for real-time audio security
Water and dust resistant (IP67)
Downloads
DS-2CD2367G2H-LIU DatasheetDS-2CD2367G2H-LIU Quick Start GuideDS-2CD2367G2H-LIU Manual
Hikvision HIK-DS-2CD2386G2-I 8MP AcuSense Turret, IP67, IR, 4K, 2.8mm (2386)
For exceptional security, trust the Hikvision HIK-DS-2CD2386G2-I 8MP AcuSense Turret. With 8 MP resolution and DarkFighter technology, it captures high quality images even in low-light conditions. Its advanced features, such as deep learning and true WDR technology, provide clear imaging and accurate target classification. This IP67 rated camera also features a built-in microphone for added security.
Features
High quality imaging with 8 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Efficient H.265+ compression technology
Clear imaging against strong back light by 120 dB true WDR technology
Focus on human and vehicle targets classification based on deep learning
Built-in microphone for real-time audio security(-U)
Water and dust resistant (IP67)
Downloads
DS-2CD2386G2-I DatasheetDS-2CD2386G2-I Quick GuideDS-2CD2386G2-I Manual
Hikvision DS-2CD2386G2-ISU/SL AcuSense Gen 2, Turret, 8MP, 4K, 2.8mm, AcuSense, Turret Network Camer
Empowered by deep learning algorithms, Hikvision AcuSense technology brings human or vehicle target classification alarms to front- and back-end devices. The system can greatly reduce false alarms generated by targets other than humans or vehicles, vastly improving alarm efficiency and effectiveness.
Features
High quality imaging with 8 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Clear imaging against strong back light due to 120 dB true WDR technology
Efficient H.265+ compression technology
Focus on human and vehicle targets classification based on deep learning
Active strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
Water and dust resistant (IP67)
Downloads
DS-2CD2386G2-ISU/SL Datasheet
Hikvision HIK-DS-2CD2387G2-LSU/SL 8MP ColorVu Turret, White Light, AcuSense, Built-in Mic, Speaker, Strobe Light, 2.8mm (2387)
Experience premium surveillance with Hikvision HIK-DS-2CD2387G2-LSU/SL-2 ColorVu Turret. Boasting 8 MP resolution, 130 dB WDR technology, and deep learning-based target classification, this camera delivers clear and efficient imaging. With 24/7 colorful imaging, active strobe light and audio alarm, and built-in two-way audio, it provides real-time security and scares off intruders. Water and dust resistant (IP67) for long-lasting use.
Features
High quality imaging with 8 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 130 dB WDR technology
Focus on human and vehicle targets classification based on deep learning
24/7 colorful imaging
Active strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
Audio and alarm interface available
Water and dust resistant (IP67)
Downloads
DS-2CD2387G2-LSU/SL DatasheetDS-2CD2387G2-LSU/SL Quick Start GuideDS-2CD2387G2-LSU/SL User Manual
Hikvision DS-2CD2387G2-LU 8MP ColorVu Turret Security Camera, White Light, AcuSense, Built-in Mic (2387) comes with 2.8mm and 4mm lens.
Capture clear images day and night with the Hikvision DS-2CD2387G2-LU 8 megapixel ColorVu Turret Security Camera. With 8 MP resolution and efficient H.265+ compression technology, it provides high quality imaging while saving storage space. The built-in mic and 130 dB WDR technology make for effective audio and backlighting security. IP67 water and dust resistance ensure durability.
High quality imaging with 8 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 130 dB WDR technology
Built-in microphone for real-time audio security(-U)
Focus on human and vehicle targets classification based on deep learning
24/7 colorful imaging
Water and dust resistant (IP67)
Downloads
DS-2CD2387G2-LUD Datasheet
Hikvision 8 MP Smart Hybrid Light with ColorVu, 2.8mm Fixed Lens, Turret Network Camera, DS-2CD2387G2H-LISU/SL
Capture clear and detailed images with the Hikvision 8 MP Smart Hybrid Light Camera. Its advanced technology provides long range and effectively combats strong back lighting with 130 dB WDR technology. This camera also utilizes efficient H.265+ compression and deep learning for human and vehicle classification. Equipped with a two-way audio system, strobe light, and audio alarm, this camera offers real-time security and deterrence against intruders. Plus, with its IP67 water and dust resistance, on-board storage up to 512 GB, and audio and alarm interface, this camera is a reliable choice for any space.
