Power and data on one cable
All eight Gigabit ports supply PoE+ (IEEE 802.3af / 802.3at) up to 30 W each, with a 240 W total budget — powering and connecting cameras, access points and sensors while cutting cabling, PSUs and install time.
Fibre-ready uplinks
Two SFP slots let you run long-range fibre between buildings, cabinets and remote sites while keeping full Gigabit speed and reliability across the link.
True plug and play
Unmanaged Layer 2 operation means zero configuration. Connect your devices, apply power, and the TSW200 starts switching traffic immediately — perfect for fast network expansion.
Rugged & reliable
A full aluminium housing rated -40 °C to +75 °C with IP30 protection, 20 Gbps non-blocking switching and jumbo-frame support keep high-bandwidth video flowing in harsh conditions.
How many PoE ports does the TSW200 have?All eight Gigabit Ethernet ports supply PoE+ (IEEE 802.3af / 802.3at), so every port can power and connect a device such as an IP camera or access point.
What is the total PoE power budget?Up to 240 W across all ports at the PSE, with up to 30 W available per port. Full PoE operation requires a 44–57 VDC power supply.
Does it support fibre?Yes. Two SFP slots accept fibre transceivers for long-range, high-speed uplinks between cabinets, buildings or remote sites.
Do I need to configure it?No. The TSW200 is an unmanaged Layer 2 switch — connect your devices, apply power, and it works straight out of the box.
How fast is it?All eight ports are full Gigabit (10/100/1000 Mbps) with 20 Gbps non-blocking switching capacity and jumbo-frame support up to 9,216 bytes.
Is a power supply included?No. The PSU is ordered separately so you can match the voltage and capacity to your PoE load. Use a 44–57 VDC supply to power PoE devices.
Can it handle harsh environments?The full aluminium housing is IP30-rated and operates from -40 °C to +75 °C, suitable for cabinets, control panels and industrial sites.
How is it mounted?The TSW200 supports DIN-rail, wall (kit required) and flat-surface mounting for flexible installation in enclosures or on a panel.
What warranty applies in Australia?The TSW200 carries a 2-year (24-month) warranty, backed by local Australian support.
