4-Camera Kit · Dahua 6MP TiOC · Active Deterrence · 24/7 Full Colour · Two-Way Audio
Dahua 4 × 6MP TiOC Full Colour CCTV Kit — Active Deterrence + Two-Way Audio + 4CH NVR or 8CH AcuPick NVR
The Dahua 4 × 6MP TiOC Full Colour CCTV Kit is the most capable plug-and-play surveillance kit for Australian homes and businesses that want cameras that don’t just record — they respond. Four DH-IPC-HDW3649H-AS-PV-ANZ-S2 TiOC cameras combine 6MP full-colour 24/7 footage, built-in siren and red/blue strobe lights, and two-way audio to actively deter intruders the moment they’re detected — before they act.
Choose the 4-channel NVR (DHI-NVR4104HS-P-AI/ANZ) for a compact home or small business setup, or upgrade to the DHI-NVR5208-8P-AI/ANZ — an 8-channel AcuPick AI NVR with 8 PoE ports, 2 HDD bays, face recognition, and full AcuPick footage search. HDD not included.
Resolution
6MP · 3072×2048
Night Vision
Full Colour 24/7
Deterrence
Siren + Red/Blue Strobe
Australian Stock · Fast Dispatch
Expert Australian Tech Support
What’s Included in This Kit
4 × DH-IPC-HDW3649H-AS-PV-ANZ-S2 — 6MP TiOC Turret Camera6MP (3072 × 2048) full-colour turret with
built-in siren, red/blue strobe lights, dual microphone, and 1-ch speaker for active deterrence and two-way talk. Dual illuminators (IR 30m + warm light 30m) for 24/7 full-colour night vision. MicroSD up to 256GB, SMD 4.0, AcuPick-capable, IP67, PoE/12V DC.
NVR Option A — DHI-NVR4104HS-P-AI/ANZ (4CH · No AcuPick)4-channel compact AI NVR with
4 built-in PoE ports, supports cameras up to 16MP, 4K HDMI output, SMD 4.0, perimeter protection, 1× SATA HDD bay (up to 10TB, not included), DMSS remote access, ONVIF, fanless compact 1U design.
Best for compact installs. AcuPick not supported.
NVR Option B — DHI-NVR5208-8P-AI/ANZ (8CH · AcuPick ✓)8-channel AcuPick AI NVR with
8 built-in PoE ports, 2× SATA HDD bays (up to 16TB each), 4K HDMI output,
full AcuPick footage search, face detection and recognition, SMD+, perimeter protection, DMSS remote access, ONVIF.
4 spare PoE ports for future camera expansion. Best for AcuPick and scalability.
What You’ll Need to Complete the InstallHDD (not included): 1× SATA surveillance-grade HDD (Option A: up to 10TB) or up to 2× SATA (Option B: up to 16TB each) — we recommend WD Purple or Seagate SkyHawk. Cable (not included): Cat5e or Cat6 Ethernet — one run per camera, max 100m each. Monitor (optional): Any HDMI display for local viewing.
Key Features
TiOC Active Deterrence — Cameras That Stop IntrudersThese cameras don’t just record — they
respond. When SMD 4.0 detects a human or vehicle, the
DH-IPC-HDW3649H-AS-PV-ANZ-S2 simultaneously triggers a
siren, red/blue strobe lights, and a two-way voice warning. Most intruders leave before they’ve taken a step.
AcuPick — Find Any Person or Vehicle in Seconds (Option B)AcuPick is Dahua’s AI-powered footage search engine. Select a person or vehicle from any snapshot and the
DHI-NVR5208-8P-AI/ANZ instantly finds every matching clip across all cameras — by clothing colour, vehicle type, plate, or body attributes. No manual scrubbing. Critical for post-incident investigation, insurance claims, and police reports.
AcuPick requires Option B NVR.
24/7 Full Colour Night Vision — No Black-and-White IRBoth IR (30m) and warm light (30m) illuminators deliver full-colour footage in complete darkness — not the black-and-white IR footage of standard cameras. Colour footage captures clothing colour, vehicle colour, and facial features that IR footage misses entirely.
6MP Resolution — See Every DetailAt 3072 × 2048 pixels, each camera captures significantly more detail than 1080p or 5MP cameras. Faces at the front door, licence plates in the driveway — all clearly identifiable in recorded footage at 25/30fps.
SMD 4.0 — AI That Only Alerts on Humans and VehiclesDahua’s Smart Motion Detection 4.0 uses deep learning to classify motion as human or vehicle — ignoring animals, foliage, rain, and passing headlights. Dramatically reduces alarm fatigue.
