Description
Seamless In-Wall Wi-Fi 6 for Hotels, Offices & Multi-Dwelling Units
The TP-Link Omada EAP615-Wall is a compact AX1800 Wi-Fi 6 access point designed to fit neatly into a standard wall plate, replacing a conventional GPO or data outlet. With a built-in 4-port Gigabit switch and PoE passthrough, it delivers high-density, high-speed wireless coverage without cluttering ceilings or requiring additional cabling runs — making it the go-to choice for installers deploying guest Wi-Fi, MDU broadband, or enterprise-grade wireless in Australia.
Key Features
-
Wi-Fi 6 (802.11ax) AX1800 — 574 Mbps on 2.4 GHz + 1201 Mbps on 5 GHz for faster throughput and reduced congestion in dense environments
-
In-Wall Form Factor — Fits standard 86 mm wall plates; replaces a single GPO or data port for a clean, professional finish
-
4-Port Gigabit Switch — Connects wired devices such as IP phones, smart TVs, and set-top boxes directly from the wall plate
-
PoE In / PoE Passthrough — Powered via a single PoE uplink; one downstream port supports PoE passthrough to power an additional device (e.g. IP phone)
-
OFDMA & MU-MIMO — Serves multiple clients simultaneously for improved efficiency in high-density deployments
-
BSS Colouring — Reduces co-channel interference in environments with overlapping Wi-Fi networks
-
Omada SDN Controller Compatible — Centralised management via Omada Hardware Controller, Software Controller, or Omada Cloud
-
Guest Network & VLAN Support — Isolate guest traffic from corporate or residential networks with ease
-
WPA3 Security — Latest wireless encryption standard for enhanced client protection
-
Band Steering & Seamless Roaming — Automatically guides clients to the optimal band; supports 802.11r/k/v for fast roaming across APs
Typical Use Cases
-
Hotels & Serviced Apartments — Per-room Wi-Fi with guest network isolation and bandwidth control
-
Multi-Dwelling Units (MDUs) — Apartment buildings and student accommodation requiring per-unit wireless coverage
-
Corporate Offices — Desk-side Wi-Fi 6 with wired ports for IP phones and workstations
-
Healthcare Facilities — Reliable, low-latency connectivity for medical devices and staff tablets
-
Education — Classroom-level coverage with VLAN segmentation for staff and student networks
Technical Specifications
| Specification |
Detail |
| Wi-Fi Standard |
IEEE 802.11ax/ac/n/g/b/a (Wi-Fi 6) |
| Maximum Speed |
AX1800 (574 Mbps @ 2.4 GHz + 1201 Mbps @ 5 GHz) |
| Antennas |
2× internal antennas (2.4 GHz: 2 dBi; 5 GHz: 3 dBi) |
| Uplink Port |
1× Gigabit RJ45 (PoE 802.3at/af in) |
| Downlink Ports |
3× Gigabit RJ45 + 1× Gigabit RJ45 with PoE passthrough (802.3af) |
| Power Input |
PoE 802.3at (48 V); passive PoE 48 V |
| Max Power Consumption |
13.5 W (without PoE passthrough) |
| MIMO |
2×2 MU-MIMO (2.4 GHz & 5 GHz) |
| Max Concurrent Clients |
Up to 128 wireless clients |
| SSIDs |
Up to 16 (8 per band) |
| Security |
WPA3, WPA2, WPA, WEP; 802.1X; Guest Network |
| Management |
Omada App, Omada Software Controller, Omada Hardware Controller, Omada Cloud |
| Mounting |
Standard 86 mm wall plate (bracket included) |
| Dimensions |
86 × 86 × 37.8 mm |
| Operating Temperature |
0 °C to 40 °C |
| Certifications |
CE, FCC, RoHS |
Official Product Video
Watch the official TP-Link Omada EAP615-Wall overview to see how it simplifies in-wall Wi-Fi 6 deployment:
▶ View on YouTube — TP-Link Omada EAP615-Wall Overview
Note: Search "EAP615-Wall" on the TP-Link official YouTube channel for the latest product videos.
Recommended Accessories & Compatible Products
-
Omada PoE Switches — TL-SG2210P, TL-SG3210XHP-M2 — to power multiple EAP615-Wall units from a single switch
-
Omada Hardware Controllers — OC200, OC300 — for on-premises centralised management without a cloud subscription
-
Omada Router — ER7206, ER8411 — for full SDN stack with VPN, load balancing, and firewall
-
Cat6 Patch Cables & Keystone Jacks — for clean in-wall terminations
Downloads
Frequently Asked Questions
Does the EAP615-Wall require a controller to operate?
No. It can run in standalone mode via the Omada App for basic configuration. However, for multi-AP deployments, VLAN management, and advanced features, an Omada Software or Hardware Controller is strongly recommended.
What PoE standard does it require?
The EAP615-Wall requires an 802.3at (PoE+) uplink to operate at full capacity. If PoE passthrough to a downstream device is needed, ensure your switch budget accounts for the additional load (up to 15.4 W passthrough via 802.3af).
Will it fit a standard Australian wall plate?
The EAP615-Wall is designed for an 86 × 86 mm wall plate, which is a common international standard. It does not fit the standard Australian 2-gang or 1-gang grid plate directly — a compatible 86 mm wall box or surface mount enclosure is required. Check with your installer for the appropriate back box.
How many access points can I manage with one Omada controller?
The OC200 supports up to 100 devices; the OC300 supports up to 500 devices. The Omada Cloud-Based Controller (CBC) supports unlimited sites and devices under a subscription model.
Does it support seamless roaming between multiple APs?
Yes. When managed by an Omada controller, the EAP615-Wall supports 802.11r (Fast BSS Transition), 802.11k (Neighbour Reports), and 802.11v (BSS Transition Management) for seamless client roaming across your wireless network.
Is the EAP615-Wall suitable for outdoor use?
No. It is rated for indoor use only (0 °C to 40 °C operating temperature) and has no IP ingress protection rating. For outdoor deployments, consider the Omada EAP outdoor range.
