IDIS ENTERPRISE SERIES · NDAA & TAA COMPLIANT
Enterprise-Grade 64-Channel VMS Recording Solution
The IDIS IR-310D-4TB is a high-density, mission-critical 2U network video recording server engineered engineered for elite commercial, municipal, and industrial security ecosystems. Arriving pre-configured and ready to install with the robust IDIS Solution Suite (ISS) VMS architecture, this enterprise-tier hardware platform delivers seamless management for large-scale corporate deployments. Equipped with professional data security safeguards, high-throughput capabilities, and intelligent processing infrastructure, the server guarantees comprehensive coverage and unyielding video data retention for up to 64 Full HD network cameras simultaneously.
Optics & System
64Ch Full HD
Storage Base
4TB Enterprise
Protection
RAID & Redundant PSU
Advanced Video Management & Complete Interoperability
At its core, the server runs on a lightning-fast M.2 SSD configured exclusively for the optimized Microsoft Windows 10 IoT Enterprise operating system. This isolates critical software functions from the high-volume recording pipeline managed across the system's expansive drive configurations. To review or compare structural deployment variations, view the IDIS IR-310D-4TB profile. The system boasts exceptional backend processing versatility, delivering advanced server-side dewarping, integrated device health tracking, and full structural compatibility with legacy hardware, DirectCX TVR platforms, DirectIP NVR architectures, and mainstream ONVIF Profile S partner cameras.
Fail-Safe Hardware Redundancy
Engineered for mission-critical deployments where zero down-time is mandatory. The recording server is fortified with hot-swappable enterprise storage trays supporting hardware RAID 1, 5, and 10 configurations alongside dual 120W hot-swappable redundant power supplies to sustain uninterrupted uptime during component failures.
Intelligent Codec Storage Optimization
Leveraging advanced H.265 technology and IDIS proprietary Intelligent Codec, the recording platform reduces extreme bandwidth and physical storage loads by up to 90% compared to traditional H.264 compression models, dramatically lowering total cost of ownership without forfeiting video clarity.
Technical Specification Matrix
| Camera Model |
IR-310D-4TB |
| Video Management System |
IDIS Solution Suite (ISS) VMS Pre-installed |
| Recommended Camera Density |
Up to 64 Channels (Full HD Recording) |
| Maximum Recording Throughput |
Up to 400Mbps per server |
| System CPU / Processor |
Intel® Core™ i5-10500 Processor (3.1GHz) |
| System Memory |
16GB DDR4 PC-25600 RAM |
| Operating System Storage |
240GB M.2 Solid State Drive (SSD) |
| Internal Drive Capacity |
4TB Installed (8x SATA Ports Internal + 3x eSATA Expansion) |
| RAID Implementations |
Hardware RAID 1, RAID 5, RAID 10 (Hot-swappable) |
| Network Interfaces |
2x Gigabit Ethernet RJ-45 Ports (1000Base-T) |
| Display Outputs |
2x High-Definition HDMI Interfaces |
| Power Supply Units |
100-240V~ Dual Redundant Power Components (120W x 2) |
| Form Factor Dimensions |
2U Rackmount Chassis | 482.6mm x 88mm x 537mm |
Is the IDIS Solution Suite camera license package included with this server?
The IR-310D-4TB server model ships with the foundational IDIS Solution Suite software platform pre-loaded onto its dedicated M.2 solid-state drive for immediate hardware onboarding. However, individual device connection licenses must be purchased separately based on your specific camera deployment requirements.
How can the device storage profile be scaled in the future?
The physical 2U chassis accommodates up to 8 hot-swappable internal SATA storage hard drives. For further scalability, the backend features 3 active eSATA high-speed data expansion ports, enabling direct interfacing with secondary IDIS external disk enclosures to significantly expand long-term media archiving capabilities.
Does this device conform with strict legal government security procurement filters?
Yes. This enterprise platform is explicitly listed and certified as fully NDAA (National Defense Authorization Act) and TAA compliant. It features zero restricted components or chipsets from banned manufacturers, qualifying it perfectly for sensitive federal, government, defense, and premium corporate projects.
What third-party camera integration parameters are natively supported?
While optimized for unified native operation with standard IDIS edge hardware, the server provides full architectural compliance with ONVIF Profile S protocols. It features dedicated driver matching for major industry vendors including Axis, Arecont Vision, and Panasonic to maintain stable cross-brand interoperability.
