Ubiquiti UniFi Protect · NDAA & TAA COMPLIANT
Modernize Legacy Intrusion Security With Enterprise-Grade Intelligence
The Ubiquiti UP-AlarmHub-Kit bridges traditional hardwired intrusion detection architectures directly into the unified UniFi Protect ecosystem. Designed for high-density commercial spaces, schools, offices, and industrial facilities, this robust 32-zone control hub allows organizations to retain existing wired door contacts, glass break detectors, and PIR sensors while migrating to a centralized, subscription-free management interface.
Zone Capacity
32 Hardwired Zones
Power Architecture
PoE++ / 12V SLA Backup
Platform Integration
UniFi Protect Native
Enclosure Build
SGCC Steel Housing
Seamless Ecosystem Synchronization and Resilient Power Distribution
Engineered for maximum reliability, the UP-AlarmHub-Kit incorporates advanced auxiliary power capabilities, delivering dedicated 12V DC sensor power rails alongside programmable wet and dry output relays for complete automation control. Administrators can easily configure end-of-line (EOL) resistor values ranging from 1 to 5.6kΩ for optimal circuit health monitoring. Explore the full scope of system integration options through our Ubiquiti security hardware collection.
Comprehensive Zone Configuration
Features 32 individual alarm sensor input terminals plus 1 dedicated emergency trigger line, accommodating expansive layouts without requiring layout redesigns.
Fail-Safe Battery Backup Support
Designed with support for an optional 12V sealed lead-acid (SLA) backup battery and flexible PoE++ or PoE+++ power feeds to maintain critical intrusion monitoring during grid outages.
Technical Specification Matrix
| Model |
UP-AlarmHub-Kit |
| Input Terminals |
32 Alarm sensor inputs, 1 Emergency input |
| Power Method |
PoE++ / PoE+++ input, optional 12V SLA battery backup |
| Networking Interface |
(1) 10/100 MbE RJ45 port |
| Enclosure Material |
SGCC steel housing with polycarbonate cover |
| Output Relays |
(2) Configurable Wet/Dry relays (Wet: 12V DC 1A, Dry: 30V DC 1A) |
| Dimensions |
379 x 355 x 105 mm (15 x 14 x 4.1 inches) |
| NDAA Compliance |
Compliant |
Can I use my existing legacy hardwired window and door contacts?
Yes. The UP-AlarmHub-Kit is explicitly engineered to interface with legacy hardwired sensors, supporting standard EOL resistor ranges from 1 to 5.6kΩ.
What software version is required to adopt the alarm hub?
The device requires UniFi Protect version 7.0.88 or later, along with matching mobile application updates for seamless mobile oversight.
Does the system support backup power during unexpected blackouts?
Yes, the unit features integrated charging support for a 12V sealed lead-acid (SLA) backup battery alongside PoE++ power inputs.
Is this hardware package compliant with federal NDAA regulations?
Yes, the UP-AlarmHub-Kit is fully NDAA compliant, satisfying deployment guidelines for government, corporate, and institutional projects.
