Ubiquiti UniFi Indoor Cat6A CMP Cable
The Ubiquiti UACC-Cable-C6A-CMP is a 305 m Category 6A bulk Ethernet cable for indoor structured-cabling installations. It uses four twisted pairs of 23 AWG solid bare-copper conductors and includes an internal divider to help control crosstalk.
Its flame-retardant PVC jacket carries a CMP flame rating tested to NFPA 262. The cable is unshielded twisted pair (UTP), with a white 6.7 mm jacket, integrated ripcord and minimum bend radius of 26.8 mm.
Cable length
305 m (1,000 ft)
Flame rating
CMP · NFPA 262
Conductors
23 AWG solid copper
Construction and installation
Unshielded Cat6A construction
Four colour-coded twisted pairs, an anti-crosstalk divider and solid bare-copper conductors provide a structured-cabling foundation for compatible Cat6A installations.
Indoor CMP-rated jacket
The flame-retardant PVC jacket is CMP rated and tested to NFPA 262. Ubiquiti specifies this cable for indoor use.
Technical specifications
| Manufacturer |
Ubiquiti |
| Product name |
UniFi Indoor Cable Cat6A CMP |
| Model |
UACC-Cable-C6A-CMP |
| Category |
Category 6A |
| Length |
305 m (1,000 ft) |
| Environment |
Indoor |
| Shielding |
UTP |
| Conductors |
23 AWG solid bare copper |
| Pair construction |
Four colour-coded twisted pairs |
| Jacket material |
Flame-retardant polyvinyl chloride (FRPVC) |
| Jacket colour |
White |
| Jacket diameter |
6.7 ± 0.2 mm |
| Minimum bend radius |
26.8 mm |
| Flame rating |
CMP |
| Flame test |
NFPA 262 |
| Installation temperature |
0°C to 60°C |
| Operating temperature |
−20°C to 75°C |
| Storage temperature |
−20°C to 75°C |
| Box dimensions |
494 × 302 × 481 mm |
| Box weight |
21.3 kg |
| Included features |
Anti-crosstalk divider and ripcord |
Standards listed by Ubiquiti
- ANSI/TIA-568.2-D
- ISO/IEC 11801-1, Edition 2.2
- IEC 61156-5, Edition 2.1
- NFPA 262
- UL 444
- CSA 22.2 No. 214
- EU Directive 2011/65/EU (RoHS 2)
Frequently asked questions
Is this cable shielded?
No. Ubiquiti identifies it as an unshielded twisted-pair cable (UTP).
Is it suitable for outdoor installation?
No. Ubiquiti specifies this model for indoor use.
Does it contain copper-clad aluminium?
No. Ubiquiti specifies 23 AWG solid bare-copper conductors.
Does the cable support 10 Gigabit Ethernet?
Category 6A is the recognised cabling category used for 10 Gigabit Ethernet channels when the complete installed channel, including its terminations, components, length and workmanship, meets the applicable Cat6A requirements.
Australian installation note
CMP is a North American cable flame classification. Before using this product in fixed or concealed cabling in Australia, confirm that the product and proposed installation satisfy applicable ACMA requirements, Australian cabling standards and project-specific fire or building requirements. Regulated cabling work must be completed by an appropriately registered cabler.
