Description
Professional PoE+ Managed Switch for Business Networks
The TP-Link Omada SG3428XMPP is a high-performance Layer 2+ managed switch purpose-built for demanding business environments. With 24 Gigabit PoE+ ports, a generous 400W PoE budget, and four 10G SFP+ uplink ports, it delivers the power and bandwidth needed to support IP cameras, wireless access points, VoIP phones, and other PoE-powered devices — all from a single, centrally managed platform.
Key Features
- 24× Gigabit RJ45 PoE+ ports (IEEE 802.3at/af) with up to 30W per port
- 4× 10G SFP+ uplink ports for high-speed backbone connectivity
- 400W total PoE budget — supports dense PoE deployments
- Layer 2+ switching with static routing, VLAN, QoS, RSTP/MSTP, and IGMP snooping
- Omada SDN integration — manage via Omada Controller (hardware, software, or cloud)
- Centralised cloud management via the Omada app and web portal
- Advanced security: 802.1X, ACL, IP/MAC/Port binding, DoS defence
- Fanless design option for quiet deployments; rack-mountable 1U form factor
- IPv6 support and comprehensive L2 feature set
Use Cases
-
IP Surveillance: Power and connect multiple IP cameras without additional power injectors
-
Wireless Networks: Ideal for powering Omada or third-party PoE access points across offices, schools, and hospitality venues
-
VoIP Deployments: Deliver reliable power and QoS prioritisation for IP phone systems
-
SMB & Enterprise Edge: Scalable managed switching for growing Australian businesses
-
CCTV Installations: Centralise camera power and network management in a single switch
Technical Specifications
| Specification |
Detail |
| Model |
SG3428XMPP |
| Standards |
IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3ae, 802.3at, 802.3af, 802.3x |
| PoE Ports |
24× Gigabit RJ45 (PoE+, IEEE 802.3at/af) |
| Uplink Ports |
4× 10G SFP+ |
| PoE Budget |
400W total |
| Max PoE per Port |
30W |
| Switching Capacity |
128 Gbps |
| Forwarding Rate |
95.24 Mpps |
| MAC Address Table |
16K |
| Jumbo Frame |
9216 Bytes |
| Layer |
Layer 2+ |
| Management |
Omada SDN, Web GUI, CLI (Telnet/SSH), SNMP v1/v2c/v3, RMON |
| VLAN |
802.1Q VLAN, up to 4K VLAN groups |
| QoS |
8 priority queues, 802.1p, DSCP |
| Spanning Tree |
STP, RSTP, MSTP |
| Routing |
Static routing, RIP v1/v2 |
| Power Input |
100–240V AC, 50/60Hz |
| Form Factor |
1U Rack-mountable |
| Dimensions |
440 × 220 × 44 mm |
| Operating Temperature |
0–45°C |
| Certifications |
CE, FCC, RoHS |
Official Product Video
Watch the official TP-Link Omada overview to see how the SG3428XMPP integrates into a unified SDN network:
View on YouTube: TP-Link Omada SG3428XMPP
Recommended Accessories
-
TP-Link Omada OC300 – Hardware Omada Controller for on-premises SDN management
-
TP-Link TL-SM5310-T – 10GBase-T SFP+ module for copper 10G uplinks
-
TP-Link TL-SM5110-SR – 10G SFP+ fibre module (short range)
-
TP-Link Omada EAP670 – Wi-Fi 6 access point, PoE-powered via SG3428XMPP
-
TP-Link Omada ER8411 – Multi-WAN VPN router for full Omada SDN stack
Downloads
Frequently Asked Questions
What is the total PoE power budget on the SG3428XMPP?
The SG3428XMPP provides a total PoE budget of 400W across all 24 PoE+ ports, with a maximum of 30W per port. This is sufficient to simultaneously power a large number of IP cameras, access points, or VoIP phones without an external power injector.
Does the SG3428XMPP support cloud management?
Yes. The switch integrates fully with the TP-Link Omada SDN platform, supporting cloud-based management via the Omada Cloud Controller, the Omada app, or a local hardware/software controller. This allows centralised configuration and monitoring from anywhere.
Can I use the SG3428XMPP without an Omada Controller?
Yes. The switch can operate in standalone mode and be managed via its web GUI, CLI (SSH/Telnet), or SNMP — no controller is required. The Omada Controller is optional but recommended for multi-device deployments.
What SFP+ modules are compatible with the uplink ports?
The four 10G SFP+ ports support standard SFP+ modules including TP-Link's own range (e.g. TL-SM5310-T for copper, TL-SM5110-SR for fibre). Third-party SFP+ modules may also be compatible — check TP-Link's compatibility list for confirmation.
Is the SG3428XMPP suitable for IP surveillance (CCTV) installations?
Absolutely. With 24 PoE+ ports and a 400W budget, it can power up to 24 IP cameras directly. Combined with VLAN segmentation and IGMP snooping for multicast video traffic, it is an excellent choice for professional CCTV and security system installations across Australia.
Does this switch support link aggregation (LAG)?
Yes. The SG3428XMPP supports IEEE 802.3ad LACP and static link aggregation, allowing you to bond multiple ports for increased throughput and redundancy to upstream devices.
