Ubiquiti UniFi · NDAA & TAA COMPLIANT
Enterprise-Grade Infrastructure Housing: UACC-Rack-42U-800-P
Engineered for high-density networking, telecommunications, and security deployments, the Ubiquiti UACC-Rack-42U-800-P provides a robust 42U structural framework built to securely house core UniFi switches, patch panels, and server hardware. Designed for professional server rooms and enterprise distribution nodes, this enclosure combines heavy-duty SPCC steel construction with optimized airflow architecture and secure, lockable access points to safeguard critical hardware infrastructure.
Rack Height
42U Enclosure
Load Capacity
800 kg Static
Cabinet Depth
800 mm Footprint
Compliance
NDAA Compliant
Optimized Thermal Regulation & Modular Deployment
Maintaining optimal operating temperatures for dense switching matrices and heavy-load processing hardware is critical. The UACC-Rack-42U-800-P incorporates high-airflow perforated door variants designed to maximize cross-cabinet ventilation. Its adaptable internal rail system features customizable mounting depths with precise 15 mm pitch increments, accommodating standard patch hardware as well as extended-depth enterprise network appliances seamlessly while maintaining strict compliance frameworks.
Heavy-Duty SPCC Steel Build
Constructed from industrial-grade cold-rolled steel with reinforced multi-thickness post frames (up to 2 mm thickness), ensuring long-term structural integrity and support for up to 800 kg of static weight.
Complete Security & Access Control
Features integrated multi-point key locks across the reversible main doors and removable side panels, preventing unauthorized physical tampering with mission-critical core routing hardware.
Technical Specification Matrix
| Model |
UACC-Rack-42U-800-P |
| Rack Height |
42U |
| Enclosure Material |
SPCC Steel (Body: 1mm, Posts: 2mm, Doors/Panels: 1.2mm) |
| Static Load Capacity |
800 kg (1,764 lb) |
| Rolling Load Capacity |
320 kg (705 lb) |
| Dimensions (W x D x H) |
600 x 800 x 1,966 mm (Without Casters) |
| Adjustable Mounting Depth |
Default 607.2 mm to Max 682.2 mm (15 mm pitch) |
| Regulatory Compliance |
NDAA Compliant, CE, EIA/ECA-310-E, RoHS |
Is the UACC-Rack-42U-800-P shipped fully assembled?
Yes, this enclosure arrives ready for deployment to minimize integration time and labor costs on site, complete with pre-installed leveling stands and heavy-duty casters.
What is the maximum static weight load supported?
The cabinet supports up to 800 kg (1,764 lb) of static load configuration, making it fully capable of handling dense multi-tier switch stacks and heavy UPS backups.
Are the doors and side panels removable?
Yes, all side panels are completely removable and lockable, and both the front and rear doors feature reversible hinges to fit constrained server room layouts.
Does this rack meet federal compliance requirements?
Yes, the unit is fully NDAA compliant, satisfying stringent supply chain regulations for corporate, educational, and government project installations.