Features
High quality imaging with 8 MP resolution
Smart Hybrid Light: advanced technology with long range
Clear imaging against strong back light due to 130 dB WDR technology
Efficient H.265+ compression technology
Focus on human and vehicle classification based on deep learning
Provide real-time security via built-in two-way audio
Active strobe light and audio alarm to warn intruders off
Support on-board storage up to 512 GB (SD card slot)
Water and dust resistant (IP67)
Audio and alarm interface available
Downloads
DS-2CD2387G2H-LISU/SL DatasheetDS-2CD2387G2H-LISU/SL Quick Start GuideDS-2CD2387G2H-LISU/SL User Manual
Hikvision DS-2CD2H46G2T-IZS, DS-2CD2H46G2-IZS 4MP Acusense Motorised Varifocal Turret Network Camera
Empowered by deep learning algorithms, Hikvision AcuSense technology brings human and vehicle targets classification alarms to front- and back-end devices. The system focuses on human and vehicle targets, vastly improving alarm efficiency and effectiveness.
Features
High quality imaging with 4MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Motorized Varifocal lens for easy installation and monitoring
Clear imaging against strong backlight due to 120 dB WDR technology
Efficient H.265+ compression technology
Focus on human and vehicle targets classification based on deep learning
Audio and alarm interface available
Water and dust resistant (IP66) and vandal proof (IK10)
Downloads
DS-2CD2H46G2-IZS Datasheet
Hikvision TVI 2CE78H8T-IT3F 5MP Turret HD Camera, Fixed 2.8mm, IR 60m, 4 in 1, 12VDC
5 MP high performance turret camera
Strong night performance, capturing images in ultra-low light down to 0.003 lux
Clear imaging even against strong back lighting due to 130 dB true WDR technology
3D DNR technology delivers clean and sharp images
EXIR 2.0: advanced infrared technology with 60 m IR distance
Water and dust resistant (IP67)
4 in 1 (4 signals switchable TVI/AHD/CVI/CVBS)
Downloads
Hikvision TVI 2CE78H8T-IT3F DatasheetHikvision TVI 2CE78H8T-IT3F User Manual
Hikvision TVI 2CE78U7T-IT3F 8MP Turret HD Camera, Ultra Low Light, Fixed 2.8mm, 4 in 1, IR 60m
8 MP high performance turret camera
Strong night performance, capturing images in ultra-low light down to 0.003 lux
Clear imaging even against strong back lighting due to 130 dB true WDR technology
3D DNR technology delivers clean and sharp images
EXIR 2.0: advanced infrared technology with 60 m IR distance
Water and dust resistant (IP67)
4 in 1 (4 signals switchable TVI/AHD/CVI/CVBS)
Downloads
TVI 2CE78U7T-IT3F Datasheet
Hikvision TVI 2CE79H8T-AIT3ZF 5MP Turret HD Camera, Motorised Vari-focal 2.7-13m, IR 60m, 4 in 1, AC/DC
5 MP high performance turret camera
Strong night performance, capturing images in ultra-low light down to 0.003 lux
Clear imaging even against strong back lighting due to 130 dB true WDR technology
3D DNR technology delivers clean and sharp images
Lens focuses automatically when zooming in or out
EXIR 2.0: advanced infrared technology with 60 m IR distance
Water and dust resistant (IP67)
4 in 1 (4 signals switchable TVI/AHD/CVI/CVBS)
Downloads
Hikvision TVI 2CE79H8T-AIT3ZF DatasheetHikvision TVI 2CE79H8T-AIT3ZF Quick Start GuideHikvision TVI 2CE79H8T-AIT3ZF User Manual
Hikvision TVI 2CE79U7T-AIT3ZF 8MP Turret HD Motorised Vari-focal Camera, 2.7-13.5mm, 4 in 1, IR 60m, VDC/VAC
8 MP high performance turret camera
Strong night performance, capturing images in ultra-low light down to 0.003 lux
Clear imaging even against strong back lighting due to 130 dB true WDR technology
3D DNR technology delivers clean and sharp images
Lens focuses automatically when zooming in or out
EXIR 2.0: advanced infrared technology with 60 m IR distance
Water and dust resistant (IP67)
4 in 1 (4 signals switchable TVI/AHD/CVI/CVBS)
Downloads
2CE79U7T-AIT3ZF Datasheet2CE79U7T-AIT3ZF Quick Start Guide2CE79U7T-AIT3ZF User Manual
Hikvision TVI ColorVu Turret DS-2CE72HFT-F28-2, 5 MP, 20m White Light, 2.8mm
Empower your security system with the Hikvision TVI ColorVu 5MP Turret Camera. Enjoy 24/7 full color imaging and clear, sharp images thanks to 130 dB true WDR and 3D DNR technology. The 20m warm supplemental light provides superior night vision, while the 4 in 1 function allows for versatile compatibility. Water and dust resistant for reliable outdoor use.
