Power and data on one cable
Four PoE+ ports (IEEE 802.3af / 802.3at) power and connect cameras, access points and sensors at the same time — cutting cabling, PSUs and install time on every site.
Built for vehicles & the edge
Runs straight off a 9–30 VDC supply or a 12 V / 24 V vehicle battery with no separate power brick, making it perfect for mobile CCTV, buses, fleets and remote enclosures.
True plug and play
Unmanaged Layer 2 operation means zero configuration. Connect your devices, apply power, and the TSW101 starts switching traffic immediately.
Rugged & reliable
A hardened aluminium housing rated -40 °C to +75 °C, 10 Gbps non-blocking switching and jumbo-frame support keep high-bandwidth video flowing in harsh conditions.
How many PoE ports does the TSW101 have?Four of its five Gigabit ports supply PoE+ (IEEE 802.3af / 802.3at). The fifth port is a standard Gigabit uplink without PoE.
What PoE standards are supported?It supports both IEEE 802.3af (PoE) and IEEE 802.3at (PoE+), delivering up to 30 W per port to powered devices such as IP cameras and access points.
Does it need a power supply?No separate PSU is required. The TSW101 runs on 9–30 VDC and can be powered directly from a 12 V or 24 V vehicle battery via its 2-pin socket.
Do I need to configure it?No. The TSW101 is an unmanaged Layer 2 switch — connect your devices, apply power, and it works straight out of the box.
How fast is it?All five ports are full Gigabit (10/100/1000 Mbps) with 10 Gbps non-blocking switching capacity and jumbo-frame support up to 9,216 bytes.
Is it suitable for in-vehicle use?Yes. It was designed for automotive and transport applications — mobile CCTV, buses, trains and fleet systems — with direct battery powering and a wide temperature range.
Can it handle harsh environments?The rugged aluminium housing is IP30-rated and operates from -40 °C to +75 °C, suitable for cabinets, vehicles and industrial sites.
How is it mounted?The TSW101 supports both DIN-rail and surface / flat mounting for flexible installation in enclosures or directly on a panel.
What warranty applies in Australia?The TSW101 carries a 2-year (24-month) warranty, backed by local Australian support.