Face Detection & Recognition (Option B)The
DHI-NVR5208-8P-AI/ANZ adds
face detection and recognition — build face databases, receive alerts when known faces appear, and search footage by face. Ideal for access control integration and high-security commercial deployments.
Two-Way Audio — Speak Through the CameraEach camera includes a built-in dual microphone and 1-ch speaker for two-way audio. Speak to visitors, warn intruders, or communicate with staff — directly through the camera from the DMSS app.
PoE Powered — One Cable Per CameraBoth NVR options have built-in PoE ports delivering power and video over a single Cat6 cable. Option B has 8 PoE ports with 4 spare for future expansion.
MicroSD Edge Storage — Backup Per CameraEach camera supports up to 256GB microSD for local edge storage — footage saved directly to the camera even if the NVR is disconnected.
DMSS Remote Access — No Port Forwarding RequiredThe free DMSS app (iOS/Android) connects via Dahua’s P2P cloud — no static IP, no DDNS, no port forwarding. Live view, playback, push notifications, two-way audio, and AcuPick search from anywhere.
Option A vs Option B — Which NVR Should I Choose?
Choose Option A — DHI-NVR4104HS-P-AI/ANZ (4CH) if…You want the most compact and affordable setup · You don’t need AcuPick footage search · You won’t be adding more cameras · You only need 1 HDD bay (up to 10TB)
Choose Option B — DHI-NVR5208-8P-AI/ANZ (8CH AcuPick) if…You want
AcuPick footage search by person/vehicle appearance · You want face detection and recognition · You want 4 spare PoE ports to add more cameras later · You want 2 HDD bays for greater storage and redundancy
Recommended For
Residential Homes — Maximum SecurityTiOC cameras at the front gate and driveway for active deterrence. DMSS keeps you informed from anywhere. Full-colour footage captures clothing and vehicle colour for police reports. Upgrade to Option B for AcuPick.
Small Retail & Convenience StoresTiOC at the entry deters shoplifters with a visible siren and strobe. Two-way audio lets staff warn customers remotely. Option B’s
DHI-NVR5208-8P-AI/ANZ AcuPick finds any person in seconds for incident review.
Warehouses & Industrial SitesTiOC at loading docks actively deters after-hours intruders. Option B adds AcuPick vehicle search for tracking deliveries and incidents.
Small Offices & Commercial PremisesFull-colour 24/7 footage captures clothing and vehicle colour — critical for insurance claims. Option B adds face recognition for access control integration.
Airbnb & Rental PropertiesTiOC at entry points deters damage and unauthorised access. MicroSD edge storage provides a backup if the NVR is tampered with.
Childcare Centres & Schools24/7 colour footage for duty-of-care compliance. Option B’s AcuPick and face recognition speeds up post-incident review dramatically.
HDD Retention Guide
HDD Not Included — Choose Your CapacityOption A has
1 × SATA bay (up to 10TB). Option B (
DHI-NVR5208-8P-AI/ANZ) has
2 × SATA bays (up to 16TB each = 32TB raw). We recommend
WD Purple or
Seagate SkyHawk surveillance-grade drives.
Estimated Retention (4 × 6MP @ 15fps, H.265+, Motion-Only)
1TB ≈ 7–10 days · 2TB ≈ 14–20 days · 4TB ≈ 28–40 days · 6TB ≈ 42–60 days · 8TB ≈ 56–80 days
Continuous 24/7 recording reduces these estimates by approximately 60–70%. Contact our team for a precise calculation.