Features
5 MP full time color turret camera
24/7 full color imaging
2.8 mm fixed focal lens
Warm supplemental light with 20 m range
Clear imaging even against strong back lighting due to 130 dB true WDR technology
3D DNR technology delivers clean and sharp images
Water and dust resistant (IP67)
4 in 1 (4 signals switchable TVI/AHD/CVI/CVBS).
Downloads
DS-2CE72HFT-F28-2 DatasheetDS-2CE72HFT-F28-2 Quick Start GuideDS-2CE72HFT-F28-2 User Manual
HiLook CCTV Kit, 2 x 6 MP Fixed Turret Camera + 4 Channel 4K NVR
This kit comes with
2 x IPC-T269H-MU-SL-21 x NVR-104MH-C/4P with 2TB
The overview of the kit are outlined below. For additional specs, please click the SKU link.
HiLook IPC-T269H-MU/SL(2.8mm) 6 MP All-in-One Fixed Turret Network Camera 2 x IPC-T269H-MU-SL-2
High quality imaging with 6 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Human and vehicle targets classification based on deep learning
Active red and blue strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
24/7 colorful imaging
Smart Dual -light Supplement,auto switch IR to White light supplement when event triggered
Water and dust resistant (IP67)
HiLook NVR-104MH-C/4P 4-ch Mini 1U 4 PoE 4K NVR 1 x NVR-104MH-C/4P
Up to 4-ch IP camera inputs
H.265+/H.265/H.264+/H.264 video formats
Up to 1-ch@8 MP/3-ch@4 MP/6-ch@1080p decoding capacity
Up to 40 Mbps incoming bandwidth
This HiLook Security Camera Bundle come with one all-in-one CCTV camera, which features two-way audio, full colour night vision and audio alarm to warn off intruders. Plus, one standard AI security cameras which comes with real-time one-way audio from footage and IR night vision. You can choose NVR recorder as well, 4 Channel with 4 PoE ports. Add more storage to keep footage for longer periods. 2TB should cover one week for two camera system.
HILook 2 x 6MP Cameras CCTV Kit: 1 x Strobe & 1 x AI Turret Cameras + 4CH or 8CH NVR Bundle
1 x IPC-T269H-MU/SLHiLook IPC-T269H-MU/SL(2.8mm) 6 MP All-in-One Fixed Turret Network Camera, comes with Strobe Light, Two-way Audio and Audio Alarm.
High quality imaging with 6 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Human and vehicle targets classification based on deep learning
Active red and blue strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
24/7 colorful imaging
Smart Dual -light Supplement,auto switch IR to White light supplement when event triggered
Water and dust resistant (IP67)
1 x IPC-T262H-MUHiLook T262H-MU 6MP AI Turret Camera, Fixed 2.8mm, IR 30m, Mic, F1.6 Aperture
High quality imaging with 6 MP resolution
Support Human and Vehicle Intelligent Detection
Dual IR lights to enhance night vision
Built-in microphone for real-time audio security
Water and dust resistant (IP67)
Efficient H.265+ compression technology
1 x NVR-104MH-CHiLook NVR-104MH-C/4P 4-ch Mini 1 x HDD Bay, 4 x PoE Port, 4K NVR Recorder with 8MP Resolution, comes with 3 year warranty.
Up to 4-ch IP camera inputs
H.265+/H.265/H.264+/H.264 video formats
Up to 1-ch@8 MP/3-ch@4 MP/6-ch@1080p decoding capacity
Up to 40 Mbps incoming bandwidth
This HiLook security cameras bundle comes with four standard AI security cameras which comes with real-time one-way audio from footage and IR night vision. You can also choose NVR recorder: 4 Channel with 4 PoE ports or 8 Channel with 8 PoE ports. Add more storage to keep footage for longer periods. 3TB should cover one week for four camera system.
