airMAX CPE — NDAA Compliant
Ubiquiti NanoStation M2 — airMAX 2.4 GHz Outdoor CPE Antenna (NSM2)
The Ubiquiti NanoStation M2 (NSM2) is a compact, all-in-one airMAX 2.4 GHz outdoor CPE with an integrated dual-polarity antenna, ideal for point-to-multipoint links, wireless bridging, and extending coverage across sites, farms, and remote buildings. Its UV-stabilised weatherproof enclosure, included pole-mount kit, and 24V PoE adapter make for a fast outdoor install. Genuine Ubiquiti stock with fast Australia-wide shipping and expert AU support.
Integrated airMAX Antenna
Built-in dual-linear 2.4 GHz antenna delivering 10.4–11.2 dBi gain with 23 dB minimum cross-pol isolation for reliable long-range links.
Outdoor-Ready Build
UV-stabilised plastic enclosure rated for −30°C to 75°C with an included pole-mount kit for quick deployment in Australian conditions.
Dual Ethernet + PoE
Two 10/100 RJ45 ports and a bundled 24V PoE adapter power and connect the unit over a single cable run — just 5.5W max draw.
Technical Specifications
| Model |
NanoStation M2 (NSM2) |
| Frequency |
2.4 GHz • 2412–2462 MHz |
| Antenna Gain |
10.4–11.2 dBi |
| Cross-pol Isolation |
23 dB min |
| Polarization |
Dual linear |
| Beamwidth |
55° (H-pol) / 53° (V-pol) / 27° (elevation) |
| Networking |
(2) 10/100 MbE RJ45 ports |
| Power Method |
Passive PoE 2-pair • 24V 0.5A adapter included • 22–27V DC |
| Max Power Consumption |
5.5 W |
| Enclosure |
Outdoor UV-stabilized plastic • pole-mount kit included |
| Dimensions / Weight |
294 × 31 × 80 mm • 400 g |
| Operating Temperature |
−30°C to 75°C • 5–95% non-condensing |
| Certifications |
FCC, IC, CE, RoHS |
| Compliance |
NDAA Compliant |
