Uniview UNV NVR501-08B-P8-IQ 8 Channel 4K AI PoE NVR — 1-Bay, NDAA

Description

NDAA-Compliant 8-Channel AI PoE NVR

Uniview UNV NVR501-08B-P8-IQ 8-Channel PoE NVR — Australian Stock & 3-Year Warranty

The Uniview UNV NVR501-08B-P8-IQ is an 8-channel network video recorder with 8 built-in PoE ports, so you can power and connect up to eight IP cameras straight from the back of the unit — no separate switch or power supplies needed. It records up to 16MP resolution in Ultra 265, takes a single SATA drive up to 16TB, and runs Uniview UNV's latest -IQ AI search tools — AcuSearch, AcuTrack and SeekFree — so you can find a person, vehicle or event in seconds instead of scrubbing footage for hours. NDAA compliant and plug-and-play, it's an ideal all-in-one recorder for homes, shops and small business sites.

Camera Inputs8 Channels
Built-in PoE8 Ports · 75W
Max Recording16MP Ultra 265
Storage1 × 16TB SATA

AI search that does the work for you

AcuSearch & AcuTrack

Frame a person or vehicle on the live or playback screen, hit search, and AcuSearch returns matches in seconds. AcuTrack then follows that target across cameras — no more frame-by-frame scrubbing.

SeekFree Smart Review

SeekFree lets you search recorded video by typing what you're looking for, condensing hours of footage down to the moments that matter for fast, plain-language review.

Smart by IPC

Run Face Detection, Smart Intrusion Prevention (SIP) and Ultra Motion Detection (UMD) across all 8 channels, applied through compatible Uniview cameras.

VCA Search & People Counting

Search by human body, motor and non-motor vehicle, plus people-counting reports and heat maps — handy analytics for retail and managed sites.

Plug-and-play PoE in one box

8 Independent PoE Ports

Eight plug-and-play PoE ports (IEEE 802.3at/af) power and connect your cameras directly — up to 30W per port and 75W total, so one cable per camera does power and data.

ANR Anti-Dropout

If a camera link drops, ANR keeps recording to the camera's onboard SD card and backfills the NVR once the connection returns — no gaps in your footage.

4K HDMI + VGA Output

Drive a 4K display over HDMI and a second monitor over VGA at the same time for a clear dual-screen live view straight from the recorder.

NDAA Compliant

Built to NDAA Section 889 requirements, making it suitable for government, education and enterprise projects with procurement restrictions.

Specifications

Recording & Decoding
Video Compression Ultra 265, H.265, H.264
Recording Resolution Up to 16MP — 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1
Decoding Capability 2 × 16MP@30 / 2 × 12MP@30 / 4 × 4K@30 / 6 × 5MP@30 / 8 × 4MP@30
Incoming / Outgoing Bandwidth 80 Mbps / 64 Mbps
Live View Display 1 / 4 / 6 / 8 / 9 split (incl. corridor mode)
Channels & Connectivity
IP Camera Input 8-ch
PoE Ports 8 × RJ45 10/100M — plug & play, IEEE 802.3at/af
PoE Power Budget Max 30W per port, 75W total
Network Interface 1 × RJ45 10/100M self-adaptive Ethernet
Video Output 1 × HDMI (4K), 1 × VGA — simultaneous output
USB 1 × USB 2.0, 1 × USB 3.0 (rear)
Audio 1-ch RCA in / out, two-way audio
AI & Smart Functions
Smart Search AcuSearch, AcuTrack, SeekFree, SmartSearch
VCA Detection (by IPC) Face Detection, SIP (Intrusion, Cross Line, Enter/Leave Area), UMD, People Counting
VCA Search Human Body, Motor & Non-Motor Vehicle, General Search, People Counting Report, Heat Map
Smart by IPC Total 8-ch (Face Detection, SIP, UMD)
ANR Supported (edge recording backfill)
ONVIF Profile S, Profile G, Profile T
Storage, Power & Build
HDD Bays 1 × SATA, up to 16TB
Power Supply DC 52V / 1.8A
Power Consumption ≤10W (without HDD, excludes PoE load)
Dimensions 260 × 222 × 47 mm, ≤1.1 kg (without HDD)
Operating Temperature -10°C to 55°C
Certification CE, FCC, UL, RoHS, WEEE — NDAA Compliant

How much footage can it hold?

Recording time depends on how many cameras you run, their resolution and frame rate, and whether you record continuously or on motion. The estimates below assume 8 cameras at 4MP, H.265, ~4 Mbps continuous — a typical real-world load. Smart/motion-only recording, lower resolution or fewer cameras will extend retention significantly. This recorder takes a single SATA drive up to 16TB.

Approximate Recording Retention (8 × 4MP, H.265)
2 TB ~6 days continuous · ~14 days motion-based
4 TB ~12 days continuous · ~28 days motion-based
8 TB ~24 days continuous · ~55 days motion-based
12 TB ~36 days continuous · ~80 days motion-based
16 TB (max) ~48 days continuous · ~108 days motion-based

Figures are estimates for guidance only and will vary with scene activity, bitrate and camera settings.

Downloads

NVR501-08B-P8-IQ Datasheet Uniview UNV NVR Quick Start Guide Uniview UNV NVR User Manual

Frequently Asked Questions

Does this NVR have built-in PoE ports?

Yes. The NVR501-08B-P8-IQ has 8 plug-and-play PoE ports built in, so you power and connect up to 8 cameras directly from the recorder — no separate PoE switch or power supplies required.

How much PoE power does it supply?

Up to 30W on a single port and 75W in total across all 8 ports, supporting both IEEE 802.3at and 802.3af cameras. Budget your camera load against the 75W total.

How many cameras can it record?

Up to 8 IP channels at once, with 80 Mbps of incoming bandwidth — enough for a full set of high-megapixel cameras.

What's the maximum storage?

One SATA bay takes a single hard drive up to 16TB. Drives are sold separately so you can size storage to your retention needs.

What resolution can it record?

Up to 16MP per channel in Ultra 265, H.265 or H.264, ready for high-resolution Uniview cameras.

What is AcuSearch, AcuTrack and SeekFree?

They're Uniview UNV's -IQ AI review tools. AcuSearch filters footage by people and vehicles, AcuTrack follows a target across cameras, and SeekFree lets you search recordings by typing what you're after.

Is it NDAA compliant?

Yes. The NVR501-08B-P8-IQ is NDAA compliant, making it suitable for government, education and enterprise projects with procurement requirements.

Can I view it remotely?

Yes. P2P cloud access through the Uniview UNV app and EZCloud lets you watch live and recorded footage from your phone or computer anywhere.

What's in the box and what warranty applies?

The recorder ships with its power adapter and accessories (drive sold separately) and is backed by a 3-year Australian warranty with local CCTV Guru support.

3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support