HILook 4 x 6MP Cameras & 4CH NVR CCTV Kit: 4 AI Turret Cameras + 4CH NVR Bundle
4 x IPC-T262H-MUHiLook T262H-MU 6MP AI Turret Camera, Fixed 2.8mm, IR 30m, Mic, F1.6 Aperture
High quality imaging with 6 MP resolution
Support Human and Vehicle Intelligent Detection
Dual IR lights to enhance night vision
Built-in microphone for real-time audio security
Water and dust resistant (IP67)
Efficient H.265+ compression technology
1 x NVR-104MH-C/4PHiLook 4-ch Mini 1 x HDD Bay, 4 x PoE Port, 4K NVR Recorder with 8MP Resolution, comes with 3 year warranty.
Up to 4-ch IP camera inputs
H.265+/H.265/H.264+/H.264 video formats
Up to 1-ch@8 MP/3-ch@4 MP/6-ch@1080p decoding capacity
Up to 40 Mbps incoming bandwidth
HILook 4 x 6MP Cameras & 8CH NVR CCTV Kit: 4 AI Turret Cameras + 8CH NVR Bundle
2 x IPC-T269H-MU/SLHiLook IPC-T269H-MU/SL(2.8mm) 6 MP All-in-One Fixed Turret Network Camera
High quality imaging with 6 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Human and vehicle targets classification based on deep learning
Active red and blue strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
24/7 colorful imaging
Smart Dual -light Supplement,auto switch IR to White light supplement when event triggered
Water and dust resistant (IP67)
2 x IPC-T262H-MUHiLook T262H-MU 6MP AI Turret Camera, Fixed 2.8mm, IR 30m, Mic, F1.6 Aperture
High quality imaging with 6 MP resolution
Support Human and Vehicle Intelligent Detection
Dual IR lights to enhance night vision
Built-in microphone for real-time audio security
Water and dust resistant (IP67)
Efficient H.265+ compression technology
1 x NVR-108MH-C/8PHiLook NVR-108MH-C/8P 8-ch 1U 8 PoE 4K NVR
Up to 8-ch IP camera inputs
H.265+/H.265/H.264+/H.264 video formats
Up to 1-ch@8 MP/3-ch@4 MP/6-ch@1080p decoding capacity
Up to 80 Mbps incoming bandwidth
This HiLook Security Camera Bundle come with one all-in-one CCTV camera, which features two-way audio, full colour night vision and audio alarm to warn off intruders. Plus, three standard AI security cameras which comes with real-time one-way audio from footage and IR night vision. You can choose NVR recorder as well, 4 Channel with 4 PoE ports or 8 Channel with 8 PoE ports. Add more storage to keep footage for longer periods. 3TB should cover one week for four camera system.
HILook 4 x 6MP Cameras CCTV Kit: 1 x Strobe & 3 x AI Turret Cameras + 4CH or 8CH NVR Bundle
1 x IPC-T269H-MU/SLHiLook IPC-T269H-MU/SL(2.8mm) 6 MP All-in-One Fixed Turret Network Camera, comes with Strobe Light, Two-way Audio and Audio Alarm.
High quality imaging with 6 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Human and vehicle targets classification based on deep learning
Active red and blue strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
24/7 colorful imaging
Smart Dual -light Supplement,auto switch IR to White light supplement when event triggered
Water and dust resistant (IP67)
3 x IPC-T262H-MUHiLook T262H-MU 6MP AI Turret Camera, Fixed 2.8mm, IR 30m, Mic, F1.6 Aperture
High quality imaging with 6 MP resolution
Support Human and Vehicle Intelligent Detection
Dual IR lights to enhance night vision
Built-in microphone for real-time audio security
Water and dust resistant (IP67)
Efficient H.265+ compression technology
1 x NVR-108MH-C/8PHiLook NVR-108MH-C/8P 8-ch 1U 8 PoE 4K NVR
Up to 8-ch IP camera inputs
H.265+/H.265/H.264+/H.264 video formats
Up to 1-ch@8 MP/3-ch@4 MP/6-ch@1080p decoding capacity
Up to 80 Mbps incoming bandwidth
HiLook CCTV Kit, 8 x 8 MP AI Fixed Turret Camera + 8 Channel 4K NVR
This kit comes with
4 x IPC-T281H-MU(2.8mm)
1 x NVR-108MH-C/8P
The overview of the kit are outlined below. For additional specs, please click the SKU link.
