IDIS DC-U6K31WRA 20MP AI Multi-Directional Camera

Description

IDIS MULTI-DIRECTIONAL SERIES · NDAA & TAA COMPLIANT

Next-Generation 20MP Panoramic Intelligence for Complete High-Density Situational Awareness

The DC-U6K31WRA represents the pinnacle of commercial-grade wide-area surveillance, combining four independent 5-Megapixel sensors into a single, high-efficiency housing to achieve an ultra-high-definition 20-Megapixel multi-directional footprint. Explicitly engineered for demanding enterprise environments such as large logistics yards, transit hubs, massive retail concourses, and critical perimeter layouts, this flagship multi-sensor array replaces up to four standard cameras. By combining a dense hardware footprint with a single network drop, it slashes license and physical installation infrastructure costs while safeguarding expansive property zones simultaneously.

Resolution
20MP (4 x 5MP Sensors)
Optics
Remote Motorized Focus/Zoom
Night Vision
Triple IR LEDs up to 25m
Protection
IP-Rated Weather Proof

Deep Learning On-Edge Analytics and Seamless DirectIP Architecture

At the core of this multi-directional imaging platform is the IDIS Deep-Learning Analytics (IDLA) engine, which converts raw video capture into highly accurate, real-time security events. Operators can deploy advanced geometric line-crossing triggers, multi-zone intrusion algorithms, and tracking criteria directly across all four sensors without relying on separate heavy analytical servers. Bandwidth utilization remains incredibly efficient thanks to a dynamic combination of native H.265 processing and IDIS Intelligent Codec technology. This ecosystem configures automatically with zero-stress deployment parameters when connected through standard protocols available at the official IDIS DC-U6K31WRA Hub.

Four Independent Motorized Gimbal Fields

Achieve unparalleled custom tracking setups with individual control over each sensor. Each of the four 5MP lenses features full remote motorized zoom and focus capabilities, letting security technicians pinpoint completely separate blind spots or form tight overlapping fields from an off-site control station.

High-Efficiency Power Over Ethernet Delivery

Streamline hardware installation pipelines with singular infrastructure pathways. Even when managing four distinct operational imaging streams, integrated AI computing chips, and dynamic night vision illumination, the complete system runs optimally using a standard PoE (IEEE 802.3at Class 4) network connection.

Technical Specification Matrix
Camera Model DC-U6K31WRA
Sensor Configuration 4 x Progressive Scan CMOS Sensors
Total Operational Resolution 20 Megapixel (5MP per channel)
Lens System Remote Motorized Varifocal Focus & Zoom Lenses
Video Compression H.265 / H.264 / Intelligent Codec
Artificial Intelligence Engine Embedded IDIS Deep-Learning Analytics (IDLA)
Infrared Illumination 3x High-Intensity Target IR LEDs (25m / 82ft Range)
Network Integration DirectIP NVR Plug-and-Play, ONVIF Profile S/T Compliant
Power Requirement PoE (IEEE 802.3at Class 4)
Environmental Rating Industrial Weather Proof Design
Does this camera comply with federal government purchasing constraints?

Yes. The DC-U6K31WRA is fully NDAA and TAA compliant. It completely avoids electronic components or chipsets sourced from blacklisted or restricted manufacturers, making it perfectly approved for deployment across critical infrastructure, defense, municipal, and institutional projects.

How does a multi-directional camera save system integration budget?

Because it operates as four separate 5MP cameras inside a single mechanical housing, it utilizes only a single VMS license on DirectIP systems, requires only one physical Ethernet cable drop, and consumes just one PoE switch port, vastly reducing deployment costs.

Can each individual sensor be adjusted independently from software?

Yes. Security personnel do not need to scale ladders or manually adjust physical lenses. Each sensor is built into an independent internal track equipped with remote motorized zoom and focus controls, enabling easy adjustments via the NVR or remote workstation software.

How does the integrated IR illumination handle target environments?

The unit features three high-performance onboard infrared LED modules strategically distributed to cast even illumination over a distance of up to 25 meters (82 feet). This guarantees clean and crisp night recording across complex, dark, low-lux external scenarios.

Technical Datasheet Quick Start Guide
Operation Manual Installation Manual
Official IDIS Stock
NDAA & TAA Certified
Aust-Wide Delivery

IDIS DC-U6K31WRA 20MP AI Multi-Directional Camera

Product form

SKU: DC-U6K31WRA

IDIS MULTI-DIRECTIONAL SERIES · NDAA & TAA COMPLIANT Next-Generation 20MP Panoramic Intelligence for Complete High-Density Situational Awareness The DC-U6K31WRA represents... Read more

$2,799.00 Incl. GST
