TP-Link VIGI NVR2016H-16MP 16-Channel 4K PoE+ Network Video Recorder

Description

TP-Link VIGI · NVR2016H-16MP · 16CH 4K PoE+ NVR · 16 PoE+ Ports 16CH 4K PoE+ NVR

VIGI NVR2016H-16MP 16-Channel 4K PoE+ Network Video Recorder — Australian Stock & 3-Year Warranty

The TP-Link VIGI NVR2016H-16MP is a 16-channel PoE+ network video recorder that powers, connects and records up to 16 cameras over a single cable each — no separate PoE switch required. With 16 built-in PoE+ ports sharing a 140 W budget, 4K HDMI output, 320 Mbps throughput and two SATA bays (up to 16 TB each), it's a clean, scalable backbone for business and multi-camera sites. Efficient H.265+ stretches your storage further, while One-Click System Initialise and full VIGI app management make setup and remote viewing simple. Backed by a local 3-year Australian warranty.

Channels
16-Channel
PoE+
16 Ports · 140 W
Output
4K HDMI + VGA
Storage
2 Bays · to 32 TB
Bandwidth
320 Mbps
Recording
Up to 8MP · H.265+

16 Cameras, One Cable Each

Sixteen built-in PoE+ ports power and connect each camera over a single network run — no separate switch or power supplies. A 140 W budget (30 W max per port) comfortably drives a full set of turret and bullet cameras.

Sharp 4K Live View

Independent 4K HDMI and VGA outputs drive two displays at once, with 1/4/6/8/9/16 multi-view layouts and 16-channel synchronous playback for fast, clear review on the spot.

Dual-Bay, High-Capacity Storage

Two SATA bays take up to 16 TB each (32 TB total) plus eSATA expansion, and efficient H.265+ compression cuts file sizes so you keep weeks of footage from a full 16-camera system.

Fast Setup & Smart Alerts

One-Click System Initialise adds cameras, formats disks and schedules storage in a tap. With compatible cameras you get human & vehicle detection, line-crossing, intrusion and more — managed locally or via the free VIGI app.

Specifications — TP-Link VIGI NVR2016H-16MP (V2)
Device Type 16-Channel PoE+ Network Video Recorder
IP Video Input 16 channels · 16-channel live view & synchronous playback
Built-in PoE 16 × 10/100 Mbps PoE+ (802.3af/at) · 140 W total · 30 W max per port
Recording Resolution Up to 8MP (8MP/5MP/4MP/3MP/1080p and lower)
Decoding 25fps: 10-ch @ 3MP / 16-ch @ 1080p · 30fps: 4-ch @ 8MP, 6-ch @ 5MP, 8-ch @ 4MP
Bandwidth 320 Mbps incoming / 320 Mbps outgoing
Video Output 1 × HDMI (4K, 3840 × 2160/30Hz) + 1 × VGA — independent output
Multi-View 1 / 4 / 6 / 8 / 9 / 16 split
Compression H.265+ / H.265 / H.264+ / H.264
Storage 2 × SATA bays, up to 16 TB each (HDD not included) · 1 × eSATA
Network 1 × RJ45 10/100/1000 Mbps Gigabit
Interoperability ONVIF Profile S · CGI · RTSP
Smart Events (via camera) Human & vehicle detection, line-crossing, intrusion, region entering/exiting, loitering, object left/removed, abnormal sound
Alarm In / Out 6 / 4
Audio 1-ch RCA input · 1-ch RCA output
USB 1 × front USB 2.0 · 1 × rear USB 3.0
Remote Access Free VIGI app (Android & iOS) · web UI
Power 53.5V DC / 3.37A · max 40 W (with disk)
Dimensions / Weight 330 × 285 × 45 mm · 2.2 kg
Operating Temp. −10°C to 55°C
In the Box NVR · power adapter & cable · HDD power/data cables · mouse · mounting accessories · quick install guide
Warranty (Australia) 3 years · CCTV Guru Australia
How Much Footage Can It Hold? (HDD Retention)
4 TB ~7 days continuous · ~14 days motion-based
8 TB ~14 days continuous · ~29 days motion-based
16 TB ~28 days continuous · ~58 days motion-based
32 TB (2 × 16 TB) ~57 days continuous · ~116 days motion-based

Retention depends on your cameras. Figures assume 16 × 4MP cameras recording continuously in H.265+ at ~3 Mbps. Fewer cameras, lower resolution/frame rate, or motion/AI-event recording will extend storage time considerably; higher resolution or bitrate will reduce it. Estimates are a guide only.

Best For
Retail & hospitality
Run up to 16 cameras across the floor, tills, storeroom and entries from one recorder.
Warehouses & industrial
Dual-bay storage and 320 Mbps throughput suit large sites with many high-res cameras.
Offices & strata
One-cable PoE+ install and 4K review for corridors, car parks, lifts and common areas.
Larger homes & acreage
Plenty of channels and storage to cover sheds, gates, driveways and the whole property.

Downloads & Resources

VIGI-NVR2016H-16MP Datasheet VIGI NVR GUI User Guide VIGI App User Guide VIGI Wired NVR Installation Guide NVR2016H-16MP Installation Guide NVR Installation Guide (16 Languages) VIGI NVR Authentication Guide
How many cameras can it run?
Up to 16 IP cameras, each powered and connected on a single cable to one of the 16 built-in PoE+ ports — no separate switch needed.
Does it include hard drives?
No — it has two empty SATA bays (up to 16 TB each). Add surveillance-grade drives to suit your retention; see the storage guide above.
What's the total PoE power budget?
140 W shared across all 16 PoE+ ports, with up to 30 W per port — enough for a full set of turret, bullet and most active-deterrence cameras.
Will it work with non-VIGI cameras?
Yes. It supports ONVIF Profile S, so it works with VIGI cameras and most third-party ONVIF IP cameras.
Can I view it remotely?
Yes. The free VIGI app for Android and iOS gives live view, playback and alerts from anywhere, with no monthly fees.
What resolution can it record and display?
It records cameras up to 8MP and outputs 4K (3840 × 2160) over HDMI, with an independent VGA output for a second screen.
Does it support smart detection?
Yes — with compatible cameras it supports human & vehicle detection, line-crossing, intrusion, loitering and more for accurate alerts.
Is it covered by warranty in Australia?
Yes — 3-year Australian warranty with local CCTV Guru tech support.
3-Year AU Warranty
Fast AU-Wide Shipping
AU Tech Support

TP-Link VIGI NVR2016H-16MP 16-Channel 4K PoE+ Network Video Recorder