4 x IPC-T281H-MU(2.8mm)HiLook IPC-T281H-MU(2.8mm) 8 MP AI Fixed Turret Network Camera
High quality imaging with 8 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 120 dB WDR technology
Focusing on human and vehicle classification based on deep learning
-U: Built-in microphone for real-time audio security
Water and dust resistant (IP67)
1 x NVR-108MH-C/8PHiLook NVR-108MH-C/8P 8-ch 1U 8 PoE 4K NVR
Up to 8-ch IP camera inputs
H.265+/H.265/H.264+/H.264 video formats
Up to 1-ch@8 MP/3-ch@4 MP/6-ch@1080p decoding capacity
Up to 80 Mbps incoming bandwidth
HiLook CCTV Kit, 8 x 8 MP AI Fixed Turret Camera + 8 Channel 4K NVR
This kit comes with
8 x IPC-T281H-MU(2.8mm)
1 x NVR-108MH-C/8P
The overview of the kit are outlined below. For additional specs, please click the SKU link.
8 x IPC-T281H-MU(2.8mm)HiLook IPC-T281H-MU(2.8mm) 8 MP AI Fixed Turret Network Camera
High quality imaging with 8 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 120 dB WDR technology
Focusing on human and vehicle classification based on deep learning
-U: Built-in microphone for real-time audio security
Water and dust resistant (IP67)
1 x NVR-108MH-C/8PHiLook NVR-108MH-C/8P 8-ch 1U 8 PoE 4K NVR
Up to 8-ch IP camera inputs
H.265+/H.265/H.264+/H.264 video formats
Up to 1-ch@8 MP/3-ch@4 MP/6-ch@1080p decoding capacity
Up to 80 Mbps incoming bandwidth
HiLook IPC-T240H-MU(2.8mm) 4 MP Fixed Turret Network Camera
High quality imaging with 4 MP resolution
Efficient H.265+ compression technology
Clear imaging even with strong back lighting due to 120 dB WDR
Water and dust resistant (IP67)
EXIR 2.0: advanced infrared technology with long IR range
-U: Built-in microphone for real-time audio security
-U: Support up to 256 GB SD card storage
Camera
Image Sensor: 1/3" progressive scan CMOS
Max. Resolution: 2560 × 1440
Min. Illumination: Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR
Shutter Time: 1/3 s to 1/100,000 s
Day & Night: IR cut filter
Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Lens
Lens Type: Fixed focal length, 2.8 mm
Focal Length & FOV: 2.8 mm, horizontal FOV 98.0°, vertical FOV 53.1°, diagonal FOV 114.7°
Lens Mount: M12
Iris Type: Fixed
Aperture: F2.0
Illuminator
Supplement Light Type: IR
Supplement Light Range: Up to 30 m
Smart Supplement Light: Yes
IR Wavelength: 850 nm
Video
Main Stream: 50 Hz: 20 fps (2560 × 1440), 25 fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub-Stream: 50 Hz: 25 fps (640 × 480, 640 × 360)
Video Compression: Main stream: H.265/H.264/H.264+/H.265+
Sub-stream: H.265/H.264/MJPEG
Video Bit Rate: 32 Kbps to 8 Mbps
H.264 Type: Baseline Profile/Main Profile/High Profile
H.265 Type: Main Profile
Region Of Interest (ROI): 1 fixed region for main stream
Image Settings: Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
Day/Night Switch: Auto, Schedule, Day, Night
Wide Dynamic Range (WDR): 120 dB
Image Enhancement: BLC, 3D DNR
Interface
Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage: -U: Built-in memory card slot, support microSD card, up to 256 GB
Built-In Microphone: -U: Yes
Reset Key: -U: Yes
Download
Data Sheet
HiLook IPC-T269H-MU/SL(2.8mm) 6MP All-in-One Fixed Turret Network Camera
High quality imaging with 6 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong back light due to 120 dB true WDR technology
Human and vehicle targets classification based on deep learning
Active red and blue strobe light and audio alarm to warn intruders off
Provide real-time security via built-in two-way audio
24/7 colorful imaging
Smart Dual -light Supplement,auto switch IR to White light supplement when event triggered
Water and dust resistant (IP67)
Camera
Image Sensor: 1/2.4" Progressive Scan CMOS
Max. Resolution: 3200 × 1800
Min. Illumination: Color: 0.003 Lux @ (F1.6, AGC ON),0 Lux with white light B/W: 0 Lux with IR
Shutter Time: 1/3 s to 1/100,000 s
