Description
VORTEX FD839-EHTV-V2 5MP AI Dome Camera + 1-Year XPRO License Included
Premium imaging, advanced analytics and full cloud functionality — all in one.
The VORTEX FD839-EHTV-V2 is a high-performance 5 MP AI dome camera built for demanding commercial and industrial applications. Equipped with a motorised 2.8–12 mm P-iris vari-focal lens, WDR Pro, and Smart IR up to 40 m, it delivers excellent clarity in all lighting conditions. Its robust metal housing is rated IP66 for outdoor weatherproofing and IK10 for vandal resistance.
This package includes a 1-Year VORTEX XPRO Cloud License, enabling advanced cloud features such as smart AI search, extended analytics, remote monitoring from any device, secure backups, and real-time push notifications. Perfect for installers and businesses seeking a future-proof cloud-enabled surveillance solution.
Features
-
5 MP high-resolution imaging – 2560×1920 clarity for forensic detail.
-
Motorised 2.8–12 mm lens – remote zoom & focus for flexible installations.
-
WDR Pro + low-light performance – balanced imaging in challenging light.
-
Smart IR up to 40 m – clear nighttime visibility.
-
IP66 & IK10 protection – built tough for outdoor and high-risk areas.
-
Built-in 256 GB storage – industrial-grade edge recording.
-
1-Year XPRO Cloud License – unlocks AI analytics, cloud storage & mobile access.
-
NDAA/TAA compliant – approved for secure government and enterprise use.
Perfect for retail, warehouses, corporate campuses, schools, logistics centres and premium residential installs.
Why choose the VORTEX FD839-EHTV-V2?
Unlock next-level surveillance performance with this advanced 5 MP AI dome camera, engineered for demanding environments and critical installations.
-
High resolution imaging: Delivers 2560 × 1920 resolution for crisp detail capture—even at distance.
-
Vari-focal lens (2.8-12 mm): Provides flexible field-of-view ranging from ~95° wide to ~28° narrow, ideal for both general and targeted coverage.
-
Robust day/night performance: With WDR Pro, Smart IR up to 40 m, color at 0.04 lux and B/W down to 0.005 lux—ensuring clarity in low-light and high contrast scenes.
-
All-weather & impact-resistant build: Rated IP66 for outdoor weatherproofing and IK10 for vandal resistance—perfect for industrial, retail or perimeter use.
-
Enterprise-grade security & compliance: Includes secure-boot, signed firmware, HTTPS/TLS encryption, full NDAA/TAA, FCC/CE/UL/RCM certifications—engineered for mission-critical deployments.
-
Seamless cloud integration: Designed to work with the VORTEX platform for remote-monitoring, AI analytics (intrusion/line-crossing/loitering), push notifications and mobile access for “monitor anywhere, anytime, any device.”
-
Long-term peace of mind: Up to 10 year warranty when used with the appropriate license—reduce total cost of ownership and avoid frequent replacement.
Typical Applications
Ideal for retail environments, logistics & warehousing, large-scale property management, corporate campuses, and any location requiring reliable analytics and future-proof surveillance.
What’s in the box
Quick installation guide, alignment sticker, screw pack, L-shaped wrench.
Technical Specifications
| Feature |
Specification |
| Model |
VORTEX FD839-EHTV-V2 5 MP AI Dome Camera |
| Included License |
1-Year VORTEX XPRO Cloud License (AI analytics, remote access, smart search, cloud recording support) |
| Image Sensor |
1/2.8" Progressive CMOS |
| Resolution |
2560×1920 (5 MP) |
| Lens |
Motorised vari-focal 2.8–12 mm, P-iris, remote focus |
| Field of View |
95.4°–28.7° (H), 68.8°–21.5° (V), 129.6°–35.9° (D) |
| IR Range |
Up to 40 m Smart IR |
| Minimum Illumination |
0.04 lux (Color)
0.005 lux (B/W)
0 lux with IR |
| Wide Dynamic Range |
WDR Pro |
| Frame Rate |
15 fps @ 2560×1920 |
| Storage |
Built-in 256 GB industrial-grade SDXC |
| Audio |
Built-in microphone; two-way audio supported with cable (AO-015) |
| Network |
10/100 Mbps Ethernet, RJ-45, IEEE 802.3af PoE |
| Power |
PoE Class 3; Max 12.4 W |
| Operating Temperature |
-35°C to 60°C |
| Weather / Impact Rating |
IP66, IK10 metal housing |
| Compliance |
FCC, CE, UL, RCM, NDAA, TAA |
| Dimensions |
Ø 134 × 116 mm |
| Weight |
Approx. 990 g |
