Dahua LM24‑H200 – Reliable 23.8″ Full High‑Definition Monitor for 24/7 Surveillance Use
Upgrade your video surveillance setup with the Dahua LM24‑H200, a sleek and reliable 23.8‑inch Full HD LED monitor designed for continuous use in security and professional environments. Featuring a 100 Hz refresh rate and ultra-fast 5 ms (OD) response time, it delivers smooth, motion‑blur‑free visuals—perfect for fast-moving footage. The VA panel ensures rich contrast and wide 178° viewing angles, even when placed off-centre.
Built for durability and simplicity, the LM24‑H200 comes with a narrow bezel design and ultra-light base, making it ideal for multi-monitor arrays. It includes HDMI, VGA, and audio input, plus integrated dual 1.5 W speakers, offering a complete display solution without extra peripherals. With low energy consumption, a 30,000-hour lifespan, and VESA 100 × 100 mm mounting, it’s perfect for 24/7 surveillance control rooms, NVR display stations, and professional workstations.
Features
- 23.8″ Full HD (1920 × 1080) VA panel
- 100 Hz refresh rate & 5 ms (OD) response time for sharp motion clarity
- 178°/178° wide viewing angles for flexible placement
- Narrow bezel and ultra-light base for multi-screen setups
- HDMI ×1, VGA ×1, and audio input with built-in dual speakers (1.5 W each)
- Energy-efficient design tailored for 24/7 use
- 30,000-hour panel lifespan
- VESA 100 × 100 mm mountable
- Suitable for surveillance, NVR displays, and pro video workstations
Technical Specifications
| Specification |
Details |
| Model |
DHI‑LM24‑H200 |
| Screen Size |
23.8″ (60.5 cm) |
| Panel Type |
VA LED |
| Resolution |
1920 × 1080 (Full HD) |
| Refresh Rate |
100 Hz |
| Response Time |
5 ms (OD) |
| Brightness / Contrast |
250 cd/m² / 4000 : 1 |
| Viewing Angle |
178° horizontal / 178° vertical |
| Display Colour |
8-bit (6-bit + FRC) |
| Inputs |
HDMI ×1, VGA ×1, Audio In ×1 |
| Speakers |
Built‑in ×2 (1.5 W each) |
| Power |
12 V DC (2 A external adapter) |
| Power Consumption |
17 W typical / 24 W max / <0.5 W standby |
| Dimensions |
541.8 × 326.4 × 47 mm |
| Weight |
3.2 kg net / 4.8 kg gross |
| Mounting |
VESA 100 × 100 mm |
| Operating Conditions |
0 °C to 40 °C, 10%–90% RH |