Day & Night: IR cut filter
Angle Adjustment: Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°
Lens
Lens Type: Fixed lens, 2.8, 4, and 6 mm optional
Iris Type: Fixed
Focal Length & FOV: 2.8 mm, horizontal FOV 105°, vertical FOV 55°, diagonal FOV 127°; 4 mm, horizontal FOV 78°, vertical FOV:38°, diagonal FOV 96°; 6 mm, horizontal FOV 51°, vertical FOV 26°, diagonal FOV 59°
Aperture: F1.6
Lens Mount: M12
Illuminator
Supplement Light Type: White light & IR
Supplement Light Range: IR Range: Up to 30m ; White light Range: Up to 30m
Smart Supplement Light: Yes
Day/Night Switch: Day,Night,Auto,Schedule
Image Enhancement: BLC,HLC,3D DNR
Image Settings: Mirror, saturation, brightness, contrast, sharpness, AGC, and white balance ajustable by client sfotware or web browser
Privacy Mask: 4 regions of privacy masks
Wide Dynamic Range (WDR): 120 dB
Download
Data Sheet
HiLook IPC-T281H-MU (2.8mm) 8 MP AI Fixed Turret Network Camera
High quality imaging with 8 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 120 dB WDR technology
Focusing on human and vehicle classification based on deep learning
-U: Built-in microphone for real-time audio security
Water and dust resistant (IP67)
Camera
Image Sensor: 1/2.8" Progressive Scan CMOS
Max. Resolution: 3840 × 2160
Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
Shutter Time: 1/3 s to 1/100,000 s
Day & Night: IR cut filter
Angle Adjustment: Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°
Lens
Lens Type: Fixed focal lens, 2.8 mm
Focal Length & FOV: 2.8 mm, horizontal FOV 107°, vertical FOV 57°, diagonal FOV 128°
Lens Mount: M12
Iris Type: Fixed
Aperture: F1.6
DORI
DORI: 2.8 mm: D: 88 m, O: 35 m, R: 17 m, I: 9 m
Illuminator
Supplement Light Type: IR
Supplement Light Range: Up to 30 m
Smart Supplement Light: Yes
IR Wavelength: 850 nm
Image Parameters Switch: Yes
Image Settings: Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night Switch: Day,Night,Auto,Schedule
Wide Dynamic Range (WDR): 120 dB
SNR: ≥ 52 dB
Image Enhancement: BLC,HLC,3D DNR
Privacy Mask: 4 programmable polygon privacy masks
Interface
Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
Built-In Microphone: -U: Yes
Reset Key: Yes
Downloads
Data Sheet
HiLook Pro IPC-T263H-MU 6MP AI Turret IP Camera, Fixed 2.8mm, IR 30m, Mic, F1.2 Aperture
Capture high-quality images with the HiLook Pro IPC-T263H-MU 6MP AI Turret IP Camera. Featuring a 2.8mm or 4mm lens and dual IR lights for enhanced night vision, this camera also supports intelligent detection of humans and vehicles. With a built-in microphone and IP67 rating for water and dust resistance, you can trust this camera for reliable and secure audio and video surveillance. Plus, its efficient H.265+ compression technology reduces storage space needed for recordings.
High quality imaging with 6 MP resolution
Support Human and Vehicle Intelligent Detection
Dual IR lights to enhance night vision
Built-in microphone for real-time audio security
Water and dust resistant (IP67)
Efficient H.265+ compression technology
Downloads
IPC-T263H-MU Datasheet
HiLook T262H-MU 6MP AI Turret Camera, Fixed 2.8mm, IR 30m, Mic, F1.6 Aperture
The HiLook T262H-MU 6MP AI Turret Camera offers high quality imaging with 6 MP resolution, dual IR lights for enhanced night vision, and a built-in microphone for real-time audio security. Its intelligent detection feature accurately identifies humans and vehicles, and its IP67 rating makes it suitable for outdoor use. With efficient H.265+ compression technology, it provides top-notch security while saving on storage space.
Features
High quality imaging with 6 MP resolution
Support Human and Vehicle Intelligent Detection
Dual IR lights to enhance night vision
Built-in microphone for real-time audio security
Water and dust resistant (IP67)
Efficient H.265+ compression technology
Downloads
IPC-T262H-MU Datasheet
