Ubiquiti Accessories Series · NDAA COMPLIANT
Seamless Outdoor Ethernet Range Extension with Passthrough Power
The Ubiquiti UACC-AE is an NDAA-compliant, high-performance outdoor Gigabit Ethernet repeater designed to bypass standard 100-meter (328 ft) twisted-pair cable distance limitations. Engineered for enterprise network extensions, government installations, remote IP surveillance deployments, and outdoor wireless access point links, the UACC-AE receives passive or active Power over Ethernet and passes it through to downstream network devices, delivering robust gigabit connectivity in harsh environments without requiring local AC power infrastructure.
Speed / Capability
1 GbE / +100m Extension
Interface
2x RJ45 GbE Ports
Power Delivery
PoE Passthrough Support
Weather Rating
IPX5 Weatherproof
Industrial-Grade Outdoor Deployment & Low-Latency Throughput
Built for demanding perimeter environments and government security compliance, the Ubiquiti UACC-AE ensures uninterrupted data transport across extended physical topologies. By conditioning signal strength inline, it maintains full 10/100/1000 Mbps line-rate transmission without adding noticeable packet latency. Its integrated surge-suppression capabilities and UV-stabilized IPX5 enclosure make it an ideal drop-in inline repeater for long-distance perimeter security cameras, outdoor UniFi Access Points, and commercial ISP building-to-building links.
Extended 100m Network Range
Cascades inline between copper Ethernet runs to add an additional 100 meters of distance without sacrificing Gigabit throughput or signal integrity.
Inline PoE Passthrough Operation
Operates entirely off incoming Power over Ethernet (PoE), drawing low operational power while passing remaining voltage directly to downstream devices.
IPX5 Outdoor Weather Resistance
Housed in a ruggedized, UV-protected shell engineered to protect internal components against rain, dust, wind, and extreme outdoor temperature swings.
Plug-and-Play Architecture
Requires zero software configuration—simply connect incoming and outgoing RJ45 network cables to immediately extend network reach and inline power.
Technical Specification Matrix
| Model |
UACC-AE |
| NDAA Compliance |
Confirmed Compliant (Yes) |
| Network Interfaces |
(2) 10/100/1000 Mbps RJ45 Ethernet Ports |
| Max Range Extension |
100 m (328 ft) per unit |
| Power Method |
PoE / Passive PoE Input |
| PoE Passthrough |
Supported (Dependent on input PoE budget) |
| ESD/EMP Protection |
Air / Contact Protection Included |
| Enclosure Material & Rating |
Polycarbonate, IPX5 Weatherproof |
| Operating Temperature |
-40°C to 70°C (-40°F to 158°F) |
Is the Ubiquiti UACC-AE NDAA compliant?
Yes, the UACC-AE is explicitly designated as NDAA compliant by Ubiquiti, making it suitable for US federal projects, government contracts, and enterprise sites requiring compliance.
Does the Ubiquiti UACC-AE require a dedicated power supply?
No, the unit is powered directly via incoming Power over Ethernet (PoE). It draws minimal power to operate its internal signal amplification circuitry and passes the remaining power through to the connected endpoint device.
How far can I extend my network using the UACC-AE?
A single UACC-AE unit adds up to 100 meters (328 ft) to a standard Ethernet cable run, doubling the effective maximum link distance to 200 meters from the switch source.
Can I install the UACC-AE directly outdoors in rain and snow?
Yes, the UACC-AE features an IPX5-rated weatherproof housing designed specifically for exterior wall or pole installations subject to weather exposure.
