TP-Link Omada POE380S 802.3bt PoE++ Injector 90W
Power High-Wattage PoE Devices Without a PoE Switch
The TP-Link Omada POE380S is a single-port 802.3bt PoE++ injector that delivers up to 90W of power over a standard Ethernet cable — enough to power the most demanding PoE devices including high-performance Wi-Fi 6/6E access points, PTZ cameras, video conferencing equipment, and thin clients. Plug-and-play with no configuration required, it’s the simplest way to add PoE power to a single device without replacing your existing non-PoE switch.
Key Features
-
802.3bt PoE++ Standard — Delivers up to 90W of PoE power per port, supporting the full range of PoE (15.4W), PoE+ (30W), and PoE++ (60W/90W) devices.
-
Gigabit Data Pass-Through — Full 10/100/1000Mbps Gigabit Ethernet data pass-through ensures no network speed penalty when adding PoE power.
-
Plug-and-Play — No configuration, no software, and no management required. Simply connect your switch, injector, and PoE device.
-
Wide Device Compatibility — Powers any IEEE 802.3af, 802.3at, or 802.3bt compliant PoE device, including access points, IP cameras, PTZ cameras, VoIP phones, and thin clients.
-
Compact & Reliable — Small desktop form factor with a robust power supply suitable for permanent installation in comms rooms, offices, and on-site deployments.
-
LED Status Indicator — Clear LED indicator shows power and PoE status at a glance.
Use Cases
- Powering high-wattage Wi-Fi 6/6E or Wi-Fi 7 access points that require more than 30W (PoE+)
- Adding PoE power to a single device connected to a non-PoE switch without replacing the switch
- Powering PTZ IP cameras requiring 60W or 90W PoE++ at remote locations
- Providing PoE power to video conferencing endpoints, thin clients, or digital signage displays
- Temporary or single-device deployments where a full PoE switch is not justified
- Installer use: powering devices during commissioning and testing before permanent infrastructure is in place
Technical Specifications
| Specification |
Detail |
| PoE Standard |
IEEE 802.3bt (PoE++), 802.3at (PoE+), 802.3af (PoE) |
| PoE Output Power |
Up to 90W |
| Data Port Speed |
10/100/1000Mbps (Gigabit) |
| Ports |
1× Gigabit RJ45 Data In + 1× Gigabit RJ45 PoE Data Out |
| Power Input |
100–240V AC, 50/60Hz (AU plug included) |
| Max Power Consumption |
100W |
| LED Indicators |
Power, PoE Status |
| Operating Temperature |
0°C – 40°C |
| Operating Humidity |
10% – 90% (non-condensing) |
| Certifications |
CE, FCC, RoHS, RCM (Australia) |
Downloads
Recommended Accessories & Products
-
TP-Link Omada EAP670 — AX3600 Wi-Fi 6 access point with 2.5G uplink, compatible with 802.3bt PoE for maximum performance
-
TP-Link Omada SG6654XHP — 48-port 2.5G PoE+ managed switch for multi-device PoE deployments
-
TP-Link Omada EAP613 — AX1800 Wi-Fi 6 ceiling AP (13.5W, 802.3af compatible) for standard PoE deployments
-
TP-Link VIGI C340 — 4MP outdoor full-colour bullet IP camera, PoE powered
-
Cat6 Ethernet Patch Cable — For reliable Gigabit data and PoE runs between injector and powered device
Frequently Asked Questions
What is the difference between PoE, PoE+, and PoE++?
IEEE 802.3af (PoE) delivers up to 15.4W per port, 802.3at (PoE+) delivers up to 30W, and 802.3bt (PoE++) delivers up to 60W (Type 3) or 90W (Type 4). The POE380S supports all three standards and delivers up to 90W, making it compatible with virtually any PoE-powered device on the market.
Do I need a PoE switch to use the POE380S?
No. The POE380S is a standalone PoE injector. Connect your existing non-PoE switch to the “Data In” port and your PoE device to the “PoE Data Out” port. The injector adds PoE power to the Ethernet connection without requiring a PoE switch.
What cable type is required for 90W PoE?
IEEE 802.3bt PoE++ at 90W requires Cat5e or better cabling. Cat6 or Cat6A is recommended for best results and future-proofing, particularly for runs over 50 metres.
Is the POE380S compatible with non-TP-Link PoE devices?
Yes. The POE380S complies with IEEE 802.3af, 802.3at, and 802.3bt standards, making it compatible with any standards-compliant PoE device regardless of brand.
Can I use the POE380S to power a Wi-Fi 6E or Wi-Fi 7 access point?
Yes. Many high-performance Wi-Fi 6E and Wi-Fi 7 access points require more than 30W (PoE+). The POE380S’s 90W output ensures it can power even the most demanding access points without power limitations affecting performance.
