Ubiquiti UniFi Access
Heavy-Duty Electric Bolt Lock for Enterprise UniFi Access Security
The UACC-Lock-Bolt-Secure is an industrial-grade electric bolt lock designed for seamless integration with UniFi Access Hubs and commercial access control systems. Built with solid steel construction and engineered for high-security applications, this electric lock delivers strong holding force and reliable physical entry deterrence across glass, wooden, aluminum, and heavy commercial doors.
Lock Mechanism
Electric Steel Bolt
Security Operation
Fail-Secure Safety
Operating Voltage
12V DC Relay Driven
Integration
UniFi Access Hub Ready
Seamless UniFi Access Control Integration & Real-Time Monitoring
Engineered to work harmoniously with UniFi Access controllers, the UACC-Lock-Bolt-Secure connects directly to UniFi Access Hub door relay terminals for instant locking state synchronization and event logging. Its heavy-duty bolt mechanism ensures long service life under high daily cycle traffic, offering clean aesthetic installation options for modern commercial entrances and secured interior suites.
Commercial Grade Security Build
Features a reinforced steel locking pin engineered to resist heavy physical force and unauthorized entry attempts, providing reliable protection for commercial buildings, server rooms, and restricted areas.
Plug-and-Play Hub Compatibility
Fully compliant with UniFi Access Hub (UA-Hub-Door, UA-Hub-Gate, and UA-Hub-Door-Mini) 12V DC relay output connections for swift deployment without complex external relay wiring.
Technical Specification Matrix
| Lock Model |
UACC-Lock-Bolt-Secure |
| Lock Mechanism Type |
Electric Drop-Bolt Lock |
| Operating Mode |
Fail-Secure (Locked when power is disconnected) |
| Input Power Requirements |
12V DC |
| Bolt Material |
Solid Stainless Steel / Heavy-Duty Alloy Pin |
| Door Compatibility |
Wood, Glass, Aluminum, Metal Doors |
| Ecosystem Compatibility |
UA-Hub-Door, UA-Hub-Gate, UA-Hub-Door-Mini |
| Installation Options |
Flush Mount / Surface Mount Configuration |
Is the UACC Lock Bolt Secure compatible with UniFi Access Hubs?
Yes, it is specifically designed to connect directly to the 12V DC powered relay outputs on UniFi Access Hubs for unified management through the UniFi Access application.
What happens to the lock during a power loss?
As a Fail-Secure device, the lock remains in a locked state when power is cut, preserving physical entry security for sensitive access points during power interruptions.
What types of doors are compatible with this electric bolt lock?
The lock is suitable for installation on timber, hollow metal, frame aluminum, and glass doors with appropriate mounting brackets or cutouts.
Does this lock require an external power supply module?
It can be powered directly via the 12V DC lock output terminals supplied by UniFi Access Hubs, eliminating the need for standalone third-party power adapters in standard installations.
