IDIS EDGE AI PLUS SERIES · FIPS 140-3 · NDAA & TAA COMPLIANT
6MP High-Density Forensic Clarity Infused with Advanced Edge AI Plus Analytics
The IDIS DC-T6631WRA represents a monumental leap forward in commercial edge intelligence, combining an ultra-high-definition 6MP optical pipeline with the industry-leading IDIS Edge AI Plus deep learning engine. Moving beyond simple pixel-shuffling motion tracking, this enterprise network bullet camera processes forensic metadata natively on the sensor—instantly isolating humans, vehicles, and faces while breaking down sophisticated structural attributes like clothing color, age groups, and vehicle types. Fully validated to rigorous military-grade FIPS 140-3 Level 3 cybersecurity thresholds, it offers a cyber-hardened, defense-ready hardware endpoint customized for critical infrastructure, government perimeters, and large-scale industrial arrays.
Intelligence
Edge AI Plus Attributes
Lens Architecture
4.3-9.8mm Motorized
Extreme Night IR
Up to 60m Smart IR
Cyber Security
FIPS 140-3 Compliant
Long-Range Vision Suppression Immunity & Extreme Environmental Armor
Outfitted with an advanced 4.3mm to 9.8mm motorized varifocal lens mechanism, the DC-T6631WRA facilitates precise optical configuration from a wide 110.4° horizontal overview down to a targeted 45° corridor perspective. Night operations are backed by 6 ultra-high-output adaptive IR LEDs that flood the target area up to an incredible 60 meters (196.8 feet) away, working in tandem with LightMaster NIR mechanics to suppress digital noise and artifact blowout in near-total darkness. Wrapped in an elite vandal-resistant IK10 shell with an integrated mechanical sunshield and internal heating elements, it guarantees structural runtime from -40°C up to +55°C. To formulate a zero-leak corporate protection array with autonomous tracking metrics, integrate this node into our broader IDIS security network.
Onboard Edge AI Plus Deep Learning Suite
Execute rapid forensic parsing without central processing server lag. The native AI engine handles real-time human attribute logging (gender, age, bag, hat, clothing colors), vehicle parameters (type, color), and face analytics, alongside specialized behavioral alerts like Crowd Detection and Fall Detection.
FIPS 140-3 Encryption & Smart Edge Failover
Secure the data stream with military-grade encryption keys while shielding evidence from system connectivity failures. If an upstream network dropout occurs, the camera automatically reroutes full-resolution frames into its internal MicroSD media slot (supporting up to 512GB), seamlessly syncing back when the network link stabilizes.
Technical Specification Matrix
| Camera Model |
DC-T6631WRA |
| Intelligence Processing |
IDIS Edge AI Plus Deep Learning Engine (Onboard Metadata Classification) |
| Cybersecurity Grade |
FIPS 140-3 Level 3 Crypto Module Validated / Chained Fingerprint Safeguard |
| Image Sensor |
1/2.8" Progressive Scan CMOS Sensor |
| Max. Resolution |
3328 x 1872 (6MP @ 30ips with True WDR Active) |
| Lens Configuration |
Motorized Varifocal f=4.3mm to 9.8mm / F1.5 to F2.8 (DC Iris) |
| Angular Field of View |
110.4° ~ 45.0° (Horizontal) / 57.7° ~ 25.0° (Vertical) / 132.0° ~ 51.5° (Diagonal) |
| Night Vision Range |
Up to 60 Meters (196.8 Feet) with 6 High-Output LightMaster NIR Smart IR LEDs |
| Wide Dynamic Range |
True WDR Processing Core (120dB) |
| Durability Ratings |
IP67 Weatherproof Shield / IK10 Vandal Proof / Built-in Enclosure Heater |
| I/O Interfaces |
Audio In/Out · Alarm In/Out · MicroSD Slot (Up to 512GB Edge Failover) |
| Power Architecture |
Power over Ethernet (PoE) IEEE 802.3af (Class 3) / 12V DC (Max. 11.5W) |
What operational edge does "Edge AI Plus" attribute classification give operators?
Standard motion filters only detect general movement, requiring security personnel to manually review hours of tape. Edge AI Plus extracts specific object properties—such as identifying a human in a blue jacket or a white truck—allowing instant forensic database sorting that reduces investigator response times to seconds.
Why is the FIPS 140-3 validation critical for enterprise and government platforms?
FIPS 140-3 Level 3 indicates that the camera uses certified hardware cryptographic modules to secure communication lines, password stores, and data structures. This prevents network interception and tampering, checking off compliance requirements for banking, utilities, and federal installations.
How does the 60-meter long-range IR system keep night scenes clean?
Unlike standard arrays that fade at long distances, this camera uses 6 heavy-duty Smart IR arrays paired with LightMaster NIR low-light intelligence. It projects usable light out to 60 meters while dynamically modifying intensity as objects approach, preventing near-field overexposure and washing out.
Can this camera operate in severe cold climates and withstand physical vandalism?
Yes. The heavy-duty structural build carries dual IP67 and IK10 ratings, ensuring protection against intense storms, water immersion, and physical impacts up to 20 joules. Additionally, the integrated internal heater allows it to operate down to -40°C without the lens cover icing over.