Technical Specifications
TiOC Camera — DH-IPC-HDW3649H-AS-PV-ANZ-S2 · Qty: 4
| Image Sensor |
1/2.7" CMOS |
| Resolution |
6MP · 3072 × 2048 @ 25/30fps |
| Lens |
2.8 mm fixed |
| Night Vision |
IR 30m + Warm Light 30m · Full-colour 24/7 |
| Compression |
Smart H.265+ / H.265 / H.264+ / H.264 |
| Active Deterrence |
Siren · Red/blue strobe lights · Voice warning |
| Audio |
Built-in dual mic · 1-ch speaker · Two-way talk |
| AI |
SMD 4.0 · AcuPick-capable (requires Option B NVR) · Perimeter protection · Tripwire |
| MicroSD |
Up to 256GB |
| WDR / 3D-NR |
Yes |
| Power |
PoE 802.3af · 12V DC |
| Protection |
IP67 |
| Operating Temp |
−30°C to +60°C |
| Compliance |
ANZ-certified firmware · CE · FCC |
NVR Option A — DHI-NVR4104HS-P-AI/ANZ · 4-Channel · No AcuPick
| Channels |
4 IP channels |
| Max Resolution |
Up to 16MP |
| Video Output |
1 × HDMI (4K) · 1 × VGA |
| Built-in PoE |
4 × PoE ports · IEEE 802.3af/at |
| HDD Bays |
1 × SATA (up to 10TB) |
| AI Features |
SMD 4.0 · Perimeter protection · Face detection |
| AcuPick |
Not supported |
| Remote Access |
DMSS app (iOS / Android) · P2P |
| Form Factor |
Compact 1U · Fanless |
| Compliance |
ANZ-certified · ONVIF · CE · FCC |
NVR Option B — DHI-NVR5208-8P-AI/ANZ · 8-Channel · AcuPick ✓
| Channels |
8 IP channels |
| Max Resolution |
Up to 32MP |
| Video Output |
1 × HDMI (4K) · 1 × VGA |
| Built-in PoE |
8 × PoE ports · IEEE 802.3af/at |
| HDD Bays |
2 × SATA (up to 16TB each) |
| AcuPick |
✓ Full support · Search by person/vehicle appearance |
| Face Recognition |
✓ Face detection · Face recognition · Face database |
| AI Features |
SMD+ · AcuPick · Face recognition · Perimeter protection · ANPR |
| Spare PoE Ports |
4 × spare for future camera expansion |
| Remote Access |
DMSS app (iOS / Android) · P2P · AcuPick search in app |
| Form Factor |
1U |
| Compliance |
ANZ-certified · ONVIF · CE · FCC |
Frequently Asked Questions
What is the difference between Option A and Option B?Option A (
DHI-NVR4104HS-P-AI/ANZ) is a compact 4-channel NVR — great for simple home installs with no AcuPick. Option B (
DHI-NVR5208-8P-AI/ANZ) is an 8-channel AcuPick AI NVR with 8 PoE ports, 2 HDD bays, face recognition, and 4 spare ports for future cameras. Choose Option B if you want AcuPick or plan to expand.
What is AcuPick and how does it work?AcuPick is Dahua’s AI footage search engine. Select a person or vehicle from any camera snapshot and the NVR instantly finds every matching clip across all cameras — filtering by clothing colour, vehicle type, plate number, or body attributes. No manual scrubbing through hours of footage. Available on Option B (
DHI-NVR5208-8P-AI/ANZ) only.
Does this kit include a hard drive?
No — Option A supports 1× SATA HDD up to 10TB. Option B supports 2× SATA HDDs up to 16TB each. We recommend WD Purple or Seagate SkyHawk. On motion-only recording at 15fps with H.265+, a 2TB drive gives approximately 14–20 days of retention across all 4 cameras.
What is TiOC active deterrence?
TiOC cameras respond when a human or vehicle is detected — simultaneously triggering a siren, red/blue strobe lights, and a voice warning. Most intruders leave before they’ve taken a step.
Do all cameras record in colour at night?
Yes — all 4 cameras use warm light illuminators for 24/7 full-colour footage. There is no black-and-white IR mode unless you manually disable the warm light.
Can I speak through the cameras?
Yes — each camera has a built-in dual microphone and speaker for two-way audio. Use the DMSS app to speak to visitors, warn intruders, or communicate with staff directly through the camera.
Can I add more cameras later?Option A (4CH) uses all 4 ports — no spare capacity. Option B (
DHI-NVR5208-8P-AI/ANZ) has 8 PoE ports with 4 spare, so you can add up to 4 more cameras without buying a new NVR.
How do I access it remotely?
Download the free DMSS app on iOS or Android. The NVR connects via Dahua’s P2P cloud — no port forwarding, no static IP, no DDNS required. Option B also supports AcuPick search directly from the DMSS app.
What’s the warranty?
Dahua manufacturer warranty on all components, supported locally by CCTV Guru’s Australian technical team.
Do you ship Australia-wide?
Yes — fast dispatch to every state and territory from Australian stock. Same-day dispatch on orders placed before 2pm AEST (business days).
Order the Dahua 6MP TiOC Full Colour Kit from CCTV Guru
CCTV Guru is an authorised Australian distributor of Dahua surveillance products. Order the Dahua 4 × 6MP TiOC Full Colour CCTV Kit today for fast Australia-wide dispatch and expert pre-sales advice on NVR selection, HDD sizing, and AcuPick configuration. Choose Option B with the DHI-NVR5208-8P-AI/ANZ for the full AcuPick experience — find any person or vehicle in seconds.
Need more cameras or a larger kit? View our full Dahua CCTV kit range →
