Description
The Uniview UNV IPC3636SE-ADF28K-WP-I1 is a premium 6 MP OwlView Plus turret network cameraengineered for vivid 24/7 full-colour surveillance and advanced smart detection. Featuring Wise-ISP ColorHuntertechnology and a bright F1.0 2.8 mm wide-angle lens, this camera delivers rich, detailed footage in low-light conditions without sacrificing colour integrity. It supports Ultra 265/H.265/H.264/MJPEG compression, intelligent perimeter protection with false alarm filtering, people flow counting, and warm white light illumination up to ~30 m. With IK10, IP67, and NEMA 4X durability, plus support for microSD up to 512 GB, it’s ideal for retail, commercial, perimeter, and property monitoring.
Key Features
-
6 MP (3072×2048) high-resolution imaging with triple stream support.
-
ColorHunter + Wise-ISP for true full-colour day/night video.
- Bright F1.0 2.8 mm wide-angle lens for broad coverage.
-
130 dB true WDR improves detail in high-contrast scenes.
-
Warm white light up to ~30 m for colour night visibility.
-
Smart perimeter protection: cross line, intrusion, enter/leave area with target classification and false alarm reduction.
-
People flow counting and crowd density analytics.
-
Smart IR / warm light day/night transition.
-
Audio & alarm I/O (1/1) with built-in mic.
-
Edge storage: microSD up to 512 GB (ANR/NAS).
-
Durability: IK10 impact, IP67 water/dust, NEMA 4X.
-
Power options: PoE (802.3af) or 12 V DC.
Specifications
| Brand / Model (SKU) |
Uniview UNV / IPC3636SE-ADF28K-WP-I1 |
| Camera Type |
OwlView Plus fixed turret |
| Max Resolution |
6 MP (3072×2048) |
| Image Sensor |
High-quality CMOS with ColorHunter + Wise-ISP |
| Lens |
Fixed 2.8 mm, F1.0 |
| Wide Dynamic Range |
130 dB true WDR |
| Warm Light Distance |
Up to ~30 m |
| Video Compression |
Ultra 265 / H.265 / H.264 / MJPEG |
| Smart Analytics |
Perimeter protection (line/intrusion/enter/leave), people count, crowd density |
| Audio & I/O |
Audio I/O 1/1; built-in microphone; Alarm I/O 1/1 |
| Edge Storage |
microSD up to 512 GB; ANR/NAS |
| Protection |
IP67, IK10, NEMA 4X |
| Power |
PoE (802.3af) / 12 V DC |
Recommended Use Cases
-
Retail & Hospitality – 24/7 full-colour evidence, excellent face and clothing detail under low light.
-
Car Parks & Perimeters – Wide 2.8mm view with warm white light (30m) for colour identification at night.
-
Offices & Warehouses – 130 dB WDR handles backlight; IK10/IP67/NEMA 4X suits harsh environments.
-
Schools & Public Spaces – People flow counting and crowd density analytics for safety and operations.
-
Residential (Premium) – Bright F1.0 lens with quiet illumination (white light) for clear night footage.
Pair With: Uniview UNV AI NVRs (Prime IQ series) to unlock advanced analytics, Smart Search, and efficient Ultra 265 storage.
More Information
IPC3636SE-ADF28K-WP-I1 Datasheet
UNV PoE Camera Quick Start Guide
UNV Network Camera User Manual
