TP-Link TL-SL1218MP 16-Port 10/100Mbps + 2-Port Gigabit Unmanaged PoE Switch

Description

TP-Link TL-SL1218MP 16-Port 10/100Mbps + 2-Port Gigabit Unmanaged PoE Switch

16 PoE+ 10/100Mbps RJ45 ports, 2 Gigabit RJ45 ports and 2 combo Gigabit SFP slots
Up to 250m data and power transmission under extend mode specially designed for surveillance system
Priority mode for port1-8 to guarantees the quality of sensitive applications like video monitor
High PoE power budget with up to 30W for each PoE port and 194W for all PoE ports
Easy to use, with no configuration and installation needed

HARDWARE FEATURES
  • Interface 16 PoE+ 10/100Mbps RJ45 Ports
  • 2 10/100/1000Mbps RJ45 Ports
  • 2 Combo Gigabit SFP Slots
  • Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
  • EIA/TIA-568 100Ω STP (maximum 100m)
  • 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
  • EIA/TIA-568 100Ω STP (maximum 100m)
  • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
  • EIA/TIA-568 100Ω STP (maximum 100m)
  • 1000BASE-X MMF, SMF
  • Fan Quantity 2 Fans
  • Physical Security Lock Yes
  • Power Supply 100-240V AC, 50/60 Hz
  • Backup Bandwidth 7.2 Gbps
  • PoE+ Ports(RJ45) Standard: 802.3at/802.3af compliant
  • PoE Ports: Port1- Port16
  • PoE Power Budget: 192W
  • Mac Address Table 8K
  • Dimensions ( W x D x H ) 17.3 × 7.1 × 1.7 in.
  • (440 × 180 × 44 mm)
  • Max Power Consumption 18.7 W (no PD connected)
  • 217.2 W (with 192W PD connected)
  • Max Heat Dissipation 63.9 BTU/h (no PD connected)
  • 741.2 BTU/h (with 192W PD connected)

SOFTWARE FEATURES
  • Advanced Features Compatible with IEEE 802.3at/af compliant devices
  • Port Priority Mode
  • Extend Mode (Up to 250m PoE power supply and data transmission)
  • Mac Address Auto-Learning And Auto-Aging
  • IEEE802.3x Flow Control
  • Transmission Method Store-And-Forward

TP-Link TL-SL1218MP 16-Port 10/100Mbps + 2-Port Gigabit Unmanaged PoE Switch

Product form

SKU: TL-SL1218MP

TP-Link TL-SL1218MP 16-Port 10/100Mbps + 2-Port Gigabit Unmanaged PoE Switch16 PoE+ 10/100Mbps RJ45 ports, 2 Gigabit RJ45 ports and 2... Read more

$329.00 Incl. GST

    • Warranty: 60 months
    • 30 day money back guarantee
    • Australian Stocks & Express Delivery
    • Back-to-base Warranty & Tech Support
      • PayPal
      • Apple Pay
      • Visa
      • Mastercard
      • Zip
      • Klarna
      • Afterpay

      Description

      TP-Link TL-SL1218MP 16-Port 10/100Mbps + 2-Port Gigabit Unmanaged PoE Switch

      16 PoE+ 10/100Mbps RJ45 ports, 2 Gigabit RJ45 ports and 2 combo Gigabit SFP slots
      Up to 250m data and power transmission under extend mode specially designed for surveillance system
      Priority mode for port1-8 to guarantees the quality of sensitive applications like video monitor
      High PoE power budget with up to 30W for each PoE port and 194W for all PoE ports
      Easy to use, with no configuration and installation needed

      HARDWARE FEATURES
      • Interface 16 PoE+ 10/100Mbps RJ45 Ports
      • 2 10/100/1000Mbps RJ45 Ports
      • 2 Combo Gigabit SFP Slots
      • Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
      • EIA/TIA-568 100Ω STP (maximum 100m)
      • 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
      • EIA/TIA-568 100Ω STP (maximum 100m)
      • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
      • EIA/TIA-568 100Ω STP (maximum 100m)
      • 1000BASE-X MMF, SMF
      • Fan Quantity 2 Fans
      • Physical Security Lock Yes
      • Power Supply 100-240V AC, 50/60 Hz
      • Backup Bandwidth 7.2 Gbps
      • PoE+ Ports(RJ45) Standard: 802.3at/802.3af compliant
      • PoE Ports: Port1- Port16
      • PoE Power Budget: 192W
      • Mac Address Table 8K
      • Dimensions ( W x D x H ) 17.3 × 7.1 × 1.7 in.
      • (440 × 180 × 44 mm)
      • Max Power Consumption 18.7 W (no PD connected)
      • 217.2 W (with 192W PD connected)
      • Max Heat Dissipation 63.9 BTU/h (no PD connected)
      • 741.2 BTU/h (with 192W PD connected)

      SOFTWARE FEATURES
      • Advanced Features Compatible with IEEE 802.3at/af compliant devices
      • Port Priority Mode
      • Extend Mode (Up to 250m PoE power supply and data transmission)
      • Mac Address Auto-Learning And Auto-Aging
      • IEEE802.3x Flow Control
      • Transmission Method Store-And-Forward
