Hikvision NDR-240-48 240W 48V Single Output Industrial DIN Rail Power Supply

Description

Hikvision Industrial Series

Heavy-Duty 240W 48V Industrial DIN Rail Power Supply

Ensure uninterrupted operation across critical security infrastructure and industrial networks with the Hikvision NDR-240-48. Designed for demanding commercial and industrial enclosures, this high-performance 240W single-output power supply converts universal AC input voltages into a stable 48 VDC output. Engineered with an ultra-slim metal housing to conserve valuable enclosure rail space, it delivers continuous power to PoE network switches, security controllers, PTZ cameras, and edge computing equipment deployed in extreme environments.

Power & Output
240W / 48V DC / 5A
AC Input Range
90 to 264 VAC Universal
Operating Efficiency
Up to 88.5% High Efficiency
Protection Suite
Short Circuit / Overload / OVP / Temp

Built-in Active PFC & TS-35 Rail Mountability

Engineered for maximum electrical stability, the NDR-240-48 features built-in active Power Factor Correction (PFC) to maintain power efficiency and comply with strict industrial power standards. Its robust metal chassis easily snaps onto standard TS-35/7.5 or TS-35/15 DIN rails, drastically reducing installation time in control panels and outdoor NEMA-rated field cabinets. With convection cooling operating from -20°C to +70°C, this power supply provides dependable operation without requiring active fan ventilation.

Slimline Metal Enclosure Design

Featuring a narrow 63mm width, this power unit maximizes space on crowded DIN rails, allowing security integrators to fit more transmission components, circuit breakers, and terminal blocks within a single enclosure.

Comprehensive Electrical Protections

Includes automated protection against short circuits, overloads, overvoltage, and over-temperature conditions, safeguarding connected surveillance hardware against grid fluctuations and field electrical anomalies.

Technical Specification Matrix
Power Supply Model NDR-240-48
Rated Power Output 240 W
DC Output Voltage 48 VDC
Rated Current 5 A
Input Voltage Range 90 to 264 VAC / 127 to 370 VDC
Efficiency (Typ.) 88.5%
Voltage Adjustment Range 48 to 55 VDC
Mounting Format DIN Rail TS-35/7.5 or TS-35/15
Operating Temperature -20°C to +70°C (-4°F to +158°F)
Dimensions (W × H × D) 63 mm × 125.2 mm × 113.5 mm

Frequently Asked Questions

Can the output voltage be adjusted on the NDR-240-48?

Yes, the front panel includes an adjustable DC voltage potentiometer allowing fine-tuning of the output voltage between 48 VDC and 55 VDC to account for long cable runs.

Is active cooling required for this power supply?

No, the unit relies on free air convection cooling within its rugged metal chassis, allowing fanless operation across a wide temperature range from -20°C to +70°C.

What equipment can be powered by this 48V power supply?

It is designed to power industrial PoE switches, hardened media converters, access controllers, and 48V security equipment mounted inside DIN rail field cabinets.

Does this unit feature Power Factor Correction (PFC)?

Yes, it includes built-in active PFC (Power Factor Correction), providing an optimized power factor under full load to reduce harmonic distortion and energy losses.

Technical Datasheet
Official Hikvision Stock
Commercial Warranty
Aust-Wide Delivery

Hikvision NDR-240-48 240W 48V Single Output Industrial DIN Rail Power Supply

Product form

SKU: NDR-240-48-HIK

$179.00 Incl. GST
