IDIS CONTERAIP OMNI LX · NDAA & TAA COMPLIANT
Next-Generation Panoramic Coverage: Maximum Situational Awareness
The IDIS AV20576DN-28 is a flagship 20-megapixel panoramic network camera designed to provide total spatial clarity across expansive commercial footprints. Featuring four independent 5MP progressive scan CMOS image sensors inside an ultra-low profile, discrete enclosure, this multi-sensor powerhouse eliminates traditional site blind spots while significantly reducing device installation counts, network drop requirements, and system licensing fees. It is uniquely engineered for high-density settings such as corporate campuses, municipal intersections, logistics hubs, and massive parking environments where seamless, continuous perimeter protection is mandatory.
Night Vision
NightView™ Low-Light
Protection
IP66 / IK10 Rated
Advanced Engineering for Dynamic Security Architectures
The system incorporates a highly versatile 3-axis tracking gimbal platform, enabling the four internal miniature multi-sensor gimbals to be manually and independently positioned anywhere along a 360-degree circular track. The design includes specialized layout variations allowing individual sensors to tilt and pivot straight down, making the AV20576DN-28 an ideal solution for critical hallway intersections or wall-mounted perimeters. Enhanced by SNAPstream+™ intelligent compression technology, this network camera drastically minimizes required data bandwidth and primary edge-storage consumption without undercutting the impeccable detail delivered by its multi-stream H.265 engine.
Customized Field of View Flex
Configure complete panoramic coverage, 270-degree corner tracking, or strict intersection cross-mapping from one terminal. Four separate gimbals enable targeted focus configurations that drastically optimize infrastructure ROI.
NightView™ Forensic Accuracy
Engineered for high performance in extremely poor lighting conditions, proprietary NightView technology maintains crisp, high-contrast color imagery down to ultra-low lux levels, ensuring critical forensic identifiers are never lost.
Technical Specification Matrix
| Camera Model |
AV20576DN-28 |
| Total Image Resolution |
20 Megapixel (4x 2592 x 1944 Active Sensors) |
| Optics & Lens Assembly |
4x 2.8mm Fixed Focal Lenses (F1.6 Autofocus Backing) |
| Minimum Illumination |
Color: 0.15 Lux / Black & White: 0.015 Lux (NightView Mode) |
| Dynamic Range & Logic |
True Wide Dynamic Range (WDR) up to 100dB |
| Video Compression Encoding |
H.265 / H.264 / M-JPEG with SNAPstream+™ Optimization |
| Maximum System Frame Rate |
15 Frames Per Second at Full 20MP Output Grid |
| Local Edge Storage Backing |
MicroSDXC Slot supporting up to 1TB expansion capacity |
| Environmental Enclosure |
IP66 Weather-Proof & IK10 Vandal-Resistant Housing Protection |
| Power Architecture Requirements |
PoE+ (IEEE 802.3at), 12V-48V DC, or 24V AC (Max 14W consumption) |
Can the AV20576DN-28 capture footage looking straight down?
Yes. The camera's innovative 3-axis tracking gimbal system includes modular positions along its track that allow individual sensor optics to be pivoted completely straight down, making it perfect for multi-directional corridor configurations or wall mount setups.
How does this unit optimize data throughput on a typical network?
The multi-sensor camera utilizes a triple-stream encoder paired with IDIS SNAPstream+™ technology. This intelligent algorithm dynamically analyzes moving pixel blocks and reduces throughput in static regions, reducing massive 20MP bandwidth limits without degrading vital video targets.
Does this camera operate reliably under extreme climate exposures?
Absolutely. Backed by full IP66 environmental ingress ratings and a heavy-duty IK10 impact-resistant shell, the camera safely operates inside a punishing temperature range between -40°C (-40°F) and +50°C (122°F).
Is the AV20576DN-28 compliant for official government enterprise infrastructure?
Yes. This camera is completely NDAA (National Defense Authorization Act) and TAA compliant, making it fully authorized for highly regulated deployments across municipal, government, defense, and high-security critical installations.
